RS RT series

• RS RT industrial circular connectors are
  a range of multiway connectors available in 8
  shell sizes and 8 insert arrangements all
  intermateable. RS RT is equipped with
  identical shells from military connectors
  complying to MIL-C-26482 spec.
• Features and benefits
• Suitable for shielding applications
• Available in 8 shell sizes and 9 insert
  arrangements.
• Available in plug and receptacle versions for
  both male and female contacts.
• Different insert orientations possible.
• Plastic inserts with flammability rating
  UL94-V0.
• 2 levels of water protection Dynamic IP67 and
  IP68 both versions are IP69K
• 2 levels of salt spray 48h and 96h
• Metal bayonet ring
• - Metal wave spring loaded
• - Locks with audible positive click
• Assures 500 matings and unmatings
• Operating temp -40C to 105C or 125C
• Insulation resistance 5000 MO min.
• Test potential 2000 VAC (standard)
• RoHS compliant

Amphenol Sine Systems NEW PRODUCTS 2009
3
Order guide 1__Plug Receptacle
Part numbering Sequence(????)
RT 0 6 16 19 P
N (H or H6) (Design variation)
(Plating)
RT RS
shell size
Type of contacts
Application
EC- end cap standard seal for wire 1814 AWG
MM- end cap reduced seal for wire 2420 AWG
0 standard 0W high density
Insert arrangement
Insert Polarisation
Body variation

• Notes
• Body variation 0 Wall mounting receptacle
• 6 Cable plug
• 7 Jam nut
  receptacle for rear panel mounting
• Shell size 10, 12, 14, 16, 18,
  20, 22, 24
• Insert arrangement
• Type of contacts P Pin contacts
• S Socket
  contacts
• Insert polarisation N Standard version
• W, X, Y, Z
  Different orientations (consult factory)

Application no letter standard version (no
o-ring) H Standard version, water protection IP
67 IP 69K H6 Water protected IP 68 IP 69K
(only needed for wall mounting jam nut
receptacles) Design variation No letter
Standard version
Others Special versions Plating No letter
standard is nickel plating (48h salt spray) 1
Black anodised, jam nut (96h salt spray) 2 Black
anodised coupling ring (96h salt spray)
Amphenol Sine Systems NEW PRODUCTS 2009
4
Order guide 2__contacts
1. Stamped formed contact (?????)
SS 20 M (---) 1 F
Contact Type Wire Awg size contact size Contact Packaging Design Variation Plating
SPMale 14(crimp AWG 14) Msize 16 Blank 3,000 pc reel 1wire and insulation crimp for size 20-26 TTin
SSFemale 16(crimp AWG 1816) Wsize 20 Lloose piece 1Wire crimp for size 14 16 FGold Flash
20(crimp AWG 2220) A2.5mm 11Wire and insulation crimp for size 16 GGold (plating thickness blank10u" if other thickness, pls label the thickness, for example 30u", label "G30"
24(crimp AWG 2624)
12(crimp AWG1412)
..
Amphenol Sine Systems NEW PRODUCTS 2009
5
Order guide 2__contacts
2. Machined contact (?????)
MS 20 M (---) 23 F
Contact Type Wire Awg size contact size Contact Packaging Design Variation Plating
MPMale 14(crimp AWG 1614) Msize 16 Bulk pack 23crimp barrel TTin
MSFemale 16(crimp AWG 2016) Wsize 20 12E0 PCB tail, for RT00( wall mouting receptacle) "" is outer length of PCB tail. FGold Flash
20(crimp AWG 2220) A2.5mm 12E7 PCB tail, for RT07( Jam nut mouting receptacle) "" is outer length of PCB tail. GGold (plating thickness blank10u" if other thickness, pls label the thickness, for example 30u", label "G30"
24(crimp AWG 2624) A2.5mm 12E7 PCB tail, for RT07( Jam nut mouting receptacle) "" is outer length of PCB tail. GGold (plating thickness blank10u" if other thickness, pls label the thickness, for example 30u", label "G30"
28(crimp AWG 3028) RS8Radsok 3.6mm,crimp barrel Splating silver(5um)
12(crimp AWG1412)
6(Crimp 65AWG, 16mm2)
8(Crimp 87AWG, 10mm2) ..
Amphenol Sine Systems NEW PRODUCTS 2009
6
Order guide 2__contacts
3. Rocksolid contact
MS 20 M (---) 23 F
Contact Type Wire Awg size contact size Contact Packaging Design Variation Plating
RSFemale 14(crimp AWG 1614) Msize 16 Bulk pack 23crimp barrel FGold Flash
16(crimp AWG 2016) Wsize 20 GGold (plating thickness blank10u" if other thickness, pls label the thickness, for example 30u", label "G30"
20(crimp AWG 2220)
24(crimp AWG 2624) ..
Amphenol Sine Systems NEW PRODUCTS 2009
7
RS RT series different point

• RS SERIES
• RockSolid female contact

• RT SERIES
• Stamped contact

• Formed contact

Amphenol Sine Systems NEW PRODUCTS 2009
8
Connector types
Wall mounting receptacle for Pin contacts RT00 ?????????????
Type 1 RT001619PN
No O-ring
Type 2 RT001619PNH
O-ring
Type 3 RT001619PNHEC
End-Cap Waterproof IP67
Amphenol Sine Systems NEW PRODUCTS 2009
9
Connector types
2. Wall mounting receptacle for socket contacts RT00 ?????????????
Type 1 RT001619SN
No O-ring
Type 2 RT001619SNH
O-ring
End-Cap Waterproof IP67
Type 3 RT001619SNHEC
Amphenol Sine Systems NEW PRODUCTS 2009
10
Connector types
3. Jam nut receptacle for Pin contacts RT07 ????????????
Type 1 RT071619PN
No O-ring
Type 2 RT071619PNH
O-ring
End-Cap Waterproof IP67
Type 3 RT071619PNHEC
Amphenol Sine Systems NEW PRODUCTS 2009
11
Connector types
4. Jam nut receptacle for socket contacts RT07 ????????????
Type 1 RT071619SN
No O-ring
Type 2 RT071619SNH
O-ring
Type 3 RT071619SNHEC
End-Cap Waterproof IP67
Amphenol Sine Systems NEW PRODUCTS 2009
12
Connector types
5. Cable plug for pin contacts RT06 ??????????
Type 1 RT061619PN
No O-ring
Type 2 RT061619PNH
O-ring
Type 3 RT061619PNHEC
End-Cap Waterproof IP67
Amphenol Sine Systems NEW PRODUCTS 2009
13
Connector types
6. Cable plug for socket contacts RT06 ??????????
Type 1 RT061619SN
No O-ring
Type 2 RT061619SNH
O-ring
Type 3 RT061619SNHEC
End-Cap Waterproof IP67
Amphenol Sine Systems NEW PRODUCTS 2009
14
Backshell solution(????????)__Cord grip
1. Shielded cable clamp with strain relief nut
for waterprotected applications(IP68)
Length
EMI shielding ring (Beryllium copper)
Thread A
Picture Sine P/N Shell Size Clamping range (F mm min/Max) Total length (mm) Thread A
RT0L-10CG-S1 10 3/6.5 50 9/16 24 UNEF
RT0L-10CG-S2 10 5/8.5 50 9/16 24 UNEF
RT0L-12CG-S1 12 6/10.5 54 11/16 24 UNEF
RT0L-12CG-S2 12 8/12.5 54 11/16 24 UNEF
RT0L-14CG-S1 14 6/10.5 54 13/16 20 UNEF
RT0L-14CG-S2 14 8/12.5 54 13/16 20 UNEF
RT0L-16CG-S1 16 9.5/14.5 60 15/16 20 UNEF
RT0L-16CG-S2 16 13.5/18 60 15/16 20 UNEF
RT0L-18CG-S1 18 9.5/14.5 60 1 1/16 18 UNEF
RT0L-18CG-S2 18 13.5/18 60 1 1/16 18 UNEF
Amphenol Sine Systems NEW PRODUCTS 2009
15
Backshell solution(????????)__Cord grip
2. Cable clamp with strain relief nut for
waterprotected applications(IP68)
Length
No EMI shielding ring
Thread A
Picture Sine P/N Shell Size Clamping range (F mm min/Max) Total length (mm) Thread A
RT0L-10CG-C1 10 3/6.5 50 9/16 24 UNEF
RT0L-10CG-C2 10 5/8.5 50 9/16 24 UNEF
RT0L-12CG-C1 12 6/10.5 54 11/16 24 UNEF
RT0L-12CG-C2 12 8/12.5 54 11/16 24 UNEF
RT0L-14CG-C1 14 6/10.5 54 13/16 20 UNEF
RT0L-14CG-C2 14 8/12.5 54 13/16 20 UNEF
RT0L-16CG-C1 16 9.5/14.5 60 15/16 20 UNEF
RT0L-16CG-C2 16 13.5/18 60 15/16 20 UNEF
RT0L-18CG-C1 18 9.5/14.5 60 1 1/16 18 UNEF
RT0L-18CG-C2 18 13.5/18 60 1 1/16 18 UNEF
Amphenol Sine Systems NEW PRODUCTS 2009
16
CORD GRIP ASSEMBLY
Step 1 ?
Step 2 ?
Step 3 ?
Step 4 ?
Step 5 ?
EMC Grounding Ring
Amphenol Sine Systems M23 and M40 Connectors .
Confidential Information . For Internal Use
Only
17
Backshell solution(????????)__Flexgrip
Amphenol Sine Systems NEW PRODUCTS 2009
18
FLEX GRIP ASSEMBLY
Step 1 ?
Step 2 ?
Step 3 ?
Step 4 ?
Step 5 ?
Step 6 ?
Amphenol Sine Systems M23 and M40 Connectors .
Confidential Information . For Internal Use
Only
19
Sealing for wall mounting receptacle (??????????,?
??)
Part number
RTFD12B
RTFD13B
RTFD14B
RTFD15B
RTFD16B
Amphenol Sine Systems NEW PRODUCTS 2009
20
Metal environmental dustcap receptacles
For dustcap without chain skip G e.g. RT010DC
Part number
RT010DCG
RT012DCG
RT014DCG
RT016DCG
RT018DCG
Amphenol Sine Systems NEW PRODUCTS 2009
21
Application(??)

• ???????????MIL-C-26482???????,??????
• ???????
• ???????????
• ?????????
• ????????
• ?????????????
• ??????????
• ???????,??????,????

?????????
??????
Amphenol Sine Systems NEW PRODUCTS 2009
