SAMBA

1
SAMBA

• Server Message Block File Print Server

2
Service Profile

• Type System-V managed service
• Packages samba-common, samba-client
• Daemons nmbd, smbd
• Script smb
• Ports 137/udp, 138/udp 139/tcp
• Configuration /etc/samba/smb.conf

3
SaMBa

• Client Server for the Common Internet File
  System (CIFS)
• Microsoft's name for its SMB protocol
  implementation
• Contains components of the LanManager and NetBIOS
  protocols
• Samba may provide performance improvements over
  native CIFS
• Hhtp//www.samba.org

4
The goal of SAMBA

• A single integrated work-group spanning Windows
  and Linux machines

5
The view from Windows

• Linux based resources look identical to Windows
  based resources.
• Using Universal Naming conventions (UNC)
• \\toltec\spirit

6
The view from Linux

• smbstatus
• Processing section "homes
• Processing section "printers
• Processing section "spirit
• Samba version 2.2.6
• Service uid gid pid machine
• spirit jay jay 7735 maya
  (172.16.1.6) Sun Aug 12 1217 2005
• spirit jay jay 7779 aztec
  (172.16.1.2) Sun Aug 12 1249 2005
• jay jay jay 7735 maya
  (172.16.1.6) Sun Aug 12 1256 2005

7
The view from Linux

• Locked files
• Pid DenyMode R/W Oplock
  Name
• --------------------------------------------------
  --------------------------------------------------
  -
• 7735 DENY_WRITE RDONLY NONE
  /u/RegClean.exe Sun Aug 12 130122 2005
• Share mode memory usage (bytes) 1048368(99)
  free 136(0) used 72(0) overhead
  1048576(100) total

8
Samba Services

• Authentication Authorization of users
• File Printer Sharing
• Name Resolution
• Comprises part of WINS, allows mapping of NetBIOS
  names to IP addresses
• WINS is independent of DNS
• Browsing (service announcements)

9
WINS

• Windows Internet Naming Service (WINS)
• Microsoft's implementation of NetBIOS Name Server
  (NBNS) on Windows
• Handles naming in NetBIOS
• Workstations preload names at boot
• Distributed model
• No hierarchy
• Deprecated from Windows 2000 onwards
• DNS and Active Directory preferred but may still
  be present in mixed environments.

10
NetBIOS Names

• 16 Bytes in length
• 15 bytes for the selected name
• All standard characters a-z, A-Z, 0-9 and ! _at_
  ( ) - ' . are allowed.
• It is normal practice to use the same machine
  name for the DNS record and the NetBIOS record.
• The 16th byte indicates the unique service
  provided by the machine
• E.g. Standard Workstation Service is 00

11
Querying NetBIOS names

• C\gtnbtstat -a toltec
• NetBIOS Remote Machine Name Table
• Name Type Status
• ---------------------------------------------
• TOLTEC lt00gt UNIQUE Registered
• TOLTEC lt03gt UNIQUE Registered
• TOLTEC lt20gt UNIQUE Registered
• ...

12
Workgroups

• SMB groups are the same as Windows Workgroups.
• There are predefined group resource types.
• Nbtstat output
• NetBIOS Remote Machine Name Table
• Name Type Status
• --------------------------------------------------
  --------------
• METRAN lt00gt GROUP Registered
• METRAN lt1Egt GROUP Registered
• ..__MSBROWSE__.lt01gt GROUP Registered

13
Smb.conf sections

• Similar layout to the windows.ini file split into
  different sections
• global generic server or global settings which
  apply to each share
• homes used to grant some or all users access
  to their home directories
• printers defines printer resources and services

14
Sample global section

• Simple global section
• global
• Log file /var/log/samba/samba.log
• Load printersyes
• Max log size50
• Netbios nameRHL
• Server stringSamba Server
• WorkgroupTardis

15
Configuring File and Directory Sharing

• Shares should have their own section
• Options include
• Public- can be accessed by guest account
• Browseable share is visible in browse lists
• Writeable resource is read and write enabled
• Printable resource is a printer, not a disk
• Group all connections to the share use the
  specified group as their primary group

16
Example

• share Ronans Home Dir
• ronan-home
• Comment Ronans Home Directory
• Path /home/rbradley
• Browseableyes
• Writeableyes
• Public yes
• createMode0664
• DirectoryMode0775
• maxConnections1
• Printable no

17
Printing

• Printers defined in /etc/cups/printers.conf
• Global options as follows
• printers
• path /var/spool/samba
• browsable yes
• public yes
• guest ok yes
• writeable no
• printable yes

18
Printing

• LibertyLane
• Comment Staff Printer LaserJet 5
• printer prll
• valid users rbradley smcneally
• path /var/spool/prll
• public no
• writeable no
• printable yes
• By default, samba assumes printing is via cups,
  this can be overridden with the printing
  parameter in the global section

19
Other examples

• lp
• print command lpr -s -P p s rm s
• printable yes
• browseable no
• nec-raw
• comment Main PostScript printer driver for
  Windows clients printer
• driver NEC SilentWriter 95
• printable yes
• browseable yes

20
Supporting WINS

• Turn WINS support on add in global
• wins support yes
• Specify the name resolution order
• name resolve order wins lmhosts hosts bcast
• This step is unncessary as the default order is
  host lmhosts wins bcast

21
Name resolution options

• host means use the system resolver library to
  determine the IP address of a name
• lmhosts means to read name-IP mappings from the
  NetBIOS lmhosts file /etc/samba/lmhosts
• If this doesnt exist, lmhosts lookup will be
  skipped
• wins tells the server to maintain a WINS database
• Names will be added and updated as clients
  connect
• bcast uses the NetBIOS broadcast mechanism to
  find the addresses of all hosts
• Broadcast storms

22
Authentication

• There are a number of mechanisms for implementing
  Authentication in Samba
• By setting the security setting this can be
  controlled by administrators
• User Validation is done on a per-user basis,
  requiring a local smbpasswd file and also
  smbusers file
• Server Validation done by another server

23
Local file based Authentication

• When local file based authentication is used,
  specify that passwords should be stored encrypted
  in smb.conf
• encrypted passwords yes
• When server based authentication is used, specify
  the servers to be contacted for authentication
  information (used when security option is not
  user).
• password server host1 host2 host3

24
Adding users and setting passwords with local
authentication

• To add a user
• smbadduser ronan.bradleyrbradley
• UNIX Username Windows Username, need not match
• Encrypted (by default) passwords stored in
  /etc/samba/smbpasswd
• Users added with smbadduser and smbpasswd
• Users defined in /etc/samba/passwd must exist in
  /etc/passwd

25
Passwords with local authentication

• Encrypted passwords stored in /etc/samba/smbpasswd

• Users added with smbadduser and smbpasswd
• Users defined in /etc/samba/passwd must exist in
  /etc/passwd
• To add a user
• smbadduser rbradleyrbradley
• UNIX Username Windows Username, need not match
• Use smbpasswd for subsequent password changes
  for all users

26
Winbind

• winbind maps between windows user and group IDs
  and unix user and group IDs
• COMPrbradley or STUDENT\srooney6 or COMP\STAFF
  or STUDENTFT211-4

27
Linux Client access with Samba

• Smbclient is the standard client utility, useful
  for testing and for scripts
• Smbfs is an optional kernel component which
  allows Linux to mount an SMB share directly, in
  similar fashion to mounting an NFS share
• Not available on UML

28
Smbclient syntax

• If you do not specify usernamepassword,
  smbclient will use the upper case version of USER
  or LOGNAME variable and the PASSWORD variable (if
  set)
• If you use the U option
• smbclient U rbradleyletmein
• Not a great idea, as the command issued is
  visible in the history and in the ps information
• Smbclient includes an ftp-like shell

29
Sample smbclient L output

• smbclient -L toltec
• added interface ip172.16.1.1 bcast172.16.1.255
  nmask255.255.255.0
• Password
• DomainMETRAN OSUnix ServerSamba 2.2.5

• Sharename Type Comment
• --------- ------ --------------
• test Disk For testing
  only, please
• IPC IPC IPC Service (Samba
  2.2.5)
• HP Printer HP 932C on Maya
• ADMIN Disk IPC Service (Samba
  2.2.5)
• Server Comment
• --------- -------
• MAYA Windows 98
• MIXTEC Samba 2.2.5
• TOLTEC Samba 2.2.5
• ZAPOTEC
• Workgroup Master

30
Samba Daemons

• Nmbd NetBIOS name server
• Resource browsing
• WINS server
• Smbd SMB/CIFS server
• Authentication and authorization
• File and Printer Sharing

31
Samba Daemon

• When an SMB client starts, it needs to know the
  IP address being used by a particular host
• Client broadcasts this request on the network and
  receives a response from nmbd containing the
  NetBIOS information

32
Configuration Testing

• testparm is used to test the correct
  configuration of your samba settings
• To check what access will be granted to a given
  host, you can also supply the IP address of a
  given host
• testparm 147.252.224.78
• Will return which resources are accessible to
  that host

33
Samba Client

• smbclient can be used as a command-line file
  retrieval/transfer tool
• smbclient //machine/resource
• cd directory
• get file
• Also allows simple view of shared resources
• smbclient L hostname
• userpassword may be specified with the U option
  or by setting and exporting USER and PASSWORD
  environment variables

34
Samba Client

• If you do not specify usernamepassword,
  smbclient will use the upper case version of USER
  or LOGNAME variable and the PASSWORD variable (if
  set)
• If you use the U option
• smbclient U rbradleyletmein
• Not a great idea, as the command issued is
  visible in the history and in the ps information
• Smbclient includes an ftp-like shell

35
Sample smbclient L output

• smbclient -L toltec
• added interface ip172.16.1.1 bcast172.16.1.255
  nmask255.255.255.0
• Password
• DomainMETRAN OSUnix ServerSamba 2.2.5

• Sharename Type Comment
• --------- ------ --------------
• test Disk For testing
  only, please
• IPC IPC IPC Service (Samba
  2.2.5)
• HP Printer HP 932C on Maya
• ADMIN Disk IPC Service (Samba
  2.2.5)
• Server Comment
• --------- -------
• MAYA Windows 98
• MIXTEC Samba 2.2.5
• TOLTEC Samba 2.2.5
• ZAPOTEC
• Workgroup Master

36
smbmount

• SMB file system can be supported by the LINUX
  kernel
• Not available in UML
• Can use smbmount to mount a SMB-shared resource
• smbmount service mountpoint o options
• smbmount //server/resource /mnt/smb o
  usernamesmbuser
• Must set CONFIG_SMB-FS set on for smbmount to work

37
Samba mounts in /etc/fstab

• Samba mounts can be performed automatically upon
  system boot by editing /etc/fstab
• Specify
• the UNC path
• the local mount point
• smbfs as the file system and a
• username
• //server1/resource /mnt/smb smbfs
  deaults,usernamenobody 0 0

38
Samba Resources

• http//info.ccone.at/INFO/Samba/introduction.html
