Mathematical Ideas that Shaped the World

1
Mathematical Ideas that Shaped the World

• Graphs and Networks

2
Plan for this class

• What was the famous Königsberg bridge problem?
• What is a graph?
• Why was the 4-colour theorem controversial?
• How are soap bubbles and slime mould good at town
  planning?
• Why is it so hard for salesmen to be efficient?
• How does Google work?

3
The Seven Bridges of Königsberg
4
The Seven Bridges of Königsberg

• Once upon a time there was a city called
  Königsberg in Prussia.
• It was founded in 1255 by the Teutonic Knights,
  and was the capital of East Prussia until 1945.
• It was a centre of learning for centuries, being
  home to Goldbach, Hilbert, Kant and Wagner.

5
The Seven Bridges of Königsberg

• Running through the city was the River Pregel.
• It separated the city into two mainland areas and
  two large islands.
• There were 7 bridges
  connecting the various
  areas of land.

6
The Seven Bridges of Königsberg

• The residents of Königsberg wondered whether they
  could wander around the city, crossing each of
  the seven bridges once and only once.
• Can you find a way?

7
Leonhard Euler (1707 1783)

• Born in Basel, Switzerland, and was expected to
  become a pastor like his father.
• Studied Hebrew and theology at university, but
  got private maths lessons from Johann Bernoulli.
• In 1727 got a job in the medical section at the
  Uni of St Petersburg

8
Leonhard Euler (1707 1783)

• but in the chaos surrounding the death of
  Empress Catherine I, he managed to sneak into the
  maths department.
• Got married in 1733 and had 13 children, of whom
  5 survived to adulthood.
• In 1741 moved to Berlin, where he spent 25 years.

9
Leonhard Euler (1707 1783)

• Published over 500 books and papers in his
  lifetime, with another 400 posthumously.
• Invented the notation i, p, e, sin, cos, f(x) and
  more!
• Lost sight in both eyes but became more
  productive, saying
• now I have fewer distractions

10
Back to Königsberg

• In 1736 Euler turned his mind to the problem of
  the bridges of Königsberg.
• He realised that it didnt matter how you walked
  around the land, or where exactly the bridges
  were.
• It only mattered how many bridges there were
  between each bit of land, and in what order you
  crossed them.

11
Reformulating the problem

• With this observation, we can re-draw the bridges
  of Königsberg as follows

12
Conditions for a solution

• Eulers Eureka! moment was realising that
  whenever you cross into a bit of land, you also
  have to cross back out of it.
• Therefore, for a bridge tour to be possible,
  there must be an even number of bridges coming
  out of every bit of land.
• (Except for the starting and finishing points.)

13
An impossible problem!

• If we look again at the map of Königsberg, we see
  that there are an odd number of bridges coming
  out of every bit of land, so such a walk around
  the city is impossible.

14
Königsberg extra

• Look at your handout to learn about these
  characters.
• Can you make them all happy?

15
Postscript on Königsberg

• Königsberg was heavily bombed during World War
  II.
• The city was taken over by Russia and re-named
  Kaliningrad.
• Two of the 7 bridges were destroyed

Question Is the bridge problem possible now?
16
The beginning of graph theory

• By solving the problem the way he did, Euler
  invented the subject of graph theory.
• A graph is a collection of nodes and edges.

• It doesnt matter how long the edges are or where
  the nodes are it only matters which edges are
  connected to which nodes.

edge
node
17
Examples of graphs
Train maps
18
Examples of graphs
Social networks
19
Examples of graphs
Chemical models
20
The Four Colour Theorem
21
The Four-Colour Problem

• Proposed by Francis Guthrie in 1852 and remained
  unsolved for more than a century.
• Can any map be coloured with 4 colours so that no
  two adjacent regions have the same colour?

22
Example of a 4-colouring
23
Why not 3 colours?

• A simple example shows that it impossible to
  always colour a map with only 3 colours.

24
Why not 5 colours?

• It was proved by 1890 that every map can be
  coloured with at most 5 colours.
• The difficult part of the problem was to show
  that there was no map sufficiently complicated as
  to need 5 colours.
• Martin Gardner set the following graph as a
  problem to his readers. Can you colour it using
  only 4 colours?

25
Martin Gardners map
26
In terms of graphs

• The 4-colour problem can be phrased in terms of
  graphs.
• Each region of the map becomes a node, with two
  nodes being connected by an edge if and only if
  the regions are adjacent on the map.
• The problem becomes can you colour the nodes
  with 4 colours so that an edge never connects two
  nodes of the same colour?

27
Maps to graphs example
28
A proof?

• In 1976, two men called Kenneth Appel and
  Wolfgang Haken announced that they had a proof of
  the conjecture.

29
A controversial result

• They had made a computer program to check the
  4-colouring of all possible examples (1,936 of
  them!).
• It was the first mathematical theorem to be
  proved with computer help, and aroused much
  controversy.

30
An inelegant result

• One critic said
• A good mathematical proof is like a poem. This
  is a telephone directory!
• However, the proof is now widely accepted and
  computers are used in many areas of pure
  mathematics.

31
Building efficient graphs
32
Building the shortest graphs

• Very often we have a set of points and want to
  find the shortest collection of edges that
  connect them up. For example,
• Roads/railways connecting towns
• Telephone/internet cables
• Gas pipes
• Connections in electronic circuits
• Neurons connecting bits of your brain

33
The shortest graph?

• Suppose we have 4 towns that we wish to connect
  up. Which of these do you think is shortest?

34
An unexpected solution

• If were restricted to roads between towns, then
  the first graph is the shortest.
• But there is a better solution, which we can find
  using a bit of perspex and some soap bubbles

35
Soap bubbles know best

• So the best solution is to create two ghost towns!

36
How do they do it?

• We currently have no (fast) algorithm for finding
  the shortest Steiner graph between a given number
  of points.
• Nature, on the other hand, is quite good at it.
• http//www.youtube.com/watch?v0lpsLCgCp2Q

37
Slime mould is better than politicians

• Scientists studied slime mould growing in a
  region shaped like Tokyo, placing food sources
  where the major regional cities would be.
• The resulting slime mould network was remarkably
  similar to the Tokyo train network.
• In some respects it was actually better!

38
Slime mould networks
Tokyo train network
Slime mould
39
Finding the shortest route
40
The Chinese postman problem

• Now suppose that the towns and roads are fixed,
  and we know the distances between them.
• The Chinese postman problem asks what is the
  shortest route that travels over every road at
  least once and returns to the start?

5
3
5
9
8
8
6
4
9
41
The Chinese postman problem

• Heres how to solve the problem
• If the graph is Eulerian (i.e. an even number of
  edges out of every node) then each edge can be
  walked exactly once, so we are done.
• If not, find the shortest distances between the
  nodes with odd numbers of edges, and add extra
  edges to turn it into an Eulerian graph.

42
Chinese postman example
B
C
5
5
3
9
8
A
D
8
4
9
6
F
E
43
The travelling salesman problem

• If, instead, you are a travelling salesman, you
  wish to find the route that allows you to visit
  each town exactly once (and then return to the
  start).
• This problem was posed as long
  ago as 1800 by the Irish
  mathematician Hamilton, and
  rose drastically in popularity
  in the 1950s and 60s.

44
The Icosian Game
45
(Or the travel version!)
46

• This is the poster for a contest run by Proctor
  Gamble in 1962.
• There were 33 cities in this problem.

47
A tantalising problem

• Unlike the Chinese postman problem, nobody has
  ever found a fast algorithm for solving the
  Travelling Salesman Problem (TSP).
• Deciding whether there is a route shorter than a
  given length is an NP-complete problem.
• Finding a good algorithm is currently worth 1
  million!

48
Methods of solving the TSP

• Brute force try all possible routes and pick
  the fastest one.
• Caveat using todays fastest supercomputer,
  solving the 33-city problem using this method
  would take about 100 trillion years!

49
Methods of solving the TSP

• Branch and bound algorithms divide the problem
  into smaller graphs and try to eliminate edges
  that cant be part of the solution.
• The record set with this kind of exact method is
  85,900 cities, which took over 126 CPU years to
  compute in 2006.

50
Methods of solving the TSP

• Heuristics find good solutions which are
  highly likely to be close to the perfect
  solution. For example,
• The nearest neighbour algorithm lets the salesman
  pick the nearest unvisited city every time.
• Find any route, then rearrange edges to find a
  shorter one.

51
Methods of solving the TSP

• Heuristic algorithms can find solutions to TSP
  with millions of cities in a fairly short amount
  of time.
• Caveat these solutions may not always be the
  best possible.

52
Have a go!

• Humans are surprisingly good at finding solutions
  to TSP quite quickly.
• Play the following game online to see how good
  you are!
• http//www.tsp.gatech.edu/games/tspOnePlayer.html

53
Applications

• The Travelling Salesman Problem has lots of
  applications in our lives
• Logistics of delivering goods
• Drilling holes in circuit boards
• Genome sequencing
• Programming space telescopes like Hubble
• Collecting post from postboxes every day
• Making travel itineraries
• X-ray crystallography

54
How does Google work?
55
The internet to Google

• Google sees the internet is a giant graph.
• Each webpage is a node, and two pages are joined
  by an edge if there is a link from one page to
  the other.
• Note the edges in the internet graph have a
  direction.
• The algorithm that Google uses to rank its
  searches is called PageRank.

56
How does PageRank work?

• Idea the more links a page has pointing to it,
  the more important it is.
• Second idea if an important page links to your
  page, this is worth more than if an unimportant
  page links to you.
• For example, Wikipedia referencing you is worth
  more than Haggis The Sheep referencing you.

57
Example
58
Using PageRank to make money!

• People who understand PageRank can make it very
  lucrative for them.
• For example, businesses or individuals with a
  high page rank can sell links to those wishing to
  boost their page rank.
• Businesses have also used similar algorithms to
  rank universities in the job market.

59
Social networking

• Graphs are also important to social networking
  sites like Facebook.
• By analysing the preferences of your friends
  and pages that you like, Facebook can target
  its advertising very effectively.

60
Making recommendations

• Similarly, shops like Amazon use graphs to make
  suggestions for future shopping.
• In 2009 the US company Netflix awarded 1 million
  to the people who best improved their
  recommendation algorithm.
• (One of the problems was that they could never
  predict whether someone would like the film
  Napoleon Dynamite!)

61
Lessons to take home

• That Graph Theory is an incredibly important part
  of modern-day life.
• That a solution to a single graph theory problem
  can have many different real-world applications.
• That slime mould is often cleverer than humans.
• That problems in graph theory can be worth a lot
  of money!

62
References

• Here are some good places to read more about the
  subjects in todays lecture.
• Four Colour Theorem http//nrich.maths.org/6291
• Four Colours Suffice by Robin Wilson, Penguin
  Books, 2003
• A comprehensive website about the Travelling
  Salesman problem http//www.tsp.gatech.edu/
• A New York Times article about the NetFlix prize
  http//www.nytimes.com/2008/11/23/magazine/23Netfl
  ix-t.html
