F.M.E.A (Failure Mode and Effect Analysis)

1
F.M.E.A (Failure Mode and Effect Analysis)

• Chapter 14
• Ronette Braithwaite
• Tom Plotner

2
GOALS

• F.M.E.A.
• What is it?
• Why is it used?
• How it is used.
• Reliability
• What is it?
• Why it is important.
• Block Diagrams

3
How are we going to accomplish the goals?

• Implement quality!

4

• Survey

5
WHAT IS F.M.E.A??

• FMEA is an analytical technique that combines the
  technology and experience of people in
  identifying foreseeable failure modes of a
  product or process and planning for its
  elimination .
• FMEA can be explained as a group of activities
  intended to
• Recognize and evaluate the potential failure of a
  product or process and its effects
• Identify actions that could eliminate or reduce
  the chance of potential failures
• Document the process

6
Cont.

• FMEA attempts to detect the potential
  product-related failure modes
• FMEA uses occurrence and detection probability
  criteria in conjunction with severity criteria to
  develop risk prioritization numbers for
  prioritization of corrective action
  considerations
• FMEA is a team effort which the engineer has to
  involve the assembly, manufacturing, materials,
  quality, service, supplier, and the next customer
  (internal or external)

7
Benefits of FMEA

• Improves the quality, reliability, and safety of
  products / services / machinery and processes
• Improves company image and competitiveness
• Increases customer satisfaction
• Reduces product development timing and cost /
  support integrated product development
• Documents and tracks action taken to reduce risk
• Reduces potential for Warranty concerns
• Integrates with Design for Manufacturing
  Assembly techniques

8
Several types of F.M.E.A design FMEA, process
FMEA, equipment FMEA, maintenance FMEA, concept
FMEA, service FMEA, system FMEA, environmental
FMEA, and others.

• Design FMEA
• Identifies known and foreseeable failure modes
• Establishes priorities based on expected failures
  and the severity of those failures
• Reduces development time and the cost of
  manufacturing process

• Process FMEA
• Identifies potential failure modes prior to
  operation of the process
• Helps to establish priorities according to the
  relative impact on the internal or external
  customer
• Helps to identify potential manufacturing or
  assembly causes in order to establish controls
  for occurrence reduction and detection

9
Reliability

• Reliability defined
• The probability of a product to perform as
  expected for a certain period of time, under the
  given operating conditions, and at a given set
  for product performance characteristics.

10
Why is reliability important?

• Reputation
• Customer Satisfaction
• Warranty Costs
• Repeat Business
• Cost Analysis
• Customer Requirements
• Competitive Advantage

11

• What is the difference between Quality and
  Reliability?

12
TAKE A BREAK!!!!

• Come back in about
• 10-15 minutes

13
Block Diagram

• Is a simple, specialized, high-level type of
  flowchart.
• Provides a quick and uncomplicated overview of a
  process.
• Is used to design new processes or to simplify
  and understand existing processes.
• Is a starting point for process improvement.
•

14
Simple Block Diagram
15

Complex Block Diagram CELL PHONE

16
ACTIVITY
17
4 Stages of FMEA

• Specifying Possibilities
• Functions
• Possible Failure Modes
• Root Causes
• Effects
• Detection/Prevention
• Quantifying Risk
• Probability of Cause
• Severity of Effect
• Effectiveness of Control to Prevent Cause
• Risk Priority Number

• Correcting High Risk Causes
• Prioritizing Work
• Detailing Action
• Assigning Action Responsibility
• Check Points on Completion
• Re-evaluation of Risk
• a. Recalculation of Risk Priority Number

18

• Design FMEA
• View Handout

19
Failure Mode And Effect Analysis(Design FMEA)

• FMEA Number______________
• Page___________of__________
• Item ____________ Design Responsibility___________
  Prepared By _______________
• Mode Number/Year________Key Date__________FMEA
  Date (Orig.)____(Rev.)____
• Core Team_________________________________________
  _____________________

20
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• List the functions of the item
• Function should be written in verb-noun context
• Each function must be measurable
• Example
• Must hold an extra large coffee (16 oz)
• Heat transmission of less than xx deg

21
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• Failure modes should be described in technical
  terms
• Avoid to many details
• Example
• Does not hold 16 oz.
• Transmits heat too quickly

22
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• Effects must be listed from the customers point
  of view
• Also state whether the failure will impact
  personal safety or break any product regulations
• Many effects may exist for each failure mode
• Example
• Insufficient quantity of coffee
• Must fill too often
• Injury to person - burn

23
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• View severity chart
• The severity applies only to the effect of the
  failure, not the potential failure mode
• If a severity of 9 or 10 is selected an action
  should be considered before continuing
• Example
• Insufficient quantity of coffee severity 5
• Must fill too often
• Injury to person (burn) severity 10

24
Item/ Function Potential Failure Mode S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• Classify any special product characteristics for
  components, subsystems, or systems that may
  require additional process controls.

25
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• Must be listed completely and consciously
• There is usually more than one cause of failure
  for each failure mode
• Causes must be identified for a failure mode, not
  an individual effect
• Example
• Insulation material too thick
• Inside cup sized incorrectly
• Insufficient insulation

26
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• View occurrence chart
• Occurrence is based on the chance that one of the
  specific causes/mechanisms will occur
• Each cause must be rated on the probability of
  occurrences as it contributes to each failure
  mode
• Example
• Insulation material too thick occurrence 5
• Inside cup sized incorrectly occurrence 2
• Insufficient insulation occurrence 5

27
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• The activities that assure the design sufficiency
  for the failure mode or mechanism are listed
• Activities may include prevention measures,
  design validation, and design verification
• Three types of design controls
• Prevent the cause/mechanism or failure mode
  effect from occurring or reduce the rate of
  occurrence
• Detect the cause/mechanism and lead to corrective
  actions
• Detect only the failure mode

28
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• The first type is the preferred method to use
• Example
• Engineering specifications preventive control
• Historical data preventive control
• Functional testing detective control

29
Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• View detection chart
• Detection is the value assigned to each of the
  detective controls
• Example
• Engineering specifications no detection value
• Historical data no detection value
• Functional testing detection 3

30

Item/ Function Potential Failure Mode Potential Effect(s) of Failure S C L A S S Potential Causes(s)/ Mechanism(s) of Failure O Current Design Controls D R P N

• RPN (S) x (O) x (D)
• Values for the RPN can range from 1 to 1000
• RPN is used to rank the various concerns on the
  document
• Example
• Insufficient quantity of coffee severity 5,
  Inside cup sized incorrectly occurrence 2,
  Functional testing detection 3
• S 5 O 2 D 3 RPN 30
• Injury to person (burn) severity 10,
  Insufficient insulation occurrence 5,
  Functional testing detection 3
• S 10 O 5 D 3 RPN 150

31
Recommended Actions Responsibility and Target Completion Dates Action Results Action Results Action Results Action Results Action Results
Actions Taken S E V O C C D E T R P N

• Recommended actions should be focused on design,
  and directed toward justifying the cause of
  failure mode, or eliminating the failure mode
• Always begin with the concern with the greatest
  RPN and working in descending order

32
Recommended Actions Responsibility and Target Completion Dates Action Results Action Results Action Results Action Results Action Results
Actions Taken S E V O C C D E T R P N

• All recommended actions must have a person
  assigned responsibility for completion of the
  action
• There must be a completion date accompanying each
  recommended completion

33
Recommended Actions Responsibility and Target Completion Dates Action Results Action Results Action Results Action Results Action Results
Actions Taken S E V O C C D E T R P N

• A brief description of the actual action and its
  effective date should be entered
• Re-estimate the resulting severity, occurrence,
  and detection rankings after the corrective
  actions have been identified
• Recalculate and record the resulting RPN

34
Process FMEA
35
ACTIVITY
36
QUIZ
37
Occurrence numbers tell

• How bad a failure is
• The likelihood of completing the FMEA
• The chance of detecting a failure
• The probability of a failure

38
FMEA stands for _________ Mode and Effects
Analysis

• Founded
• Failure
• Function
• Fart

39
RPN development is the reason FMEAs are performed

• True
• False

40
Reliability is important to external and internal
customers?

• True
• False

41
There are only two types of FMEAs Design and
Process

• True
• False

42
Design FMEA should always begin with

• Risk priority number
• FMEA team
• Block diagram
• Failure rate

43
Is FMEA a team effort?

• True
• False

44
Does an organization need to implement FMEA to
achieve quality?

• True
• False

45
Design FMEA should always start with a _________.

• FMEA Team
• FMEA evaluation
• Block diagram
• Quality function deployment

46
Are you comfortable in conducting your own FMEA
document ?

• TRUE
