Ponaganset High School Fuel Cell Initiative Program

1
Ponaganset High School Fuel Cell Initiative
Program

• 1923 Fuel Cell Ford Model T Project

2
3
Objective

• To build a hydrogen/electric fuel cell hybrid
  vehicle by converting a gasoline powered 1923
  Ford T Bucket vehicle, using the batteries as
  primary power, and the fuel cell as a range
  extender.

4
Goals
Vehicle Goals

• 70 mph average highway travel speed
• 100 Mile Range using fuel cells
• 30 Mile Range on Batteries
• Fuel Cell will act as a range extender

5
(No Transcript)
6
Energy Dynamics of Electric Vehicles
7
Fuel Cells will act as range extenders
8
Project Goals

• Battery Electric completion June 2006
• Travel to Rhode Island State House, Roger
  Williams Park/Zoo, Local Sponsors, and
  Washington, D.C.
• Advocate hydrogen fuel cell technology

9
(No Transcript)
10
While on our travels

• We plan to visit a hydrogen refueling station in
  Washington, D.C

11
Technical Data
Fuel Cell

• Hydrogenics HyPM12 Proton Exchange Membrane 12 kW
  Fuel Cell
• Measures 37.72 L x 20.24 W x 14.25 H
• Weighs 211.64 lbs

12

• The hydrogenics HyPM12 12 kW fuel cell is very
  versatile, operating between 50-104 degrees
  Fahrenheit, as well as being built for mobile
  operation and to handle several of natures
  abilities such as humidity and heat.

13
Technical Data (Continued)
Batteries

• (12) 12 Volt Optima D-31

14
Technical Data (continued)
Motor

• 30HP DC Motor

15
Funding
Several of PHS Fuel Cells Sponsors

• US Department of Defense
• Fuel Cell Test and Evaluation Center
• RI State Energy Office

16
Funding (continued)

• RI Resource Recovery Corp.
• Praxair
• Logan Energy

17
But.

• This project isnt only made possible by the
  previously mentioned sponsors.
• It is made most possible by the dedicated team of
  support and enthusiasts that operate continuously
  both behind the scenes and publicly.

18

• This FCT is still a work in progress, and it
  seems like we are over the hump and each task
  completed makes us closer and closer to finishing
  the goals we have set.

19
In Conclusion

• Building a street legal Hydrogen Fuel Cell/
  Battery Electric vehicle will promote effective,
  clean, renewable energy and demonstrate to all
  that it doesnt take millions of dollars to
  create a cleaner environment, but the willpower
  and perseverance to make it happen.

20
The End
