Title: 2003 NASA OSMA Software Assurance Symposium SARP Initiative 583


1
2003 NASA OSMA Software Assurance SymposiumSARP
Initiative 583
  • The Use of a Virtual System Simulator
    Executable Specifications to Enhance SW
    Validation, Verification, and Safety Assurance

An Introductory BriefingBy Ted Bennett Paul
Wennberg
31 July 2003
2
Definitions
  • Executable Specification (ES) Description of the
    dynamic behavior of a system or system element in
    an executable language, through the execution of
    which its behavior may be tested, validated
    verified. The ES used in this project are
    bounded with virtual interfaces analogous to the
    real parts they specify.
  • Detailed Executable (DE) Virtual embedded
    control system element simulation running the
    unmodified object software developed for its
    real-world counterpart.
  • Virtual System Integration Laboratory (VSIL)
    Virtual environment wherein embedded system
    element executable specifications and detailed
    executables may be interconnected and tested for
    verification validation purposes.

3
These Are the Problems
  • Most embedded SW faults traceable to ambiguities
    errors in system rqmts. 1,2,3
  • Poor comm. of rqmts. changes and poor comm.
    between teams during development also implicated
    as a major source of SW faults and significant
    schedule budget overruns 1, et al
  • Conventional fault injection-based testing
    limited by cost and schedule constraints
  • Present methods of collecting dynamic SW metrics
    are intrusive - typically requiring
    instrumentation of operating system or target
    software itself

4
Project Objectives
  • Evaluate viability benefit of maintaining test
    consistency between VSIL using ES, VSIL using
    DE running executable SW
  • Evaluate metric capabilities of VSIL
  • New types of dynamic metrics,easier capture
    methods
  • Reliability, accuracy benefit of noninvasive
    metric capture

5
Project Plan
  1. Create simplified simulation of Shuttle Robotic
    Manipulator System (Robotic Arm)
  2. VSIL simulation to comprise multiple ES and one
    computerized subsystem developed into DE
  3. Write test suite to VV system design
  4. Develop DE and control SW from target ES
  5. Rerun all system tests with DE substituted for ES
  6. Use VSIL to investigate metric objectives

6
ES in IcoSim VSIL
  • Hierarchical
  • Highly Bounded
  • Firmly Anchored in Reality

7
ES/DE Test Consistency
DirectSubstitution
  • Substitute DE for ES
  • Run same test sequences
  • When DE SW passes tests,it correctly
    implementsfunctionality verified in ES

8
Simulator Abstraction Charts
9
IcoSim Part Characteristics
  • Highly modular
  • Bounded
  • Hierarchical
  • Recursive
  • Abstract or Detailed
  • Simple or Complex
  • Definable intrinsic failure modes

Hierarchical yes, modular yes but definitely not
a Venn diagram!
10
Potential Contributions
  • Reduce interpretation induced SW faults due to
    ambiguities in system requirements
  • Improve ability for dynamic, noninvasive test of
    system SW response to failure conditions
  • Known behavioral characteristics failure modes
    of real part are intrinsic to virtual part and
    manifested under test control

11
Potential Contributions (Contd)
  • Reduce SW faults caused by breakdown in
    communication of system Rqmts changes
  • System design, ES, and DE changes verified in
    VSIL by Systems Engineering VSIL Development
    team
  • Updates to VSIL and all tests maintained under
    configuration control and distributed as they
    occur to all team members

12
Potential Contributions (Contd)
  • New capacity for empirical SW VV in cases where
    analysis was only viable means
  • Realistic fault injection failure mode testing
  • Complex digital signal processor designs
  • Complete VSIL also provides useful tool for
  • Post deployment command testing
  • Post deployment SW change testing
  • Anomaly/mishap analysis problem solving

13
Potential Contributions (Contd)
  • Reduce project development costs time by doing
    bulk of integration testing in VSIL during SW
    development phase

14
Project Status
  • Project started in April
  • ES-based simulator operational
  • System-level tests in development

Next Steps
  • Create DE and write control SW
  • Verify control SW passes system tests
  • Collect dynamic metrics

15
Questions?
Please stop by Friday for a demo
16
References
  • 1 Lutz, Robyn R. 1994. Analyzing Software
    Errors in Safety-Critical, Embedded Systems. Jet
    Propulsion Laboratory, California Institute of
    Technology, Pasadena, CA.
  • 2 Ellis, A. 1995. Achieving Safety in Complex
    Control Systems. Proceedings of the
    Safety-Critical Systems Symposium. pp. 2-14.
    Brighton, England. Springr-Verlag. ISBN
    3-540-19922-5
  • 3 Leveson N. G. 1995. Safeware - System,
    Safety and Computers. Addison Wesley 1995. ISBN
    0-201-11972-2
