Implications of Securing

1

• Implications of Securing
• Router Infrastructure
• NANOG 31
• May 24, 2004
• Ryan McDowell
• ryanm_at_sprint.net

2
Control Plane Packet Filters

• Receive Access-List (rACL) on Cisco
• Input filter on Lo0 on Juniper
• Deployed in 2002
• Deny IP fragments
• Permit SSH, SNMP, DNS, TACACS, NTP, etc
• secured by src/dst pairs
• Permit BGP, IGMP, PIM
• Permit subset of ICMP
• Permit UDP gt 1024
• do not break traceroute to the router
• Deny everything else
• and count it

3
(No Transcript)
4
(No Transcript)
5
Control Plane Packet Filters

• How we deployed Cisco rACLs
• 1. Build the access-list
• 2. Replace all deny statements with permit
• 3. Deploy on several routers
• 4. If you get matches where you shouldnt,
• change to permit/log and see what it is
• 5. Repeat until no more unexpected matches
• Constantly improve
• Add src/dst pairs, reduce src/dst ranges, etc

6
Control Plane Packet Filters

• Good IP addressing strategy needed
• Made routers harder to kill
• Really helps with the magic packet attacks
• Few operational implications
• Sprints routers are broken because I cannot
  ping your router with a 1501/4471 byte
  (fragmented) packet.
• Change control can be difficult
• Routers still vulnerable to attacks against
  TCP/179, ICMP, IP options, UDP, etc

7
Limit Reachability To Control Plane IP Addresses

• Most attacks target IPs on routers obtained from
  a traceroute
• Lets remove the ability to reach
  SprintLink-Customer /30 networks from the big
  dangerous Internet

8
Route 192.0.2.0/24 to Null0
.5
192.0.2.4/30
.6
9
.5
192.0.2.4/30
.6
10
Limit Reachability To Control Plane IP Addresses

• Does not add 100 security
• But makes it a little harder for the attacker
• 25 of customers required the use of their
  point-to-point address
• Took over a year to implement
• Implications
• Traceroute through the router not impacted
• Any packets to the routers breaks
• PING
• Folks LOVE to PING our routers
• Traceroute

11
Limit Reachability To Control Plane IP Addresses

• Do the same thing in the core
• advertise-passive-only in Cisco
• IS-IS export policy in Juniper

12
.4
192.0.2.4/31
Route 192.0.2.0/24 to Null0
.5
.6
192.0.2.6/31
.7
13
Limit Reachability To Control Plane IP Addresses

• RFC1918 loop backs for management (SNMP, SSH,
  iBGP, etc.)
• Rate limiting rACL
• CoPP (Control Plane Policing) on Cisco
• Apply BTSH/GTSH to rACL
• Ignore IP-Options
• Forward packets as if there are no options set
• Similar to no ip source-route on Cisco

14
What does all this mean?

• Dont plan on sending any packets destined to the
  router.
• But this is already happening with the
  MPLS-ization of networks.
• More secure infrastructure
• Not perfect, but better than where most of us are
  now
• Can be done without ingress filtering which is
  hard

15

• References
• http//www.cisco.com/univercd/cc/td/doc/product/so
  ftware/ios120/120newft/120limit/120s/120s22/ft_ipa
  cl.pdf
• http//www.juniper.net/solutions/literature/app_no
  te/350013.pdf
