Title: Guide to Computer Forensics and Investigations Fourth Edition


1
Guide to Computer Forensics and
InvestigationsFourth Edition
  • Chapter 8
  • Macintosh and Linux Boot Processes and File
    Systems

2
Objectives
  • Explain Macintosh file structures and the boot
    process
  • Explain UNIX and Linux disk structures and boot
    processes
  • Describe other disk structures

3
Understanding the Macintosh File Structure and
Boot Process
  • Mac OS X version 10.4
  • Darwin core
  • BSD UNIX application layer
  • Hierarchical File System (HFS)
  • Files stored in nested directories (folders)
  • Extended Format File System (HFS)
  • Introduced with Mac OS 8.1
  • Supports smaller file sizes on larger volumes,
    resulting in more efficient disk use

4
Understanding the Macintosh File Structure and
Boot Process (continued)
  • File Manager utility
  • Reading, writing, and storing data to physical
    media
  • Finder
  • Keeps track of files and maintain users desktops
  • In older Mac OSs, a file consists of two parts
  • Data fork and resource fork
  • Stores file metadata and application information

5
(No Transcript)
6
Understanding Macintosh OS 9 Volumes
  • A volume is any storage medium used to store
    files
  • Can be all or part of a hard disk
  • On a floppy disk is always the entire disk
  • Allocation and logical blocks
  • Logical blocks cannot exceed 512 bytes
  • Allocation blocks are a set of consecutive
    logical blocks

7
Understanding Macintosh OS 9 Volumes (continued)
8
Understanding Macintosh OS 9 Volumes (continued)
  • Two EOF descriptors
  • Logical EOF
  • Actual size of the file
  • Physical EOF
  • The number of allocation blocks for that file
  • Clumps
  • Groups of contiguous allocation blocks
  • Reduce fragmentation

9
Understanding Macintosh OS 9 Volumes (continued)
10
Exploring Macintosh Boot Tasks
  • Use Open Firmware
  • Processor- and system-independent firmware
  • Controls microprocessor after hardware
    initialization
  • The boot process for OS 9 is as follows
  • 1. Power on the computer
  • 2. Hardware self-test and Open Firmware run
  • 3. Macintosh OS starts
  • 4. The startup disk is located
  • 5. System files are opened

11
Exploring Macintosh Boot Tasks (continued)
  • The boot process for OS 9 (continued)
  • 6. System extensions are loaded
  • 7. OS 9 Finder starts
  • Tables 8-1 and 8-2 are an overview of how HFS and
    HFS system files handle data

12
(No Transcript)
13
(No Transcript)
14
Exploring Macintosh Boot Tasks (continued)
  • Older Macintosh OSs use
  • First two logical blocks as boot blocks
  • Master Directory Block (MDB) or Volume
    Information Block (VIB)
  • Stores all information about a volume
  • Volume Control Block (VCB)
  • Stores information from the MDB when OS mounts
  • Extents overflow file
  • Stores any file information not in the MDB or a
    VCB

15
Exploring Macintosh Boot Tasks (continued)
  • Catalog
  • Listing of all files and directories on the
    volume
  • Maintains relationships between files and
    directories
  • Volume Bitmap
  • Tracks used and unused blocks on a volume
  • Mac OS 9 uses the B-tree file system for File
    Manager
  • Actual file data is stored on the leaf nodes
  • B-tree also uses header, index, and map nodes

16
Using Macintosh Forensic Software
  • Tools and vendors
  • BlackBag Technologies
  • SubRosaSoft MacForensicsLab
  • Guidance EnCase
  • X-Ways Forensics
  • ProDiscover Forensic Edition
  • Sleuth Kit and Autopsy

17
Using Macintosh Forensic Software (continued)
  • Macintosh Acquisition Methods
  • Make an image of the drive
  • Static acquisition of the suspect drive is
    preferable to a live acquisition
  • Removing the drive from a Macintosh Minis CPU
    case is difficult
  • Attempting to do so without Apple factory
    training could damage the computer
  • Use a Macintosh-compatible forensic boot CD to
    make an image

18
Using Macintosh Forensic Software (continued)
  • Macintosh Acquisition Methods (continued)
  • BlackBag Technologies sells acquisition products
    specifically designed for OS 9 and earlier
  • As well as OS X
  • MacQuisition is a forensic boot CD that makes an
    image of a Macintosh drive
  • After making an acquisition, examine the image of
    the file system
  • The tool you use depends on the image file format

19
Using Macintosh Forensic Software (continued)
  • Macintosh Acquisition Methods (continued)
  • BlackBag Technologies Macintosh Forensic Software
    and SubRosaSoft MacForensicsLab
  • Can disable/enable Disk Arbitration
  • Being able to turn off the mount function in OS X
  • Allows you to connect a suspect drive to a
    Macintosh without a write-blocking device

20
Using Macintosh Forensic Software (continued)
  • Examining OS 9 Data Structures with BlackBag
  • Activities in this section assume you have a
    Macintosh running OS X
  • All data acquisitions (image files) must be
    configured as Disk Images
  • With the correct filename and extensions
  • To keep the correct order of each segment
  • Numbers need to be inserted between the filename
    and the extension
  • See Table 8-3

21
Using Macintosh Forensic Software (continued)
22
Using Macintosh Forensic Software (continued)
  • Examining OS 9 Data Structures with BlackBag
    (continued)
  • Load images as a virtual disk image
    double-clicking the files in Finder
  • See Figure 8-4
  • OS X loads and displays an icon of the virtual
    mounted disk with the name untitled on the
    desktop
  • You can rename it with your case name
  • See Figure 8-5

23
Using Macintosh Forensic Software (continued)
24
(No Transcript)
25
Using Macintosh Forensic Software (continued)
  • Examining OS 9 Data Structures with BlackBag
    (continued)
  • Start BlackBag from Finder
  • See Figure 8-6
  • BlackBag includes several utilities for
    conducting a full analysis of evidence, including
  • PDISKInfo, PMAPInfo, DirectoryScan, FileSearch,
    MacCarver, and FileSpy

26
(No Transcript)
27
Using Macintosh Forensic Software (continued)
  • Examining OS 9 Data Structures with BlackBag
    (continued)
  • Activity 1
  • Use the BlackBag DirectoryScan utility, which
    lists all folders and files, visible and hidden,
    in the image loaded as a .dmg file
  • See Figure 8-8
  • Activity 2
  • Use the FileSearcher utility to locate files by a
    specific extension
  • See Figure 8-9

28
Using Macintosh Forensic Software (continued)
29
(No Transcript)
30
Examining UNIX and Linux Disk Structures and Boot
Processes
  • UNIX flavors
  • System V variants, Sun Solaris, IBM AIX, and
    HP-UX
  • BSD, FreeBSD, OpenBSD, and NetBSD
  • Linux distributions
  • Red Hat, Fedora, Ubuntu, and Debian
  • Most consistent UNIX-like OSs
  • Linux kernel is regulated under the GNU General
    Public License (GPL) agreement

31
Examining UNIX and Linux Disk Structures and Boot
Processes (continued)
  • BSD license is similar to the GPL
  • But makes no requirements for derivative works
  • Some useful Linux commands to find information
    about your Linux system
  • uname a
  • ls l
  • ls ul filename
  • netstat -s

32
(No Transcript)
33
(No Transcript)
34
Examining UNIX and Linux Disk Structures and Boot
Processes (continued)
  • Linux file systems
  • Second Extended File System (Ext2fs)
  • Ext3fs, journaling version of Ext2fs
  • Employs inodes
  • Contain information about each file or directory
  • Pointer to other inodes or blocks
  • Keep internal link count
  • Deleted inodes have count value 0

35
UNIX and Linux Overview
  • Everything is a file
  • Files are objects with properties and methods
  • UNIX consists of four components
  • Boot block
  • Block is a disk allocation unit of at least 512
    bytes
  • Contains the bootstrap code
  • UNIX/Linux computer has only one boot block,
    located on the main hard disk

36
UNIX and Linux Overview (continued)
  • Superblock
  • Indicates disk geometry, available space, and
    location of the first inode
  • Manages the file system
  • Inode blocks
  • First data after the superblock
  • Assigned to every file allocation unit
  • Data blocks
  • Where directories and files are stored
  • This location is linked directly to inodes

37
UNIX and Linux Overview (continued)
38
UNIX and Linux Overview (continued)
  • Bad block inode
  • Keeps track of disks bad sectors
  • Commands badblocks, mke2fs, and e2fsck/
  • Linux ls command displays information about files
    and directories
  • Continuation inode
  • Provides information about a file or directory
  • Mode and file type, the quantity of links in the
    file or directory, the file or directory status
    flag

39
UNIX and Linux Overview (continued)
40
UNIX and Linux Overview (continued)
41
Understanding Inodes
  • Link data stored in data blocks
  • Ext2fs and Ext3fs are improvements over Ext
  • Data recovery easier on Ext3fs than on Ext2fs
  • First inode has 13 pointers
  • Pointers 1 to 10 are direct pointers to data
    storage blocks
  • Pointer 11 is an indirect pointer
  • Pointer 12 is a double-indirect pointer
  • Pointer 13 is a triple-indirect pointer

42
(No Transcript)
43
Understanding Inodes (continued)
44
Understanding UNIX and Linux Boot Processes
  • Instruction code in firmware is loaded into RAM
  • Instruction code then
  • Checks the hardware
  • Load the boot program
  • Boot program
  • Loads kernel
  • Transfers control to kernel
  • Kernels first task is to identify all devices

45
Understanding UNIX and Linux Boot Processes
(continued)
  • Kernel
  • Boots system on single-user mode
  • Runs startup scripts
  • Changes to multiuser mode
  • Identifies root directory, swap, and dump files
  • Sets hostname and time zone
  • Runs consistency checks on the file system and
    mounts partitions
  • Starts services and sets up the NIC
  • Establishes user and system accounting and quotas

46
Understanding Linux Loader and GRUB
  • Linux Loader (LILO)
  • Old boot manager
  • Can start two or more OSs
  • Uses configuration file Lilo.conf
  • Grand Unified Boot Loader (GRUB)
  • More powerful than LILO
  • As LILO, it resides on MBR
  • Command line or menu driven

47
Understanding UNIX and Linux Drives and Partition
Schemes
  • Labeled as path starting at root (/) directory
  • Primary master disk (/dev/had)
  • First partition is /dev/hda1
  • Second partition is /dev/hda2
  • Primary slave or secondary master or slave
    (/dev/hdb)
  • First partition is /dev/hdb2
  • SCSI controllers
  • /dev/sda with first partition /dev/sda1
  • Linux treats SATA, USB, and FireWire devices the
    same way as SCSI devices

48
Examining UNIX and Linux Disk Structures
  • Most commercial computer forensics tools can
    analyze UNIX UFS and UFS2
  • And Linux Ext2, Ext3, ReiserFS, and Reiser4 file
    systems
  • Freeware tools include Sleuth Kit and its Web
    browser interface, Autopsy Browser
  • Foremost
  • A freeware carving tool that can read many image
    file formats
  • Configuration file foremost.conf

49
Examining UNIX and Linux Disk Structures
(continued)
  • Tarball
  • A data file containing one or more files or whole
    directories and their contents
  • Installing Sleuth Kit and Autopsy
  • Requires downloading and installing the most
    recent updates of these tools
  • Download the most current source code from
    www.sleuthkit.org
  • To run Sleuth Kit and Autopsy Browser, you need
    to have root privileges

50
Examining UNIX and Linux Disk Structures
(continued)
51
(No Transcript)
52
Examining UNIX and Linux Disk Structures
(continued)
  • Examining a case with Sleuth Kit and Autopsy
  • Use Sleuth Kit and Autopsy Browser to analyze a
    Linux Ext2 and Ext3 file system
  • See Figures 8-15 through 8-18

53
Examining UNIX and Linux Disk Structures
(continued)
54
Examining UNIX and Linux Disk Structures
(continued)
55
Examining UNIX and Linux Disk Structures
(continued)
56
(No Transcript)
57
Examining UNIX and Linux Disk Structures
(continued)
  • Examining a case with Sleuth Kit and Autopsy
    (continued)
  • Use the File Activity Time Lines function
  • Identifies what files were active at a specific
    time
  • See Figures 8-19 and 8-20

58
Examining UNIX and Linux Disk Structures
(continued)
59
Examining UNIX and Linux Disk Structures
(continued)
60
Understanding Other Disk Structures
  • SCSI disks
  • IDE/EIDE disks
  • SATA drives

61
Examining CD Data Structures
  • Laser burns flat areas (lands)
  • Lower areas are called pits
  • Transitions
  • From lands to pits have binary value 1 (on)
  • No transition has binary value 0 (off)
  • International Organization of Standards (ISO)
  • ISO 9660 for CD, CD-R and CD-RW
  • ISO 13346 for DVDs

62
(No Transcript)
63
Examining CD Data Structures (continued)
64
Examining CD Data Structures (continued)
  • Frame is the unit storage
  • Contains 24 17-bits symbols
  • Frames are combined into blocks
  • Blocks are combined into sectors
  • 2352 bytes for CD-DA
  • 2048 bytes for CD
  • Constant Linear Velocity (lt 12X)
  • Constant Angular Velocity (gt 12X)

65
Examining CD Data Structures (continued)
  • DVD disk file structures use a Universal Disk
    Format (UDF)
  • Called Micro-UDF (M-UDF)
  • For backward compatibility, some DVDs have
    integrated ISO 9660
  • To allow compatibility with current OSs

66
Examining SCSI Disks
  • Small Computer System Interface (SCSI)
  • Provides a common bus communication device
  • During investigation
  • Check if the device is internal or external
  • Check if card, cables, adapters, terminators, and
    drivers are available
  • Advance SCSI Programming Interface (ASPI)
  • Provides several software drivers for
    communication between the OS and SCSI component

67
Examining SCSI Disks (continued)
  • Might need to adjust settings
  • Port numbers and terminators
  • Newer SCSI devices typically use an integrated
    self-terminator
  • One problem with older SCSI drives is identifying
    which jumper group terminates and assigns a port
    number

68
Examining IDE/EIDE and SATA Devices
  • Most forensic disk examinations involve EIDE and
    SATA drives
  • ATA drives from ATA-33 to ATA-133
  • Standard 40-pin ribbon or shielded cable
  • 40-pin/80-wire cable for ATA-66, 100, and 133
  • CMOS identifies proper disk settings using
  • Logical block addressing (LBA)
  • Enhanced CHS configurations
  • Can be a problem during an investigation

69
Examining IDE/EIDE and SATA Devices (continued)
  • Solutions
  • Use disk imaging tools
  • Use an old PC
  • Cards and adapters
  • ISA SCSI card
  • A-Card IDE adapter
  • SCSI-to-IDE adapter
  • EISA FireWire card
  • FireWire-to-EIDE adapter

70
Examining IDE/EIDE and SATA Devices (continued)
  • Examining the IDE host protected area
  • ATAPI-5 AT introduced in 1998 reserved and
    protected areas on IDE devices
  • Protected Area Run Time Interface Extension
    Service (PARTIES)
  • Data stored by diagnostic and restore programs
  • Tools
  • X-Ways Replica
  • HPA is also referred to as a BIOS Engineering
    Extension Record (BEER) data structure

71
Examining IDE/EIDE and SATA Devices (continued)
  • Exploring hidden partitions
  • Suspects try to conceal evidence by hiding disk
    partitions
  • Norton Disk Edit can change the disk partition
    table
  • Leaving no indication that the deactivated
    partition exists
  • Use imaging tools that can access unpartitioned
    areas of a drive

72
Summary
  • Macintosh uses HFS
  • Hierarchical structure
  • Mac OS file structure
  • Data fork and resource fork
  • Volume refers to any storage media
  • Allocation and logical blocks
  • Ext2fs uses inodes
  • Ext3fs journaling version of Ext2fs

73
Summary (continued)
  • Linux file structure
  • Metadata and data
  • CD and DVDs are optical media
  • ISO 9660 and 13346
  • Other device technologies
  • SCSI
  • IDE/EIDE
  • SATA
Write a Comment
User Comments (0)
About PowerShow.com
