Information Technology Fundamentals (ITF)

1
Information Technology Fundamentals (ITF)

• Mr. Shultz

2
Todays Objective(s) and Bell-Ringer

• Objective
• Given a computer, TSW correctly locate and
  describe the characteristics and functions of
  video, sound, network, and RAM cards with no
  errors. (BUS6670.048)
• Bell-Ringer Questions
• What is the first thing you should do before
  working in a computer?
• What is the second thing?
• How do you know which way to plug in the power
  cables?

3
Bell-Ringer

• What is the first thing you should do before
  working in a computer?
• Remove all rings, bracelets, watches, long
  necklaces, etc.

4
Bell-Ringer

• What is the second thing?
• Put on anti-static wrist band
• Adjust if necessary
• Attach to bare metal

5
Bell-Ringer

• How do you know which way to plug in the power
  cables?
• Beveled edge up

6
Look at the beveled corners on the power connector
7
Bell-Ringer

• Only fits one way!
• NEVER force a connector in a computer!

8
Testing

• This information may be on tests

9
Safety!!!!!

• Keep copy of Safety handout in front of notebook
• Take your time!
• Cut Procedures
• Notify me right away

10
Safety!!!!!

• Remove all rings, bracelets, watches, long
  necklaces, etc.
• Put on anti-static wrist strap
• Adjust strap if too loose
• Connect to bare metal when working in the computer

11

• Unscrew two screws
• Slide cover off

12
Keep the screws on the cover so you dont lose
them
13

• Take a look around the inside
• Do you know any parts?

14
Remove the screw on the first card
Remove the cable from the first card
15
Sound Card

• What does the Sound Card do?
• Put the sound card and screw on the cover

16
Remove the screw on the second card
17
NIC Network Interface Card

• What does the NIC do?
• Put the NIC and screw on the cover

18
Remove the screw on the third card
19
Video Card

• What does the Video Card do?
• Put the Video Card and screw on the cover

20
Look at the connectors on the motherboard
VGP
PCI
ISA
21
Look at the RAM slots
22
Push the clips back and remove the RAM
23
Notice that the RAM will only go in the slot one
way
24
Replace the RAM but DO NOT touch the clips. Each
person take a turn removing and replacing
25
Look at the Hard Drive
26
Remove the power connector
27
Remove the data cable
28
Look at the data cable there is a notch on one
side
29
Look at the beveled corners on the power connector
30
Inside the Computer

• Re-connect in reverse order
• Hard Drive
• Video Card
• NIC
• Sound Card

31
Virtual Tour Assignment

• Go to ITF page
• Open Click-N-Learn web page
• Answer questions on Virtual Tour worksheet

32
ESD Assignment

• If not completed
• Go to ITF page
• Read all four pages of the ESD web page
• Complete the ESD Review
• Use the web page as a reference while answering
  the review questions

33
Information Technology Fundamentals (ITF)
