Title: Binary Lesson 6 Classful Subnetting


1
Binary Lesson 6Classful Subnetting
2
Slash Notation
  • Consider a class A address of 1.2.3.4
  • The network portion is the first octet
  • 1
  • This situation can be written
  • 1.2.3.4/8
  • The number after the / is the number of bits in
    the network portion

3
Subnet Mask
  • Consider a class A address of 1.2.3.4 /8 in
    binary
  • The subnet mask is 255.0.0.0
  • The network address is 1.0.0.0
  • In Binary
  • IP 00000001 00000010 00000011 00000100
  • Subnt Msk 11111111 00000000 00000000 00000000
  • Net Addr 00000001 00000000 00000000 00000000

4
AND
  • To find the network address, take a node's IP
    address and do this
  • If the Subnet mask bit is 1, keep the IP address
    bit
  • If the Subnet mask bit is 0, that bit changes to
    0
  • This is called a bitwise AND operation
  • IP 00000001 00000010 00000011 00000100
  • Subnt Msk 11111111 00000000 00000000 00000000
  • Net Addr 00000001 00000000 00000000 00000000

5
Class B
  • Class B address 147.144.1.212 /16
  • The subnet mask is 255.255.0.0
  • The network address is 147.144.0.0
  • In Binary
  • IP 10010011 10010000 00000001 11010100
  • Subnt Msk 11111111 11111111 00000000 00000000
  • Net Addr 10010011 10010000 00000000 00000000

6
Class C
  • Class C address 192.168.1.10 /24
  • The subnet mask is 255.255.255.0
  • The network address is 192.168.1.0
  • In Binary
  • IP 11000000 10101000 00000001 00001010
  • Subnt Msk 11111111 11111111 11111111 00000000
  • Net Addr 11000000 10101000 00000001 00000000

7
192.168.1.0 /25
  • You can split a class C in half with a /25
  • IP 192.168.1.10 /25
  • Subnet Mask 255.255.255.128
  • Network 192.168.1.0
  • IP 11000000 10101000 00000001 00001010
  • Subnt Msk 11111111 11111111 11111111 10000000
  • Net Addr 11000000 10101000 00000001 00000000

8
192.168.1.0 /25
  • There are only 128 addresses in a /25 block
  • Network 192.168.1.0 /25
  • 1st Usable 192.168.1.1
  • Last Usable 192.168.1.126
  • Broadcast 192.168.1.127
  • Net Addr 11000000 10101000 00000001 00000000
  • First Use 11000000 10101000 00000001 00000001
  • Last Use 11000000 10101000 00000001 01111110
  • Broadcast 11000000 10101000 00000001 01111111

9
192.168.1.128 /25
  • There are only 128 addresses in a /25 block
  • Network 192.168.1.128 /25
  • 1st Usable 192.168.1.129
  • Last Usable 192.168.1.254
  • Broadcast 192.168.1.255
  • Net Addr 11000000 10101000 00000001 10000000
  • First Use 11000000 10101000 00000001 10000001
  • Last Use 11000000 10101000 00000001 11111110
  • Broadcast 11000000 10101000 00000001 11111111

10
192.168.1.0 /26
  • There are only 64 addresses in a /26 block
  • Network 192.168.1.0 /26
  • 1st Usable 192.168.1.1
  • Last Usable 192.168.1.62
  • Broadcast 192.168.1.63
  • Net Addr 11000000 10101000 00000001 00000000
  • First Use 11000000 10101000 00000001 00000001
  • Last Use 11000000 10101000 00000001 00111110
  • Broadcast 11000000 10101000 00000001 00111111

11
192.168.1.64 /26
  • There are only 64 addresses in a /26 block
  • Network 192.168.1.64 /26
  • 1st Usable 192.168.1.65
  • Last Usable 192.168.1.126
  • Broadcast 192.168.1.127
  • Net Addr 11000000 10101000 00000001 01000000
  • First Use 11000000 10101000 00000001 01000001
  • Last Use 11000000 10101000 00000001 01111110
  • Broadcast 11000000 10101000 00000001 01111111

12
192.168.1.128 /26
  • There are only 64 addresses in a /26 block
  • Network 192.168.1.128 /26
  • 1st Usable 192.168.1.129
  • Last Usable 192.168.1.190
  • Broadcast 192.168.1.191
  • Net Addr 11000000 10101000 00000001 10000000
  • First Use 11000000 10101000 00000001 10000001
  • Last Use 11000000 10101000 00000001 10111110
  • Broadcast 11000000 10101000 00000001 10111111

13
192.168.1.192 /26
  • There are only 64 addresses in a /26 block
  • Network 192.168.1.192 /26
  • 1st Usable 192.168.1.193
  • Last Usable 192.168.1.254
  • Broadcast 192.168.1.255
  • Net Addr 11000000 10101000 00000001 11000000
  • First Use 11000000 10101000 00000001 11000001
  • Last Use 11000000 10101000 00000001 11111110
  • Broadcast 11000000 10101000 00000001 11111111

14
Classful Subnetting iClicker Questions
15
What is the broadcast address in this
network?15.254.222.199 /8
  1. 15.255.255.255
  2. 15.254.255.255
  3. 15.254.222.255
  4. 15.254.222.0
  5. Something else

1 of 11
16
What is the broadcast address in this
network?215.2.1.254 /24
  1. 215.255.255.255
  2. 215.2.255.255
  3. 215.2.1.255
  4. 215.2.1.0
  5. Something else

2 of 11
17
What is the first usable address for this
network?185.2.1.0.2 /16
  1. 185.0.0.1
  2. 185.2.0.1
  3. 185.2.1.1
  4. 185.2.255.255
  5. Something else

3 of 11
18
What is the last usable address for this
network?147.144.1.212 /16
  1. 147.255.255.254
  2. 147.144.255.255
  3. 147.144.255.254
  4. 147.144.1.254
  5. Something else

4 of 11
19
What is the first usable address for this
network?147.144.1.0 /25
  1. 147.0.0.1
  2. 147.144.0.1
  3. 147.144.1.1
  4. 147.144.1.255
  5. Something else

5 of 11
20
What is the last usable address for this
network?200.0.14.0 /24
  1. 200.255.255.254
  2. 200.0.255.254
  3. 200.0.14.254
  4. 200.0.14.255
  5. Something else

6 of 11
21
What is the last usable address for this
network?200.0.14.0 /25
  1. 200.0.14.126
  2. 200.0.14.127
  3. 200.0.14.254
  4. 200.0.14.255
  5. Something else

7 of 11
22
What is the last usable address for this
network?200.0.14.128 /25
  1. 200.0.14.126
  2. 200.0.14.127
  3. 200.0.14.254
  4. 200.0.14.255
  5. Something else

8 of 11
23
What is the last usable address for this
network?200.0.14.128 /26
  1. 200.0.14.126
  2. 200.0.14.62
  3. 200.0.14.254
  4. 200.0.14.190
  5. Something else

9 of 11
24
What is the last usable address for this
network?200.0.14.64 /26
  1. 200.0.14.126
  2. 200.0.14.62
  3. 200.0.14.254
  4. 200.0.14.190
  5. Something else

10 of 11
25
What is the last usable address for this
network?200.0.14.64 /26
  1. 200.0.14.126
  2. 200.0.14.62
  3. 200.0.14.254
  4. 200.0.14.190
  5. Something else

10 of 11
26
What is the first usable address on this
subnet?222.0.0.192 /26
  1. 222.0.0.194
  2. 222.0.0.254
  3. 222.0.0.129
  4. 222.0.0.192
  5. Something else

11 of 11
