VEX Grippers (Devices that can attach to objects)

1
VEX Grippers(Devices that can attach to objects)
2
Outline

• Gripper Theory
• Control
• Speed
• Common Types of Grippers
• Servo Grip
• Motorized Grip
• Pneumatic Grip
• Roller Grip
• Challenge
• Hints
• Use Lock Bars to attach devices to axles
• Use an Ultrasonic Ranger to find objects

Vex Labs Gridiron Robot
3
Control

• Holy grail of gripping
• Get object fast
• Hang on
• Let go quickly
• This must be done under excellent control
• Limit switches
• Auto-functions
• Ease of operation

4
Speed

• Quickness covers mistakes
• Quick to grab
• Drop re-grab
• Fast
• Servo gripper
• Pneumatic gripper
• Not fast
• Roller gripper
• Motor gripper

5
Servo Grip

• Precise
• Limited range of motion
• Limited torque

Roberts ARL robot in 2006
6
Motorized Grip

• Can be geared for speed or torque
• More complex

FVC Team 31 in 2005
7
Pneumatic Grip

• Powerful
• Reliable
• Requires entire (unreliable) pneumatics system

Some robot
8
Roller Grip

• Slow
• Allows for misalignment when grabbing
• Wont let go
• Extends object as releasing
• Simple mechanism

FVC Team 34 in 2005
9
Gripper Challenge
10
Lock-Bars

• Axles fit through the square holes.
• Bolts fit through the round holes.

• Lock-bars allow for any component to be attached
  to an axle and rotated by a motor or servo.

11
Ultrasonic Range Finder

• Detect the distance to the nearest object or wall
• Bounces sound waves off of objects and measures
  the time it takes sound waves to return
• The time can be used to calculate distances from
  3 cm to 3 m

12
Thanks/Resources

• Designing Competitive Manipulators The Mechanics
  Strategy
• by Greg Needel (www.robogreg.com)
