Mitosis in Onion Root Tip Cells

1
Mitosis in Onion Root Tip Cells
2
(No Transcript)
3
Onion root tip mitosis
Interphase

• cell grows in size
• cell replicates DNA in preparation for mitosis
• individual chromosomes not clearly discernable
• nucleolus may be visible as dark spot
• nucleus is apparent

4
Onion root tip mitosis
Prophase

• chromatin in nucleus begins to condense and
  becomes visible under light microscope
• spindle fibers (microtubules) attach to
  centromeres of chromosomes
• nuclear envelope starts to break down

5
Metaphase
Prophase
6
Onion root tip mitosis
Metaphase

• spindle fibers align chromosomes along center of
  cell (metaphase plate)

7
Onion root tip mitosis
Anaphase

• as spindle fibers shorten, paired chromosomes
  separate and move to opposite sides of cell

8
Onion root tip mitosis
Telophase

• chromosomes are at opposite sides of cell
• nuclear envelope reforms
• cytokinesis begins, in which a new cell wall will
  be created along the metaphase plate and two
  daughter cell will be formed

9
(No Transcript)
10
View of Onion root tip using 400x magnification
11
Overview of phases of mitotic cell cycle
interphase
interphase
prophase
metaphase
anaphase
telophase
