11i Cloning Panel

1
11i Cloning Panel

• Panel Moderator
• Sandra Vucinic

2
Panel Members

• Lynne Paulus - Fair Isaac Company
• John Stouffer Solution Beacon
• James Lui - Employers Insurance Group
• Steve Noynaert RingMaster Software
• Sandra Vucinic VLAD Group, Inc.
• Panel Contributors
• Eric Cole - National Institutes of Health

3
Agenda

• Available cloning methods
• Differences between methods
• Cloning Options available for each method
• Advanced Rapid Clone Options
• Future Cloning Options
• Rapid Clone Tips, tricks and lessons learned
• Case Study - 11i Cloning at NIH
• Custom cloning method
• Automated third party tools

4
How can I clone an Oracle Applications 11i System?

• Available methods
• Cloning using AD Clone utility (adclone.pl)
• Cloning using Rapid Clone
• Custom cloning methods
• Automated tools

5
What are differences between available cloning
methods?

• Cloning using adclone.pl method
• Applicable for all 11i releases up to 11.5.5 that
  are not AutoConfig enabled
• adclone.pl method requires that you run Rapid
  Install and apply RDBMS and Technology Stack
  patches to target system
• Cloning using Rapid Clone
• Applicable for all 11i systems that have migrated
  to AutoConfig and enabled Rapid Clone

6
Which cloning method is best for your environment?

• The best method depends on
• Version of applications
• Prior to version 11.5.7 (adclone.pl)
• Version 11.5.7 and higher (Rapid Clone)
• Version of Database
• 8i (adclone.pl and Rapid Clone)
• 9i (Rapid Clone only)

7
Future Cloning Options

• Fully automated RAC cloning with Rapid Clone
  (available now !!!!!)
• Cloning using Oracle Maintenance Wizard version
  1.10 and Applications Cloning Assistant for
  11.5.10 (planned to be released this summer)

8
What cloning options are available for each
method?
9
Advanced Rapid Clone Options

• Cloning a single-node to a multi-node system
• Cloning a multi-node system to a multi-node
  system
• Adding a new node to an existing system
• Cloning shared appl_top
• Cloning a multi-node to as single-node system
• Follow the procedure for Merging Existing
  APPL_TOPs doc id 233428.1
• Use Rapid Clone from OAM

10
Rapid Clone

• Advantages of Rapid Clone
• All Tech stack is copied unlike adclone
• Includes RDBMS, 8.0.6 and iAS
• Exact copy of Source Environment
• Able avoid re-applying tech stack patches
• Create new environment without running Rapid
  Install
• Disadvantage of Rapid Clone Numerous Steps, not
  a single program

11
Rapid Clone Tips - RMAN

• Cloning Oracle Applications Release 11i with
  Rapid Clone (doc 230672.1)
• Integration with RMAN
• Copy database tier file system (Section 2-Step
  2b)
• Copy rman files, Delay ORACLE_HOME copy
• Use RMAN, duplicate source DB
• Pre-create tempfile for TEMP tablespace
• Shutdown Target DB after RMAN complete
• Complete Step 2b, copy Source ORACLE_HOME
• Configure target system database server
  (Section 2-Step 3a)

12
Rapid Clone Tips - Patching

• Rapid Clone and AutoConfig tightly coupled
• Patches to either destabilize cloning
• Retest Clone method after patches to either
• Avoid patches to either unless time for testing
• We did not patch either for 1 year after 11.5.8
  upg
• After patches to either, build new target context
  file
• Do not reuse existing since usually new entries
• Use Port Pool logic when running adcfgclone.pl
• RDBMS context file rebuilt with adbldxml.sh

13
Rapid Clone Tips.

• RDBMS AutoConfig, Rapid Clone may/will clobber
  files
• init_ltsidgt.ora, tnsnames.ora, sqlnet.ora
• Avoid direct changes to AutoConfig generated
  files
• Take advantage of ifiles, not clobbered
• Give ifiles meaningful names in RDBMS context
  file
• init_ltsidgt_ifile.ora, tns_ltsidgt_ifile.ora

14
Rapid Clone Tips

• Check log files (some not documented)
• /tmp/adcfgclone, ORACLE_HOME/install/makelog
• Unset environment before run adcfgclone.pl
• Problems if point to Source by accident
• Call ltsidgt_ltboxgt.env instead of APPSORA.env
• Reuse Target context file (except after some
  patches)
• perl ./adcfgclone.pl dbTier ltcontext filenamegt
• perl ./adcfgclone.pl appsTier ltcontext filenamegt
• Develop detailed Rapid Clone cookbook

15
Case Study 11i Cloning at National Institutes
of Health

• Five year phased implementation
• Multiple, nightly clones (approximately 100/year)
• Automated/unattended cron scripts
• Releases 11.5.3 to 11.5.9
• Multiple servers, accounts, mountpoints, ports
• Multiple database environments (Oracle/Gelco)

16
Case Study 11i Cloning at National Institutes
of Health

• Environment Statistics
• Oracle E-Business Suite Release 11i - Production
• 550 Application Users
• 200 Database Users
• 225,000 Database Objects
• Total Environment Size 210 GB Disk Allocated,
  179 GB Used
• 125 GB Database
• 30 GB Application Code
• 9 GB Patches
• Nine Production and Production Support
  Environments (Production, Quality, Test,
  Training, Development, Sandbox, Patch, Year-end,
  Upgrade)
• Gelco Travel Manager 8.10
• 33,000 Traveler Users
• 2,700 Application Users (Planners, Reviewers,
  Approvers, Administrators, System Administrators,
  Super Users)
• 10 Database Users
• 3,900 Database Objects
• Total Environment Size 30 GB Disk Allocated,
  24 GB Used
• 14 GB Database Size
• 7 GB Application Code
• Nine Production and Production Support
  Environments (Production, Quality, Test,
  Training, Development, Sandbox, Patch, Year-end,
  Upgrade)

17
Case Study 11i Cloning at National Institutes
of Health

• Weekly cold backup using gtar/compress to
  separate disk mountpoint also used for disaster
  recovery
• Untar cold backup of source environment into
  ORACLE_BASE of target environment
• gtar zxvf ltsidgt_weekly_diskbackup.091304.gz
• Supply source and target environment information
• Hostname
• SID
• Starting port
• Post clone tasks
• Scramble privacy act data
• Remove old directories
• Implement customizations - WebADI
• AutoConfig enabled but not executed during clone
  process up through 11.5.9

18
Service Oriented Architecture
Service Oriented Architecture
19
Process Layer Part 1 of 2
Process Layer Part 1 of 2
20
Process Layer Part 2 of 2
Process Layer Part 2 of 2
21
Architecture
Oracle Applications 11i
RingMaster
Hot or cold Backup
Apache
PROD
SAN NAS STAGING
Real time Clone
Client IE Mozilla Netscape
SSH SCP FTP RCP Telnet
Backup based Clone
Tar Gzip Compress RMAN
TEST
NetApp EMC Hitachi
22
Cloning Prod to Test
Pre-clone steps
Data transfer (Threaded)
PROD
TEST
Post-clone steps
Single click Scheduling request
Reports
Automatic Audit Trail
Downtime, who, what, when?
23
Benefits

• Single click - Component complete
• Reduce time spent on cloning
• Clone more frequently
• SOX compliant (audit trail, reports)

24
Q A
25
Thank
You! Lynne Paulus - LynnePaulus_at_FairIsaac.com
John Stouffer jstouffer_at_solutionbeacon.com
James Lui - jlui_at_jlui.net Steve Noynaert -
snoynaert_at_ringmastersw.com Sandra Vucinic -
sandrav_at_vladgroup.com
