DNA Network Analysis

1
Trust Factory Fact based analysis for Domino and
Lotus Notes
2
Table of Contents

• What is DNA? What are the wins?
• Problem statement
• Delivarables linked to Problem Statement
• Overall Health Check of entire Domino environment
  described
• Sample Reports

3
What is DNA?

• DNA collects information
• Log data configuration elements
• Off-site processing analysis
• Applied business intelligence
• Comparison with industry averages
• Interpretation
• In line with customer scope objectives
• Presentation

4
What does DNA offer?

• In-depth understanding of
• User demand system activity
• Resources capacity
• Performance issues
• Reduce cost increase efficiency
• Quick Wins
• Project Wins

5
What are Quick Wins?

• Reduce traffic footprint
• Increase quality efficiency
• Minimum investment in resources
• Short term
• Example network compression,
• internet passwords,
• group cycles,
• duplicate replicas

6
What are Project Wins?

• Identify eliminate project risks
• Taking corrective action before project instead
  of during or after
• Capacity planning
• Prevent over- under-capacity in server,
  network, Applications storage sizing
• Based on factual evidence versus assumptions
• Project Execution
• Fast risk free
• Project results verified with DNA facts

7
(assumed) Problem Statement

• Reduce Lotus Notes overcapacity and its
  costdrivers
• No insight in key cost drivers
• No detailled fact based view of total application
  landscape
• No facts on the real end user demand on those
  Applications
• No understanding of Application usage per office
  location
• No understanding of the cost reduction
  opportunities within Lotus Notes in general
• Detect chunks of overcapacity in the Notes
  Environment, in and outside the Application
  landscape
• No inside info on the real end user demand and
  patterns
• No fact based info available to determine new
  hardware requirements (if any)
• No information on user concurrency worldwide or
  per office location
• No what if data available for server placement
  scenarios

8
Deliverables linked to Problem Statement

• Measure and highlite the end user bandwidth usage
  per office location
• Do a complete Integrity Check to score on
  Operational wins
• Check user Concurrency and session time for
  office locations
• Compare the Network usage aswell as User
  concurrency with all the internal office
  locations
• Compare overall performance with Trust Factorys
  datawarehouse of 700K Corporate end users (Trust
  Factory Bench Mark)
• Compute per office location the concurrent user
  levels
• Report on the real end user demand of
  applications and compare this with the capacity
  in place
• Deliver facts about current usage of hardware and
  determine clean up roadmap for Application
  landscape
• Provide fact based data to achieve internal
  consencus

9
Overall Health Check

• Operational Health Check (Deployment Integrity
  Checks)
• Intergrity check - Duplicate Replica on same
  server
• - Duplicate template on same server
• - Replicas acting as different template
• - Same replica but different enheritance
• Consistency Check - Same file name but different
  Replica ID
• - Same Replica ID different filename
• - Same Replica ID different filepath
• - Same filepath but different Replica ID
• Missing Data in Addres Book
• Group Cycles
• Unsupported Characters in NAB
• Conflicting/Duplicate replica's
• HTTP Password Integrity check

10
Overall Health Check Continued

• Benchmarks
• Active users
• Network Bandwidth Consumption per user
• Document I/O per user
• Time spent online by users
• Overall User demand characteristics (Notes
  sessions, Document reads, etc)
• Other
• Storage Analysis and its trend growth
• Heavy user highlite
• Heavily used databases (!)
• Heavy databases
• Demand per database type
• Optimization opportunities in Server to Server
  replication
• Server utilization (User Concurrency), per region
  or office location
• Mail Routing overview and email top 50 users
• Recommandations

11
Next Report SamplesPlease note that each
report has the actual core data behind it. We can
zoom in to every minute of the day allowing great
discovery opportunities to investigate anomalies
or match a user complaint with the actual
performance measuredFollowing is just a
shorlist of examples
12
Consolidation Potential Example
Actual Potential Domino
Server locations 120 39 Domino
Servers 216 4 Registered
Users 58,691 25,250 Nr. of Domino
Versions 14 1 OS Platforms 6 1
After executing recommendations Depends on
server placement strategy
13
Consolidation Potential

• Consolidation Potential
• Today 54 server locations
• 89 servers in scope
• Results
• Sites / servers that can consolidate

100 scenario is not realistic, meant for
reference only
14
Migration Effort for Applications

• All datases, minus
• Mail Files
• From person documents in Domino directory
• Including replicas of these mail files on other
  servers
• Address Books
• Directories and Directory Catalogs
• System Databases
• DNAs list of known filepaths

15
Migration Effort for Applications
The tabel left comes with the actual factsheets
that allows forensic verification of each
touchdone on apps by the end users.
16
Active users versus registered users
17
User Profiles (time spent online)
Relative many Remote users for this Customer
18
DB Volume Growth (nr of databases)
19
Bandwidth Consumption, avg per hour
Peaks in demand, Monday morning
20
Demand Characteristics
21
Type user sessions Users working on mail file
or applications Mail/Calendar Notifications Backgr
ound replication
22
Existing Situation Concurrency
23
Zooming in on an issue Concurrency
Service Degradation on MiamiHub1
24
Demand per DB Type (IMPORTANT)
Most network demand on mail files for this
Customer
25
8.5 Network Compression will save gt 40
26
Heavy Users (shortlist)
username Db Transactions Network IO Document
IO CNLEI Funktion/OUGT/Oanonymized 66.09
64.05 72.81 CNOutBackService/OUGlostrup/O 4
.05 2.40 3.34 CNNotes-Kp Administrator/OUSys
tem/OUAdmin/O 2.51 1.36 3.31 CNFunktion/OU
GT/O 1.12 0.57 0.35 CNFunktion/OUGT/O
0.13 2.26 0.09
Addressing Heavy Users will save 54
27
Db Storage Distribution
28
Storage Analysis
29
Server Platforms Releases
30
Deployment Integrity

• High number of issues
• gt 1,000 in databases deployed
• gt 2,000 in domino directories

31
Database Deployment Integrity
Significant nr of issues identified. Recommended
to clean up to reduce HelpDesk calls.
Causes Risks. Use data spreadsheets to follow-up
and clean up.
32
Weak HTTP Passwords
7 of the internet passwords are insecure
33
What are DNA Benchmarks and how should we
interpret them?

• Provide an objective comparison of key
  performance indicators
• Consist of more than 700,000 corporate users from
  medium to large companies worldwide
• Developed / Owned by Trust Factory

34
Time spent online
Customer users spent less time per week while
sessions appear to be faster
ACME
Lowest Customer
DNA Average
Highest Customer
16.2
5.4
29.2
61.7
Hours per Week
3.7
1.2
9.6
28.4
Minutes per Session
35
Document Reads and Writes
Customer users read write LARGE amounts of
documents.
36
Network Bandwidth Consumption
37
Some References
