Object Oriented Programming using VC

1
Object Oriented Programming using VC
2
Introduction

• Program Set of instruction written in a high
  level language
• High level language used for writing programs is
  also called as Programming Language
• Every Programming language has a compiler or an
  interpreter which merely translates the
  instructions issued in high level language to low
  level language that is understandable by the
  computer.
• Machine language comprises of zeros and ones (0
  and 1)

3
Programming Paradigms

• Paradigm is nothing but a style of programming
• Few paradigms are
• Structured Programming (C)
• Object Oriented Programming (C,Java,C,VB .Net)
• Object Based Programming (Java Script, VB Script)
• Event driven Programming (Visual Basic)
• Service Oriented Programming (Any web
  application)
• Component Based Programming (COM, CORBA)

4
Object Oriented Programming

• OOP is a programming style that is focused on
  objects
• Features of OOP
• Modularity
• Reusability
• Readability
• Maintainability
• Inheritance
• Polymorphism
• Abstraction
• Encapsulation

5
Structured Vs OOP
Structured OOP
Focuses on Process Focuses on Object
Follows Top Down Approach Follows Bottom Up Approach
6
Approaches in Software Development

• Top Down approach
• A Single module will be split into several
  smaller modules
• General to Specific
• Bottom Up approach
• Lot of small modules will be grouped to form a
  single large module
• Specific to General
• If the requirements are clear at the first
  instance we can go for Top down approach
• In circumstances where the requirements may keep
  on adding, we go for Bottom up approach

7
OOP Significance

• In real world scenario, for developing a
  software, we need requirements.
• But practically speaking, requirements keep on
  changing and request to add new features will
  keep on accumulating.
• So its better if we follow a bottom up approach
  I.e. Object Oriented Programming Strategy

8
OOP Extension

• With the advent of OOP, databases too started
  implementing the concept.
• Databases that make use of objects are called as
  Object Oriented Databases
• This simple maps a class in OOP to a table
• More explanation on notes page

9
Modularity

• Feature that enables us to split a single large
  module to several small sub modules
• Enables easy maintainability of code
• Enables easy readability and understandability of
  code
• Achieved in OOPS using functions

10
Maintainability and Readability

• Functions in OOPS enables maintainability and
  readability of code
• The presence of comments in code, enables the
  readability of the code
• Also in future if we want to get the
  functionality of our code, then comments will
  definitely of great help.

11
Reusability

• This feature enables us to re use the objects
  (functions, variables)
• Write Once, Use Any where, any number of times
• Since functions are independent piece of code,
  they can be used any number of times

12
Abstraction

• Showing only the essential features and hiding
  the unnecessary features
• The access modifiers in C or any OOP language,
  provides abstraction
• Functions also provide abstraction
• If a variable is declared as private, then other
  classes cannot access it
• The function name that is used in function call
  hides the implementation details from user. It
  shows only the outline of functionality that the
  function provides.

13
Encapsulation

• The process of bringing together the data and
  method of an object is called as encapsulation
• The data and method are given in the class
  definition
• Classes provides us with this feature -
  Encapsulation

14
Inheritance

• Feature that enables the characteristics or
  properties of a parent to reach its child
• C supports inheritance
• A class can inherit one or more classes
• Inherited class is called as parent class or
  super class or base class
• Class that inherits a parent class is called as
  child class or sub class or derived class

15
Polymorphism

• Poly Many
• Morph Form
• Polymorphism is the characteristic that enables
  an entity to co exist in more than one form
• C supports function overloading and operator
  overloading to implement polymorphism

16
Writing a simple C Program

• Open Microsoft Visual Studio -gt Visual C
• Click File -gt New
• In the dialog box, select Project Tab
• Select Windows Console Application
• Give a name for the project
• Click Files Tab
• Select C source files
• Give File name
• Click OK

17
Writing a simple C Program

• In the editor opened, type the code given at the
  notes page
• Save the file
• Compile the file
• This generates an exe for the project
• Build the file
• This generates an obj file for the source file
• Execute the file

18
Writing an OOP in C

• includeltiostream.hgt
• class Person // Class declaration
• private // Access specifier Private can be
  accessed
• int id // with in the class and objects of
  the class
• char name10
• public // Access specifier Public can be
  accessed
• void getDetails() // with in class and also
  outside class
• void showDetails()
• void PersongetDetails() // is called as
  scope resolution operator. Refer Notes page
• cout ltlt Enter Id
• cin gtgt id // characters entered through key
  board is pushed to variable id
• cout ltlt Enter Name
• cin gtgt name

19
Writing an OOP in C

• void PersonshowDetails()
• cout ltlt Id ltlt id ltlt endl
• cout ltlt Name ltlt name ltlt endl
• int main()
• Person p // Creating object for class Person
• p.getDetails() // invoking the classs method
• p.showDetails()
• return 0

20
Conditions

• if
• if..else
• If..elseif..else
• switch case

21
Loops

• While
• while(condn)
• Statements
• Do while
• do
• statements
• while(condn)
• For
• for( initialization condition cheking
  increment/decrement )
• body of for loop

22
Variables

• Variable names are case sensitive
• Variables can contain _, alphabets and numbers
• Variables should either start with an alphabet or
  an _ (underscore)
• Variable names should not be a reserved word

23
Data types

• Integer
• int a
• Float
• float b
• Double
• double c
• Char
• char d

24
Inline Functions

• By default all functions that are defined with in
  a class definition are inline functions
• If we wish to define a function outside class
  definition, and still want it to behave like an
  inline function, we need to use the keyword
  inline before the function return type in the
  function definition

25
Inline Functions

• If a function is declared as inline, then the
  function call will be directly replaced by the
  body of the function
• In non inline functions, if a function call is
  encountered, then the program execution saves the
  current context in stack and jumps to the memory
  location where the function is defined, executes
  it and returns back to the entry point.

26
Inline Functions

• Advantages with inline function
• Execution is made faster
• Stack overhead reduced
• Inline function is similar to preprocessor
  directives in C.
• If we give define MAX 5 in C, then wherever MAX
  comes in the program, it will be replaced by 5

27
Inheritance

• Feature by which an entity gets the
  characteristics or properties of its ancestors
• A class can derive properties and methods
  belonging to another class by means of
  inheritance
• The former is called as derived class or child
  class or sub class
• The latter is called as base class or parent
  class or super class

28
Types of Inheritance

• Simple
• A derived class inherits from one base class
• Multi level
• Inheritance in several levels One class per
  level
• Multiple
• A class inherits from more than one base class
• Hierarchical
• Several derived class inherits from a single base
  class
• Hybrid
• Combination of multiple and hierarchical
  inheritance. Also called as diamond inheritance

29
Inheritance

• A class can inherit the members and methods of
  another class in 3 ways
• Public
• Private
• Protected
• Private members cannot be inherited
• Only public or protected members can be inherited

30
Constructors

• Constructors are used for initializing data
  members of a class
• Constructors are always to be defined under
  public access
• Constructor is invoked whenever an object is
  created
• Name of the constructor is the class name
• Constructor should not contain a return type
• Constructor can contain one or more parameters

31
Destructors

• Destructors are used to release the memory used
  by the objects
• Destructors cannot have parameters or return type
• There is only one destructor for a class
• Destructors are invoked before the program
  execution ends
• Name of the destructor is a tilde symbol ()
  followed by class name and parenthesis
• cls()

32
Polymorphism

• Ability of an entity to co exist in more than one
  form
• Two types of polymorphism
• Static or compile time polymorphism
• Dynamic or run time polymorphism
• Static polymorphism is called as early binding
• Dynamic polymorphism is called as late binding

33
Static Polymorphism

• Three types of static polymorphism
• Constructor overloading
• A class can contain more than one constructors
• Function overloading
• A class can contain more than one function with
  the same name
• Operator overloading
• In a class, the normal behavior of an operator
  can be changed. I.e in addition to its normal
  behavior we can give additional functionality

34
Constructor Overloading

• Constructor overloading is said to be done on
  constructors if
• The number of parameters for the constructors are
  different
• If data type of the parameters for the
  constructors are different
• Eg. Class called Sample having constructors like
  Sample(), Sample(int a), Sample(int a, float b)
  and so on

35
Function Overloading

• Two or more functions with same name can co exist
  in the same class if they are overloaded. They
  are said to be overloaded functions if
• Return types of the functions are different
• Number of parameters in them are different
• Data types of parameters are different

36
Operator Overloading

• Syntax
• ltReturn typegt operator ltoperator to be
  overloadedgt (ltparameter listgt)
• body of the function
• Usage
• Obj.operatorltoverloaded operatorgt (values)

37
Dynamic Polymorphism

• Implemented via abstract classes and virtual
  function
• If we have given a function in base class as
  virtual function, then it means that its
  definition can be altered in the derived classes.
• Example
• virtual int area() 0
• We can give the definition for the function in
  the derived class

38
Templates

• Templates enforces reusability property of object
  oriented programming
• We can write functions using generic data types
  and while creating objects or calling functions,
  we can specify the data types
• Accordingly functions definition or classs
  definition will be changed to the required data
  type

39
Function templates

• template ltclass Tgt
• T max(T a, T b)
• return agtb?ab
• int main()
• cout ltlt maxltintgt(1,2)

40
Class Templates

• template ltclass Tgt
• class Test
• T val
• Test(T a)
• val a
• int main()
• Test ltintgt t1(10) //a is treated as int
• Test ltdoublegt t2(1.3) // a is treated as double
• return 0

41
Exception Handling

• Exception Error occurring at the run time or
  during execution
• Exceptions are not recognized during compilation
• C implements exception handling using try catch
  mechanism
• The portion of code that may cause exception is
  written with in try block.
• The catch block contains the code that need to be
  executed when exception occurs.

42
Example

• int main()
• int a10
• int b0
• try
• cout ltlt a/b //throws an exception
• throw(b)
• catch(int e)
• cout ltlt divide by zero exception ltlt e
• We can also reassign value of b and make the
  program to continue its execution in the catch
  block, instead of stopping the execution
• If catch() is present, then it is called as
  default exception

43
Namespaces

• Allows to group entities like classes, objects,
  functions under a name
• Format
• namespace ltltnamespace_namegtgt
• declarations and definitions

44
Using namespaces

• We can change the namespace that is being used
  currently by means of using directive
• We can declare alternate names for existing
  namespaces according to the following format
• namespace new_name current_name
• using ltltnamespace_namegtgt
• We can access members of namespace using a
  operator (scope resolution operator)
• ltnamespace_namegtltltmember_namegtgt
