Title: Spacecraft Accommodation


1
Spacecraft Accommodation Resources
HMI00370A
  • Brock Carpenter
  • HMI System Engineering
  • Brock.A.Carpenter_at_LMCo.com
  • 650-424-2776

2
S/C Accommodations Resources Agenda
  • S/C Accommodations
  • Current Status
  • Interface Control Documents
  • HMI Resources
  • Mass
  • Power
  • Data Rates
  • Spacecraft Resources
  • ICD Development (Open Action Items)

3
S/C Accommodations Current Status
  • No major spacecraft compatibility issues with HMI
  • Spacecraft appears capable of providing
    sufficient critical resources volume, mass,
    power, stability, telemetry, and thermal
    fields-of-view
  • Updated Optics Package and Electronics Box
    designs need to be incorporated into the
    Interface Control Document
  • Electronics Box volume and mass have increased
    since the last interface working group
  • Optics Package volume has increased since the
    last interface working group
  • Informal technical exchanges show increases are
    acceptable
  • Mechanical interface control drawings being
    updated for presentation to SDO

4
S/C Accommodations S/C to HMI Interface
Control Document
  • HMI00241 Sections 01 02 Cover , Signatures,
    Introduction
  • HMI00243 Section 03 Mechanical
  • HMI00244 Section 04 Thermal
  • HMI00245 Section 05 Electrical
  • HMI00246 Section 06 CDH
  • HMI00247 Section 07 CDH Ops
  • HMI00248 Section 08 GNC
  • HMI00249 Section 09 Contamination
  • HMI00250 Section 10 Environments
  • HMI00251 Section 30 Mechanical Implementation
  • HMI00252 Section 40 Thermal Implementation
  • HMI00253 Section 50 Electrical Implementation
  • HMI00254 Section 60 CDH Implementation
  • HMI00255 Section 70 IT Implementation
  • HMI00235 SDO Electrical System Specification
  • HMI00285 SDO High-Speed Bus Interface Control
    Document (SpaceWire)

5
HMI Installation on the SDO Spacecraft
  • Thermal fields of view are sufficient for HMI.
  • Radiators for the CCDs on the optics package have
    unobstructed view of deep space
  • Camera electronics boxes require radiator
    extensions
  • Main electronics box mounted on radiator which
    has nearly unobstructed view of deep space

HMI Optics Pkg.
HMI Electronics Box
6
Optics Package Envelope
  • Envelope Dimensions
  • Overall 47" x 32.5" x 11.3"
  • MLI, not shown, adds ½ inch to overall length
  • For reference, X-Y rectangle encompassing
    mounting bolts/pins on the Inst. Module 34.5" x
    31.9"
  • For reference, main box dimensions 33" x 21.5"
    x 6.3"
  • Critical dimensions are controlled by the HMI
    Mechanical Interface Drawing, 2H00019

7
HMI Electronics Box Envelope
8
HMI Resources - Mass
  • Notes
  • Margin for HMI exceeds the recommended 25 for
    PDR considering the S/C is holding 20 margin
  • Mass Estimates from Nov. 2003 HMI Mass Summary
    Report - HMI00157H
  • Harness Mass based on 4 meter maximum length
  • Harness shielding requirements still being worked

9
HMI Resources - Average Power
  • Notes
  • Margin for HMI exceeds the recommended 25 for
    PDR considering the S/C is holding 20 margin
  • Power Estimates from Nov. 2003 HMI Power Report -
    HMI00158G

10
HMI Resources Data Rates
  • Science 1355 High-Speed Bus - SpaceWire
  • Allocation of 55 Mbps is sufficient for HMI
  • Compression will be tailored to fully utilize the
    available link
  • Housekeeping 1553 Bus
  • Nominal rate allocation of 2 kbps is sufficient
    for HMI
  • Based on MDI and current preliminary telemetry
    list by using several packet types each with its
    own application identifier (APID). Expect to
    produce one Health Safety packet every 4
    seconds, one Image ID packet every 2 seconds and
    fill in remainder 2 slots every 8 seconds with
    diagnostic data, memory dumps, command summary,
    etc.
  • Reduced rate allocation of 1 kbps is sufficient
    for HMI
  • S/C will filter nominal rate based upon APID
  • Critical (emergency) rate allocation of 100 bps
    is sufficient for HMI
  • S/C will filter nominal rate based upon APID
  • Command Uplink
  • Allocation of 2 kbps is sufficient for HMI
  • Expectation is to send a few commands each day

11
Spacecraft Resources
  • Spacecraft Pointing Stability
  • The spacecraft shall maintain the HMI reference
    boresight to within 200 arc-seconds of sun
    center.
  • The spacecraft shall maintain the HMI roll
    reference to within 100 arc-seconds of the
    projection of solar North onto the plane of the
    sky .
  • The spacecraft shall maintain drift between the
    spacecraft and HMI reference boresights to within
    14 arc-seconds in the pitch and roll (Y Z) axes
    over a period not less than one week.
  • The spacecraft jitter at the HMI mounting
    interface to the optical bench shall be less than
    5 arcsec (3 sigma) in the pitch, yaw, and roll
    (X, Y, Z) axes. (Frequency content is under
    study.)
  • Spacecraft Thermal Environment
  • The HMI Optics Package shall be thermally
    isolated from the spacecraft to allow independent
    thermal control.
  • The spacecraft shall provide a sink temperature
    sufficient to maintain the HMI CCD at
    temperatures less than -70 C.
  • Spacecraft Off-point Roll Capability
  • The spacecraft shall be capable of 360 rolls
    while maintaining accurate sun pointing.
  • The spacecraft shall be capable of off-points up
    to 12 arc-minutes from disk center while
    maintaining nominal jitter performance.

12
HMI ICD Open Action Items (1 of 2)
  • M11 Comment on request to have Optics-Package
    mass simulator compatible with thermal/vac
    environments
  • M12 Review SDO tolerance of Optics-Package
    mounting foot pin-to-pin tolerances on
    Instrument Module
  • E2 Review SDO design that power-on transient to
    be controlled by SSPC switches in subsystem
    power nodes (SPNs)
  • E11 Review requirement that the harnesses to the
    survival heaters/sensors will be provided by
    GSFC
  • E13 Review CCD decontam heater relay-circuit
    requirement for Elect. Box
  • E14 Review clarifications in Draft 3 of
    Electrical Section (5) of the ICD
  • E15 Review voltage-rise time plot in section 5 of
    the ICD
  • E17 Review documentation of requirement that
    Instruments must survive hard shut down
  • C3 Review SDO decision to not provide S/C
    housekeeping parameters for inclusion in the
    HMI high-speed data stream.

13
HMI ICD Open Action Items (2 of 2)
  • C8 Review SDO decision to not provide S/C
    pointing data for inclusion in the HMI
    high-speed data stream.
  • C11 Comment on SDO method of using two 1553
    channels to provide HMI with 2 polls/second
  • C12 Comment on SDO clarification of data rate
    switching w/o notification
  • C13 Review addition of a time jammed flag to
    the time tone message
  • GC6 Determine whether degraded calibration
    accuracy is acceptable in the event of S/C
    wheel failures.
  • GC8 HMI to provide an updated table of HMI
    mechanism characteristics for S/C jitter
    analysis
  • CT2 Review Draft 3 of Contam. Section (9) of the
    ICD incorporating HMI input
  • EN1 Review Draft 3 of Environments Section (10)
    to include only test environments, not radiation
    environments
  • G3 Review clarification of location of fault
    tolerance requirements in documentation
    (regarding heater fault tolerance)
