Integumentary System

1
Integumentary System

2
Integumentary System

• Epidermis (epithelial tissue)
• Dermis (connective tissue)
• Hypodermis (not part of the skin)

3
(No Transcript)
4
(No Transcript)
5
Hypodermis

• subcutaneous layer (underneath the skin)

6
Hypodermis

• contains areolar and adipose tissue

7
Hypodermis

• attaches skin to underlying tissues and organs

8
Hypodermis

• Conatains pacinian corpuscles ( sensitive to
  pressure / looks like an onion)

9
Epidermis

• Stratified Squamous epithelium
• 4 different types of cells
• 5 layers

10
Types of Cells in Epidermis

1. Keratinocytes
2. Melanocytes
3. Langerhans
4. Merkel

11
Keratinocytes

• 90 of epidermal cells

12
Keratinocytes

• produce the protein keratin which protects the
  skin and underlying tissues from heat, microbes,
  and chemicals

13
Keratinocytes

• produce lamellar granules which produce a water
  repellant sealant

14
Melanocytes

• 8 of epidermal cells

15
Melanocytes

• Produces the pigment melanin

16
Melanocytes

• Transfers melanin granules to keratinocytes

17
Melanocytes

• In keratinocytes the melanin granules acts like
  an umbrella over the DNA in order to protect it
  from UV light

18
Langerhans

• migrate from red bone marrow to epidermis

19
Langerhans

• involved in immune response

20
Merkel

• sensitive to touch

21
Merkel

• located in stratum basale

22
Merkel

• Have contact with the flattened process of a
  sensory neuron (Merkel disc)

23
5 layers of Epidermis

1. Stratum Basale
2. Stratum Spinosum
3. Stratum Granulosum
4. Stratum Lucidum
5. Stratum Corneum

24
Stratum Basale

• Deepest layer of the epidermis

25
(No Transcript)
26
Stratum Basale

• Single layer of cuboidal or columnar
  keratinocytes

27
(No Transcript)
28
Stratum Basale

• Nuclei large

29
Stratum Basale

• Also contains some melanocytes, merkel cells, and
  langerhans cells

30
Stratum Spinosum

• 8 to 10 layers of squamous shaped keratinocytes

31
(No Transcript)
32
Stratum Spinosum

• Has a large nucleus

33
Stratum Spinosum

• Appear spiny underneath microscope

34
Stratum Spinosum

• Some langerhans cells and melanocytes

35
Stratum Granulosum

• 3 to five layer of squamous keratinocytes

36
(No Transcript)
37
Stratum Granulosum

• Undergoing apoptosis (cell death)

38
Stratum Granulosum

• Nuclei disappearing

39
Stratum Granulosum

• Contains protein keratohyalin which converts
  tonofilaments into keratin

40
Stratum Granulosum

• Secretes lamellar granules which fills the spaces
  between stratum granulousum, stratum lucidum, and
  stratum corneum

41
Stratum Lucidum

• Only in thick skin

42
(No Transcript)
43
Stratum Lucidum

• 3 to 5 layers of clear, dead, squamous
  keratinocytes

44
Stratum Lucidum

• Contain keratin

45
Stratum Corneum

• 25 to 30 layers

46
(No Transcript)
47
Stratum Corneum

• Dead squamous keratinocytes

48
Stratum Corneum

• Contain keratin

49
Stratum Corneum

• Sometimes forms callus (the stratum corneum is
  abnormally thick)

50
Dermis

• Two Regions
• Papillary Region
• Reticular Region

51
Papillary Region

• Contains areolar connective tissue with fine
  elastic fibers

52
(No Transcript)
53
Papillary Region

• 20 percent or one fifth of dermis

54
Papillary Region

• Contains Meisner corpuscles ( sensitive to
  touch)

55
Papillary Region

• Contains dermal papillae (small,fingerlike
  projections that indent the epidermis and some
  contain capillary loops)

56
(No Transcript)
57
Reticular Region

• Contains dense irregular connective tissue with
  collagen fibers and course elastic fibers

58
Reticular Region

• Contain some adipocytes, hair follicles,
  nerves, sebaceous glands, and sweat glands

59
(No Transcript)
60
(No Transcript)
61
Skin Color

• Melanin
• Carotene
• Hemoglobin

62
Melanin

• Number of melanocytes doesnt vary among people

63
Melanin

• Differences in skin color can be attributed to
  the amount that these melanocytes produce

64
Melanin

• Melanocytes most commonly found in the epidermis
  of the penis, nipples, face and limbs

65
Melanin

• Freckles and age spot (accumulations of melanin)

66
Carotene

• Yellow-orange pigment
• Precursor to vitamin A

67
Carotene

• Found in stratum corneum, fatty areas of dermis,
  and hypodermis

68
Hemoglobin

• Protein in rbcs that carries oxygen
• Found in capillaries in blood

69
Albinos

• Contain melanocytes, but are unable to produce
  melanin
• Inherited
• Melanin is absent in hair, eyes, and skin

70
Vitiligo

• Irregular white spots
• Due to loss of melanocytes
• Antibodies in body attack melanocytes

71
Types of Skin

1. Thin Skin
2. Thick Skin

72
Thin Skin

• Covers all surfaces except palms, fingertips,
  and soles

73
(No Transcript)
74
Thin Skin

• Lacks stratum lucidum
• Thin stratum spinosum and corneum

75
Thin Skin

• Lack epidermal ridges (fingerprints)

76
Thin Skin

• Fewer sweat glands
• Fewer sensory receptors

77
Thin Skin

• Contains hair follicles, arrector pili muscles,
  and sebaceous (oil) gland

78
(No Transcript)
79
Thick Skin

• Located on palms, fingertips, and soles

80
(No Transcript)
81
Thick Skin

• Stratum Lucidum
• Thicker stratum spinosum and corneum

82
Thick Skin

• Contains epidermal ridges
• Contains more sweat glands

83
Thick Skin

• Lacks hair follicles, sebaceous glands, and
  arector pili muscles

84
Accessory Structures

1. Hair
2. Glands
3. Nails

85
Hair

• Shaft
• Superficial portion of hair

86
Hair

• Root
• Penetrates into dermis

87
Hair

• Root and Shaft contain three layers
• Inner medulla(may lack in thin hair), cortex
  (contains pigment granules), and cuticle

88
Hair

• Hair Follicle
• Surrounds the root of the hair
• Contains an external root sheath (continuation of
  epidermis) and internal root sheath (produced by
  the matrix)

89
Hair

• Bulb
• Contains papilla of hair (areolar connective
  tissue and blood vessels to nourish hair)
• Contains matrix (produce new hairs)

90
(No Transcript)
91
(No Transcript)
92
Hair

• Sebaceous glands and arrector pili muscle
  associated with hairs

93
Hair

• Arrector pili muscle responsible for goose
  bumps

94
(No Transcript)
95
(No Transcript)
