Plate Tectonics

1
Plate Tectonics

• Rearranging Earths Surface

2
Tectonic Processes

• GOAL To understand the processes behind the
  distribution of Earths continents and oceans

3
Tectonic Processes

• Alfred Wegener and how a scientific paradigm
  operates
• Structure of Earth allows continents to move
• Types of Plate Interactions
• Divergence
• Convergence
• Transform
• 4. Hot Spots

4
1. Alfred Wegener and how a scientific paradigm
operates
"Scientists still do not appear to understand
sufficiently that all earth sciences must
contribute evidence toward unveiling the state of
our planet in earlier times, and that the truth
of the matter can only be reached by combing all
this evidence. . . It is only by combing the
information furnished by all the earth sciences
that we can hope to determine 'truth' here, that
is to say, to find the picture that sets out all
the known facts in the best arrangement and that
therefore has the highest degree of probability.
Further, we have to be prepared always for the
possibility that each new discovery, no matter
what science furnishes it, may modify the
conclusions we draw." Alfred Wegener. The Origins
of Continents and Oceans (4th edition)
5
Field work Atlantic once closed
6
Shape MatchRocks MatchFossils MatchLifetime of
work
7
Theory of Continental Drift

• Meteorologist proposes
• to change geology

1st edition 1915
8
Earlier, Sir Francis Bacon

• Wondered about similar shape of South America and
  Africa coastline

9
Until 1960s Utter Rejection by Geologists
Dr. Rollin T. Chamberlin of the University of
Chicago said, "Wegener's hypothesis in general is
of the footloose type, in that it takes
considerable liberty with our globe, and is less
bound by restrictions or tied down by awkward,
ugly facts than most of its rival theories."
American Association of Petroleum Geologists
organized a symposium specifically in opposition
to the continental drift hypothesis.
"Utter, damned rot!" W.B. Scott, President of
the American Philosophical Society
10
Today We Map Tectonic Plates
11
Classroom Resources Folder
Today We Accept that most Earthquakes and
Volcanoes occur along boundaries of Tectonic
Plates
12
Today We Accept Plate Movement
13
Today We Accept Pangaeaand its breakup
14
Resources
Pangaea Breakup

• Earth in the Future

Animation of Drift Over Time
15
Online Video Presentations
16
Why the opposition shift?

• An example of how a discipline can get locked
  into a pathway of mental thinking for decades
  (paradigm), rejecting the idea of moving
  continents.
• An example of how a discipline protects its
  turf rejecting the thoughts of a
  meteorologist.
• Enough time for the opponents to die, and a bunch
  of new geologists in the 1960s to challenge the
  establishment.
• Reminder throughout this class that ideas shift
  and much depends on the mental framework of the
  scientist

17
2. Structure of Earth allows continents to move

• Wegener could not answer a fundamental question
  of HOW continents could move.

But geology advanced to the point to begin to
understand Earths internal structure how it
allows continental drift
18
Structure and Internal Energy

• Knowledge of Earths Interior is incomplete
  weve only explored about 1/1000 of Earths
  radius
• Inferential knowledge through monitoring of
  shockwaves transmitted through Earth from
  earthquakes or human-made explosions
• Four main zones of the Earths Interior
• Earths Core Deepest part of the Earth
• Inner Core supposedly solid, dense (iron/nickel
  or iron/silicate
• Outer Core (molten) liquid shell beneath the
  mantle that encloses the inner core

19
Structure and Internal Energy (cont.)

• Earth in Cross Section
• 3. Earths Mantle Surrounds the outer core,
  largest of all four shells believe 3 zones
  within mantle
• Lithosphere uppermost zone of mantle crust
  together
• Asthenosphere plastic layer below lithosphere
• Mesosphere rigid part of mantle below
  asthenosphere
• 4. Earths Crust outermost layer mixed rock
  types
• Mohorovicic discontinuity (Moho) boundary
  between earths crust mantle

20
Earth in Cross Section
21
(No Transcript)
22
Earths Interior
23
Earths Interior
24
Core to Crust
25
Earths Structure
26
Brittle Crust Floats on Flowing Asthenosphere
27
Different Crusts 5/6th submerged(isostatic
balance)

• Ocean Crust Continental Crust
• Dense (sima) Lighter (sial)


28
ISOSTACYCrust adjusts to create a balance
(equilibrium)
29
Human Induced Change
30
2 continental plates under Tibet

• To reach isostatic
• balance, Tibet
• Plateau
• rises

Too thick, so get uplift
31
Effects Of Erosion on Isostacy
32
Earth oozes at different rates

• Asthenosphere flows

Even the crust adjusts
33
Reason for Movement

• Excess heat from radioactive decay creates liquid
  outer core (and magnetic field), and forces
  mantle to have convection

34
Exactly how mantle moves?

• ASU view

35
Classroom Resources

• Animation of a theoretical model showing sinking
  crust and rising hot plumes all in the mantle

36
3. TYPES OF PLATE INTERACTION

• Stream Systems on
• Dynamic Earth

37
3. Type of Plate Interactionsa. Divergent
Boundaries

• Mid-ocean
• ridges are
• places of
• plate divergence

38
Mid-Atlantic Ridge is the Icon
39

• Mid
• Atlantic
• Ridge

• East
• Pacific
• Rise

• Mid Indian
• Ridge

40
Why a ridge? Why not a Valley?

• Heat makes the large structure rise up, but at
  the axis there is a rift valley from spreading

41
Sea Floor Spreading Key to Rejecting the Old Ways

• Plate Tectonics continental drift sea-floor
  spreading
• Rename the theory with new evidence
• Potassium-Argon dating
• Paleomagnetism

42
Potassium - Argon Dating

• Discovery middle of ocean ridges youngest

43

• Millions of years before present

44
Classroom Resources

• Animation showing ages of ocean crust getting
  older away from spreading

45
Paleomagnetism
46
Classroom Resources

• Visualizing reversals of magnetic field and how
  this creates a mirror image on the two sides of a
  spreading center

47

• Lava has minerals that record the magnetic field

48
Paleomagnetism in Symmetry

• Conclusion
• was that
• Sea floors
• Spreading
• apart

49
Source for Latest Info

• Website

50
Continents can also spread

• Atlantic Opened up

Africa is Rifting
51
Obvious question with making new sea floor, why
isnt Earth expanding?

• Old ocean plates undergo subduction

52
3. Type of Plate Interactionsb. Convergent
Boundaries
53
Oceanic-Continental Convergence

• Denser Oceanic Crust Subducts
• Trench Forms
• Volcanoes Form
• Lithosphere Subducts Into Asthenosphere
• Earthquakes Common All Along Boundary

54
Andes
Cartoon

• Nazca plate collide with South American Plate

Recent Research from Nature
55
Classroom Resources

• Visualizations about the Andes Mtns as from
  Convergence of Ocean Continental Plates

56

• From the East-Pacific Rise, the Pacific plate
  moves towards subduction in the Aleutian Trench

57

• Ocean-Cont.
• Convergence
• in Pacific
• Northwest

58
Island Arcs from Ocean-Ocean Convergence
59
Convergence of 2 continental plates

• Example of Himalaya

60
Classroom Resources

• Animations of Himalaya Formation

61
Formation of Appalachian Mountains resulted from
the collision of the African and European Plates
with North American Plate prior to 300 million
years ago.
62
Ural Mountains
Formation of the Ural Mountains related to
collision tectonics prior to 300 Mya ago.
63
Convergence Tsunami
64
Effects Of Plate Locking
65
EQ (or landslide or volcanic eruption) movement
generates the wave that travels about 500 mph
66
Classroom Resources

• Shows how Tsunami can be made from subduction

Shows time sequence in Tsunami destroying coastal
city in Alaska
67
Animated gif
68
Mega-Quake Set off 2004 Tsunami will happen
again

• Energy ripple

69
Sri Lanka
Sumatra Uplift
70
Indonesia
71
Indonesia
72
Has Happened, Will Happen Again
In Classroom Resources Folder, Animation of Chile
EQ generating Tsunami that destroyed Hilo in 1960

• Hilo, 1960

73
3. Type of Plate Interactionsc. Transform
Boundaries

• Side-by-side motion
• along San Andreas zone

74
Transform motion of the San Andreas Fault can be
seen by offset of streams that cross the fault
zone.
75
California Wont Fall into the Ocean

• Continent is 5/6ths submerged, so it is anchored
  very tight

76
Classroom Resource

• Animation showing how there used to be
  convergence along the California coast, but it
  turned into a transform boundary

Animation of San Francisco Peninsula Topography
shows the gash of the San Andreas fault zone
77
Other Transform Boundaries
78
(No Transcript)
79
4. Hot Spots
Focus here on Hawaii
Often in the middle of a plate
80
Hawaiian Hotspot
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
Classroom Resources

• Animation of Hawaii as moves over Hot Spot

86
Trail of the Hot Spot

• Note change in direction 43 myr ago

Change in direction 43 myr ago
87
Alternative Hypothesis
88
Online Visualizations

• Tsunami Visualizations
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/collections/tsunami.html
• Plate Tectonic Movement Visualizations
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/PTMovements.html
• Isostacy
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/collections/IsoGrav.html
• Mountain Uplift
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/collections/mouneros.html
• Earth History
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/collections/geotime.html
• Mountain Building
• http//serc.carleton.edu/NAGTWorkshops/visualizati
  on/collections/orogeny.html
