68HC11 Parallel I/O

1
68HC11 Parallel I/O

• Chapter 7

2
Microcontroller-Based System
To I/O
Microcontroller e.g. M68HC11
CPU Central Processor Unit I/O
Input/Output Memory Program and Data Bus
Address signals, Control signals, and Data signals
3
Terminology

• Pin This is a physical point that connects the
  microcontroller to the outside world.
• I/O Input /Output
• Input This is an input pin
• Output This is an output pin
• Bidirectional I/O This is pin which can be
  configured as either input or output.
• Port I/O register This is a data register that
  is physically connected to a set of I/O pins
• Control register This a control register used
  to configure the operation of a data port or some
  other function on the controller.

4
Terminology

• Memory-mapped I/O Microcontroller configuration
  in which external I/O is accessed using normal
  memory access instructions.
• The M68HC11 uses memory mapped I/O.
• This is in contrast to other microprocessors
  (e.g. Intel) which have a separate I/O address
  space and use special instructions to access it.

5
Review of Data I/O
6
Input Buffer
Din
Equation
Symbol
Input pin
Truth Table
Din Y
0 0
1 1
7
Output Buffer
Dout
Equation
Output pin
Symbol
Truth Table
A Dout
0 0
1 1
8
Another meaning of buffer

• The word buffer is also frequently used in
  computer engineering to refer to a region of
  storage (registers or memory) that is used to
  hold data temporarily while it is being (or
  waiting to be) sent or received.
• This usage is contrasted with an electrical
  buffer (previous slides) which just amplifies and
  delays a signal.

9
Tri-state drivers(Three-state drivers)
10
Multiple Outputs
Y
lower
A
A
Y
Y
0
1
raise
Chip A
Chip B
Let A_A 0
Let B_A 1
What is Y?
Unknown X
11
Tri-State Driver
Active-low signal OEn(Output Enable)
Equation
Symbol
Truth Table
A OEn Y
d 1 Z
0 0 0
1 0 1
High Impedance State
Open Circuit
12
One implementation
Of a tristate buffer in CMOS
Vdd
Output-drivinginverter
CMOSTransmissionGate
A
A
Y
OEn
GND
13
Multiple Outputs
Y Bus
Driver
Floating
0
1
raise
Chip A
Chip B
Let A_A1
Let B_A0
Y1
1
0
controller
14
Multiple Outputs
Y Bus
Floating
Driver
0
1
Chip A
Chip B
Let A_A0
Let B_A1
Y0
0
1
controller
15
Open Drain Output Drivers
16
Field Effect Transistors - FETS
A
FET acts like a switch If Vgate is ONE, switch
is closed, connecting A and B otherwise A and B
are isolated.
B
Field Effect Transistor (FET)
17
Open Drain Output Driver
We can use an FET as an Output Driver
When Din1, Dout0
When Din0, DoutZ
open circuit
How does Dout become an ONE?
18
Open Drain Output Driver
Use an external pull-up resistor
When Din1, Dout0 FET is ON, Dout0
When Din0, Dout1 FET is OFF, Dout is pulled up
to VDD
Why do this?
19
Simple Data I/O Control
Controller sends data to Chip-A and Chip-B
Halt
B
A
Data
However, either device can Halt the transfer by
bringing the halt line low.
Wired-OR configuration
20
Bi-Directional I/O Buffer/Drivers
21
Bi-directional I/O Driver

• Allows a single pin to be configured as an input
  buffer or an output buffer.

22
Bi-Directional I/O Buffer
Symbol
Tri-state Buffer
Function Table
From Ckt
OEn Function
0 Output mode
1 Input mode
dio Pin
ToCkt
Input Buffer
Note I/O buffer is either Input or output
23
Bi-Directional I/O Bufferas Input Buffer
Symbol
Floating
1
Dio
(Input)
To_ckt
Input Buffer
To_ckt Dio
24
Bi-Directional I/O Bufferas Output Buffer
Symbol
0
Active
Dio is From_ckt
From_ckt
Dio
(Output)
To_ckt
Note To_ckt is also From_ckt
Input Buffer
25
68HC11 Parallel I/O Ports

• Section 7.4

26
M68HC11 Port Summary

• PortA
• 1 bidirectional, 3 input, and 4 output port
• Timer port
• PortB
• 8-bit fixed output port
• Used for high byte of mem. addr. in expanded mode
• PortC
• 8-bit bidirectional parallel port
• Used for low byte of address for data in
  expanded mode
• PortD
• 6-bit bidirectional parallel or serial I/O port
• PortE
• 8-bit digital or analog input port

One of the 4 outputs isbidirectional on the E9
27
M68HC11E block diagram
From datasheet, p.17
28
Tangent on Operating Modes

• The HC11 has four operating modes.
• These are selected by input signals on the MODB
  and MODA inputs when the chip is reset.

(from HC11 Reference Manual, p.47)
29
Default Memory Maps of HC11E9
(From the HC11E series datasheet, p.37)
30
Ports B and C are mode-dependent
Reference manual, p. 62
31
Example pin connections in single-chip HC11
systems

• Very simple configuration.
• A small amount of external circuitry is still
  needed, for
• Power supply conditioning
• External clocking
• Low-voltage reset
• Setting mode bits
• Note there is no external ROM/RAM in this mode!
• But B and C ports are available for doing
  parallel I/O.

(Reference manual, p.117)
32
Demultiplexing address/datain Expanded modes
Datasheet, p. 34
33
Connecting External memory
Reference Manual, pp. 117-118
PC
PB
34
Connecting External Memory

• Note in this example, the 8K EPROM Chip is
  Selected (CS) if A13 A15 are high.
• And, A0-A12 are fed to the EPROM.
• Therefore, what range(s) of addresses does the
  EPROM chip map to?

Reference Manual, p. 118
35
Port A Address 1000

• An 8-bit, parallel I/O port.
• Data address 1000 (normally)
• Multi-Function
• I/O Port
• Timer Port
• PACTL Port A Control Register (1026)
• determines port function

36
Port A I/O Pin Modes

• Bits 0-2 Input Bits
• PA0-PA2
• Bits 3-6 Output Bits
• PA3-PA6
• Bit 7 Bidirectional Bit
• Direction set in PACTL

Except that PA3 isbidirectional in the E9
37
Port A - 1000 Data
I
I
O
I
O
O
O
B
Bits
Notation PA7 Bit 7 of Port A PA6 Bit 6 of
Port A PA5 Bit 5 of Port A . PA0
Bit 0 of Port A
OOutput I Input BBidirectional
38
Port A Circuit Schematic
This one is also bidirectional in the HC11Es
39
Port A I/O Port Mode

• Example
• Bit 7 configured as input (default)
• PortA EQU 1000
• Output a C to Port A
• Outdata EQU 01101000 Sets bits 3,5,6
• Output data to PortA
• LDAA Outdata
• STAA PortA
• Read Data from PortA
• LDAA PortA

40
PACTL 1026Port A Control Register
This is DDRA3 in the E series
DDRA7 Data Direction Register A7 0 Input
Direction (Default) 1 Output Direction PAEN
Pulse Accumulator System Enable 0 Disable
(Default) Port A is set for I/O
function 1 Enable Port A is set for
Pulse Accumulator function (part of timer
system, to be discussed later)
41
LED Circuit Example
Switch
Light On
Light Off
42
68HC11 LED Example

• Well use PA7 for Input, PA6 for output
• PA70 switch open, PA71 switch closed
• PA60 LED off, PA61 LED on
• Pseudo-code
• Configure PortA
• Repeat
• IF(PA70) then Switch is open
• PA60 Turn LED OFF
• Else
• PA61 Turn LED ON
• EndIF
• Until Forever

43
Program, using BRSET/BSET/BCLR

• These instructions allow us to manipulate
  individual bits, but they force us to use indexed
  addressing to refer to the I/O registers
• Extended direct mode is not available with these
  particular instructions

BIT6 EQU 01000000 Mask for bit 6 BIT7
EQU 10000000 Mask for bit 7 IOBASE EQU
1000 Base of I/O config
registers PORTA EQU 00 Offset
of PORTA (1000) PACTL EQU 26
Offset of PACTL (1026) start LDX IOBASE
Point X at I/O config registers
CLR PACTL,X Clear all PACTL control
flags. loop BRSET PORTA,X BIT7 on If port A
bit 7 is set, turn LED on BCLR PORTA,X
BIT6 else, turn LED off. (Clear bit 6)
BRA endif Go to end of if
statement. on BSET PORTA,X BIT6 Turn
LED on (set bit 6). endif JMP loop
Repeat.
44
Simulator Example
45
Port B

• 8-bit port
• Fixed Direction Output
• Data address 1004
• Writing to Address 1004 will write to the port.
• Example
• PortB EQU 1004
• Value EQU F2
• ...
• LDAA Value
• STAA PortB
• When the HC11 is in expanded mode, on boards with
  no Port Replacement Unit,
• Port B is reserved for the upper 8 address bits
  (AD9-AD15)

46
Port B - 1004 Data
O
O
O
O
O
O
O
O
Bits
OOutput
47
Port C

• 8-bit bidirectional port
• Data address 1003
• Multi-Function
• In single-chip mode, or with a Port Replacement
  Unit
• I/O Port
• Latched data from Port C is available at address
  1005
• Its latched when a rising edge occurs on STRA
  pin
• Handshaking port
• In expanded mode with no Port Replacement Unit,
• Used for low 8 bits (AD0-AD7) of memory address
  bus and for memory data bus (D0-D7)
• PIOC Parallel I/O Control Register C determines
  function

48
Port C - 1003 Data
B
B
B
B
B
B
B
B
Bits
OOutput I Input BBidirectional
49
DDRC - 1007
DDCn Data Direction Bit n
DDC0
DDC1
DDC2
DDC3
DDC4
DDC5
DDC6
DDC7
Bits
DDCn 0 Input (Default) 1 Output
50
PORTCL - 1005 Latched Data
B
B
B
B
B
B
B
B
Bits
OOutput I Input BBidirectional
51
PIOC - 1002 (STAF Bit)Parallel I/O Control
Register
INVB
EGA
HNDS
CWOM
STAI
STAF
OIN
PLS
Bits
STAF Strobe A Flag 0 Inactive
(default) 1 Set at the active edge
of STRA pin Read only bit. Used to determine
when data have been latched into Port C. Cleared
after bit has been set and read.
52
PIOC - 1002 (STAI Bit)Parallel I/O Control
Register
INVB
EGA
HNDS
CWOM
STAI
STAF
OIN
PLS
Bits
STAI Strobe A Interrupt Enable 0
No hardware interrupt generated (default)
1 Interrupt requested when STAF1 Enables
or disables the interrupt request from being
generated when STRA is asserted.
53
PIOC - 1002 Parallel I/O Control
Register(CWOM and EGA Bit)
INVB
EGA
HNDS
CWOM
STAI
STAF
OIN
PLS
Bits
CWOM Port C Wire-OR Mode 0 Normal
Outputs (default) 1 Open Drain
Outputs EGA Active Edge Select for STRA
0 Falling edge (High to Low) 1
Rising edge (Low to High)
54
Port D

• 6-bit
• Address 1008
• Multi-Function
• Bidirectional Port
• Serial I/O Port
• Serial Communications Interface (SCI)
• Asynchronous (i.e. no clock signal needed)
• Serial Peripheral Interface (SPI)
• Synchronous (i.e. a clock signal needed)

55
Port D - 1008 Data Register
B
B
B
B
B
B
X
X
Bits
XNot Used BBidirectional
56
DDRD - 1009
DDDn Data Direction Bit n
DDD0
DDD1
DDD2
DDD3
DDD4
DDD5
X
X
Bits
DDDn 0 Input (Default) 1 Output
57
SPCR - 1028 SPI Control Register
SPR0
SPR1
MSTR
DWOM
SPE
SPIE
CPOL
CPOH
Bits
SPIE SPI System Enable 0 Disable
(default) 1 Enable This bit should
be 0 to use Port D for parallel I/O
DWOM Port D Wire-OR Mode 0 Normal
Outputs (default) 1 Open Drain
Outputs
58
SCCR2 - 102DSCI Control Register 2
SBK
RWU
ILIE
RIE
TCIE
TIE
TE
RE
Bits
TE Transmit Enable 0 Disable
(default) 1 Enable This bit should
be 0 to used Port D for parallel I/O
RE Receiver Enable 0 Disable
(default) 1 Enable This bit should
be 0 to used Port D for parallel I/O
59
Port E

• 8-bit
• Address 100A
• Multi-Function
• Digital Input Port
• Analog Input Port (Built-in A/D)

60
Port E - 100A Data Register
I
I
I
I
I
I
I
I
Bits
OOutput I Input BBidirectional
61
Handshaking I/O

• Section 7.5

62
Problem

• Need to transfer data to and from Source to 6811

63
Several Approaches

• Simple Strobed I/O
• Full Handshaking I/O
• Lets look at several examples

64
Simple Strobed I/O

• Data Bus
• Single Control line between Source and 6811

Data Bus
Control Bus
65
Simple Strobed Input
Data source places data on bus, uses strobe to
indicate the data is now valid
66
Simple Strobed Input

• Timing Diagram

This edge indicates that the data are now valid
Use this edge to latch the data into the 6811
67
Simple Strobed Output
6811 uses strobe to indicate to the receiver
that Data are available
68
Simple Strobed Output

• Timing Diagram

This edge indicates that the data are ready
69
Simple Strobed I/O

• Advantage -
• Simple
• Disadvantage
• Must know timing relationship between data
  source/rcvr and 6811.
• Input How fast can 6811 accept new data.
• Output How fast can receiver accept data
  from 6811

70
Simple Strobed I/O Using the 6811

• Page 131

71
Simple Strobed I/O Using the 6811

• PORTC is used for strobed input
• Read data from PORTCL (1005)
• External pin STRA is used to latch data
• PORTB is used for strobed output
• External pin STRB is used as output ready

72
Simple Strobed I/O Using the 6811

• SET HNDS bit (bit 4) in PIOC control register
  (1002) to 0
• SET EGA bit (bit 1) in PIOC control register
  (1002) to desired active edge
• 0 High to Low (falling)
• 1 Low to High (rising)
• SET INVB to set active edge of output strobe
• 0 active low (High to low)
• 1 active high (low to high) (default)

73
Simple Stobed Input
Input Pins
74
Reading Input

• STAF bit in PIOC is set when new data are written
  into latch.
• Reading STAF bit will reset it to zero
• Lets look at an example

75
Reading Input

• Configure PortC for input
• Write 00 to DDRC (1007)
• Configure PortC via PIOC (1002) for
• No interrupts (STAI0)
• Active High Inputs (EGA1)
• Active High Outputs (INVB1)
• Simple Handshaking (HNDS0)
• Config bits 00000011

76
Reading Input

• Repeat
• Read STAF
• Until STAF1
• Read PORTCL (1005) This clears STAF

77
Simple Stobed Output
1004
78
Writing Output

• Writing to Port B will automatically assert the
  STRB pin for two clock periods.
• Use INVB to control the polarity on STRB
• 0 Active low
• 1 Active high

79
Full Handshaking I/O

• Page 130

80
Full Handshaking I/O Protocol

• Data Bus
• Two Control Lines

Data Bus
Control Bus
81
Full Handshaking I/O

• Disadvantages
• More complicated I/O
• Advantages
• Control timing relationship between 6811 and
  External Device

82
Input Handshaking

• Input Handshaking

• Ext. Device places data on bus
• Device asserts strobe to indicate data is
  available.
• Ext. Device asserts strobe to indicate
• acknowledgement or I have the data.

83
Input Handshaking
Data
STRA
STRF
Internal Flag
STRB
This edge indicates to the 6811 that data are
available.
This edge indicates to the External Device that
I have the data. Ext. Device can send the next
byte
84
Reading Input Full Handshaking

• Configure PortC for input
• Write 00 to DDRC (1007)
• Configure PortC via PIOC (1002) for
• No interrupts (STAI0)
• Active High Inputs (EGA1)
• Active High Outputs (INVB1)
• Full Handshaking (HNDS1)
• Input Handshaking (OIN0)
• STRB Level mode select (PLS0)
• Config bits 00010011
• Read input as in Simple Input example

85
Output Handshaking

• 6811 asserts STRB that says data are
  available.
• Ext. Device reads data.
• Ext. Device asserts strobe to indicate that
• I have the data. Ready for another byte.

86
Output Handshaking
Data
STRB
STRA
STRF
This edge indicates to the External Device that
data are available.
This edge indicates to the 6811 that I have the
data. 6811 can Send another data byte
87
Writing Full Handshaking

• Configure PortC for output
• Write FF to DDRC (1007)
• Configure PortC via PIOC (1002) for
• No interrupts (STAI0)
• Active High Inputs (EGA1)
• Active High Outputs (INVB1)
• Full Handshaking (HNDS1)
• Output Handshaking (OIN1)
• STRB Level mode select (PLS0)
• Config bits 00011011
• Read input as in Simple Input example
