Hamiltonian Cycles in Triangular Grids

1
Hamiltonian Cycles in Triangular Grids

• Valentin Polishchuk
• joint work with
• Estie Arkin and Joseph Mitchell

Applied Math and Statistics Stony Brook University
2
Grids
3
Grids, grids
4
Grids, grids, grids
5
Square Grid Graph

• Subset S of Z2
• vertices S
• edge (i,j) if Si Sj 1
• Solid grid
• no holes
• all bounded faces unit squares

6
Hamiltonicity of Square Grids

• NP-compete in general Itai, Papadimitriou,
  and Szwarcfiter 82
• even if max deg 3 Papadimitriou and
  Vazirani 84, Buro 03
• Solid grids
• polynomial Umans and Lenhart 96
• short covering tour Arkin, Fekete, Mitchell
  92
• length (6/5)N
• linear time

7
Tilings

• Square grid
• unit squares

8
Tilings

• Square grid
• unit squares

• Triangular grid
• unit equilateral triangles

9
Triangular Grid Graph

• Subset S
• vertices S
• edge (i,j) if
• Si Sj 1

10
Solid Triangular Grid

• No holes
• all bounded faces
• unit equilateral triangles

11
Grids
12
Grids, grids
13
Hamiltonicity of Grids
14
Previous Work

• Other triangulations
• Dillencourt 92, Arkin, Held, Mitchell, Skiena
  96, Cimikowski 90, 93, Dogrusoz and
  Krishnamoorthy 95, Flatland 04
• Long cycles through faces
• stripification Bushan, Diaz-Gutierrez,
  Eppstein, Gopi 04,06
• possible subdivision
• relaxed notion of Hamiltonicity
• Demaine, Eppstein, Erickson, Hart, O'Rourke 01
• Hamiltonian cycle through vertices?

15
Our Contribution

• NP-compete in general
• even if max deg 4
• Solid triangular grids
• polynomial
• cut-free Hamiltonian
• not the Star of David
• linear-time to find a cycle
• linear-time solution to TSP

16
NP-Completeness Results
17
The Reduction

• Same idea as for square grids
• Itai, Papadimitriou, and Szwarcfiter 82,
  Papadimitriou and Vazirani 84
• Hamiltonian Cycle
• undirected planar bipartite graphs
• max deg 3
• G0

Embed 0o, 60o, 120o segments
18
The Node Gadget
19
The Tentacles
20
Connection to a White Node
21
Connection to a Black Node
22
Traversing Tentacles

• Black node-tentacle connection
• a cut

Return path Cross path returns to
white node connects white and black nodes
23
HC in G HC in G0

• Any node gadget
• adjacent to 2 cross paths

Return path Cross path

• Edges of G0 in HC
• Cross paths
• Edges of G0 not in HC
• Return paths from white nodes

24
Max degree 4 Grids

• No degree-6 vertices
• Degree-5 vertices

Modified gadgets
25
Almost AllSolid Grids are Hamiltonian
26
Assumption

• No cut vertex
• removal disconnects G
• WLOG
• o.w. no cycle

27
Boundary

• deg lt 6 vertices
• Internal vertices
• deg-6 vertices
• No cut vertex
• cycle B around the boundary
• visits every bd vertex once

28
Idea

• B cycle around the boundary
• Local modifications
• attach to B internal vertices
• cost 1 per vertex

29
L-modification
30
V-modification
31
Z-modification
32
Priority L , V , Z

• L
• V
• Z

33
Wedges

• Sharp
• 60o turn
• Wide
• 120o turn

34
The Main Lemma

• Until
• B passes through ALL internal vertices
• either L, V, or Z may be applied
• small print
• unless G is the Star of David

35
Internal vertex v not in B

• A neighbor u is in B
• Crossed edges
• not in B
• o.w. apply L

36
How is u visited?

• WLOG, 1 is in B

37
s is in B
L cannot be applied
How is s visited?
38
Sharp Wedge
s
V

• Z

s
39
Wide Wedge

• L cannot be applied t is in B

40
Deja Vu

• Rhombus
• edge of B
• vertex not in B
• vertex in B

• Unless
• t is a wide wedge
• modification!
• welcome new vertex to B

41
Another Wide Wedge

• Yet Another vertex
• Yet Another rhombus

Yet Another wide wedge
42
And so on

• Star of David!

43
Summary

• Triangular grids
• solid
• Hamiltonian Cycle Problem
• NP-compete even if max deg 4
• Solid triangular grids
• cut-free Hamiltonian
• not the Star of David
• linear-time to find a cycle
• linear-time solution to TSP
• Topological proof

44
Extensions

• Grids with holes
• no local cut
• Manifolds (meshes)
• some assumptions

45
Open

• Max degree 3
• Hexagonal grids

Thank you!
