Title: Automated Driver Testing System


1
(No Transcript)
2
Automated Driver Testing System
Objective
  • Standardize and automate the procedure of
    evaluating the driving skills of a driver
  • Eliminate subjective opinion of an examiner
  • Same yardstick will assess every candidate
  • Ability to drive a vehicle on different types of
    road is checked

3
Automated Driver Testing System
Skill Assessed
  • Ability to drive on various shaped and size like
    S, H and 8 shaped road and any customized
    shaped road
  • Ability to drive forward on a road with upward
    gradient without any backward movement
  • Parking a vehicle while driving in reverse
  • Identifying traffic symbols

4
Automated Driver Testing System
Advantages
  • No subjectivity-earlier multiple examiner at
    locations rated driving on subjective assessment
  • Because of the GPS Based System the Driver get
    all the information on the desk
  • Automated Display of the Traffic signal on the
    Wireless Billboard Board helps the driver for
    proper guidance on the track
  • Total transparency
  • Consistency in selection
  • No disturbance to operational staff at depots and
    divisions
  • Prevents untrained drivers from getting in to the
    system
  • Ensure selection only on merit
  • No scope for extraneous consideration
  • Ease, Efficiency, Economy and equity
  • Installation cost recoverable from processing
    fees in a short period

5
Automated Driver Testing System
Salient Features
  • Special tracks with a system of sensors embedded
    in the tracks
  • Real time data transfer to central location
  • The system awards mark automatically
  • On completion of all tests, the results are
    printed and handed over to the candidate
    immediately
  • Biometric based secure identification of the
    candidate
  • Wireless Display Board for displaying different
    traffic signals
  • GPS Based navigation system for the correct
    driving experience
  • Any type of vehicle including LMV, LCV

6
Automated Driver Testing System
7
Automated Driver Testing System
Types of Test
  • Negotiation of S shaped road with proper
    indication of Speed and traffic signals using GPS
    based system and Wireless Display board.
  • Measures time duration to complete test and any
    poles movement
  • Automated generation of traffic signals on the
    Wireless billboard board for testing proper
    skills of the driver.

8
Automated Driver Testing System
Types of Test
  • Negotiation of 8 shaped road with proper
    indication of Speed and traffic signals using GPS
    based system and Wireless Display board.
  • Measures time duration to complete test and any
    poles movement
  • Automated generation of traffic signals on the
    Wireless billboard board for testing proper
    skills of the driver.

9
Automated Driver Testing System
Types of Test
  • Negotiation of H shaped road with proper
    indication of Speed and traffic signals using GPS
    based system and Wireless Display board.
  • Measures time duration to complete test and any
    poles movement
  • Automated generation of traffic signals on the
    Wireless billboard board for testing proper
    skills of the driver.
  • Different type of Forward Entrance, Reverse,
    Forward and Forward Exit Tests has been carried
    out in this test

10
Automated Driver Testing System
Types of Test
  • Negotiation of Gradient shaped road with proper
    indication of Speed and traffic signals using GPS
    based system and Wireless Display board.
  • Measures time duration to complete test and any
    poles movement
  • Automated generation of traffic signals on the
    Wireless billboard board for testing proper
    skills of the driver.

11
Automated Driver Testing System
Traffic Signal Test (Kiosk based Signal Test)
  • The candidate will be displayed with 4 road
    signals along with 8 options out of which 4 will
    be correct answer.
  • The candidate has to match the symbol with the
    correct answer in the options provided.
  • The time allotted for this test is 2 minutes.
  • The candidate will be given 1 mark for every
    correct answer.

12
Automated Driver Testing System
Traffic Signal Test (Kiosk based Signal Test)
13
Automated Driver Testing System
How it Works
  • The Automatic Driver Testing System will make
    use of optical/proximity based sensors which will
    be connected over to central control unit.
  • The software will check the status of each sensor
    while test is performed and time taken and
    generate report for each user. On completion of
    test, the system will generate the test result
    automatically. The data will be logged in central
    database
  • During the Test Drive the Driver should follow
    all the rules displayed on the Wireless Display
    Board and Control the speed using the GPS based
    system.

14
Automated Driver Testing System
System Flow
  • User registers on website or on designated center
  • User gets a Test Call on mobile SMS or an email
  • User reaches at Test Center and provide documents
    and call ID
  • User details are registered such as, photos,
    personal information, address etc. with biometric
    fingerprint
  • User undertake the all required tests
  • The system stores all details during test and
    generate a Test Report once all tests are
    completed
  • User go to RTO center with given result to
    collect a driver license
  • RTO issue a driver license by verified users
    result and fingerprint details

15
Automated Driver Testing System
System Requirement
  • Land for testing center
  • Construction work of Test Routes/Tracks
  • Sensors and controllers for Automated Driver Test
    system
  • Software application
  • Computers with Printer
  • Server for Database
  • Intranet/Internet Network connection
  • Wireless Display Board
  • GPS Based System

16
Automated Driver Testing System
Software Application
Application Screenshots
8 Test
Real Time Sensor Details
Candidate Number
Candidate Details with Photo
Test Duration Details
Number of Poles Knock Down
17
Automated Driver Testing System
Software Application
Application Screenshots
S Test
Real Time Sensor Details
Candidate Number
Candidate Details with Photo
Test Duration Details
Number of Poles Knock Down
18
Automated Driver Testing System
Software Application
Application Screenshots
Reverse Parking Test
Real Time Sensor Details
Candidate Number
Candidate Details with Photo
Test Duration Details
Number of Poles Knock Down
19
Automated Driver Testing System
Software Application
Application Screenshots
Up Gradient Test
Real Time Sensor Details
Candidate Number
Candidate Details with Photo
Test Duration Details
Number of Poles Knock Down
20
Automated Driver Testing System
21
Automated Driver Testing System
Contact Us
Saltriver Infosystems Pvt. Ltd. B-11, Premium
House, Ellis bridge, Ahmedabad, Gujarat,
India Phone 91-79-26580392,26574356 www.saltrive
r.com
