PLATON, A Multipurpose Crystallographic Tool

1
PLATON, A Multipurpose Crystallographic Tool

• Ton Spek,
• National Single Crystal Service Facility,
• Utrecht, The Netherlands.

2
What is PLATON

• A Multipurpose Crystallographic Tool.
• A Program Developed in, and Addressing the needs
  of, a Single Crystal Service Environment.
• Compatible with and Complementary to the Public
  Domain SHELX Bruker-AXS SHELXTL Software.
  (.res,.hkl,.cif,.fcf)
• Semi Public domain (I.e. free-of-charge for
  academics, but with a License Fee for For Profit
  Organizations).
• Developed on UNIX/LINUX and available on
  MS-Windows MAC-OSX Platforms.

3
Multipurpose Crystallographic Tool

• Automatic Geometry Analysis Listing.
• Molecular Graphics (ORTEP, PLUTON, Contour)
• Absorption Correction Tools(MULABS,TOMPA)
• ADDSYM - Check for Missed Symmetry.
• SQUEEZE Disordered Solvent Handling.
• Generation of Powder Patterns (Coordinates, hkl)
• Structure Validation (part of IUCr CHECKCIF).
• Analysis of Fo/Fc data including Bijvoet Pairs.
• Analysis of (Pseudo) Merohedral Twinning.
• System-S, Automated Structure Determination.

4
EXAMPLE

• Input Shelx Style sucrose.res
• Alternatively
• .cif, .pdb, .fdat, .spf style files
• Invoke PLATON
• UNIX platon sucrose.res
• MS-Windows via Farrugia task menu
• Opening Menu (4 areas) ?

5
(No Transcript)
6
EXAMPLE

• Input Shelx Style sucrose.res
• (Alternatively .cif,.pdb,.dat,.spf style)
• Automatic ORTEP style PLOT ?

7
(No Transcript)
8
(No Transcript)
9
EXAMPLE

• Input Shelx Style sucrose.res
• (Alternatively .cif,.pdb,.dat,.spf style)
• Automatic PLUTON style PLOT ?

10
(No Transcript)
11
EXAMPLE

• Input Shelx Style sucrose.res
• (Alternatively .cif,.pdb,.dat,.spf style)
• NEWMAN Plots ?

12
(No Transcript)
13
EXAMPLE

• Input Shelx Style sucrose.res
• (Alternatively .cif,.pdb,.dat,.spf style)
• Simulated Powder Pattern (hkl or coord)
• from coordinates ?

14
(No Transcript)
15
Intra-molecular Geometry

• Atom list sort.
• Detection of residues (connected set) and
  derivation of the Moiety formula, Z and Z.
• Bond distances, Bond Angles, Torsion Angles.
• Automatic ring search,automatic seach of planar
  parts in the structure

16
Intra-Molecular (Continued)

• Determination of the hybridization, R/S
  assignments and topology numbers.
• Listing of the plane-plane and bond-plane
  angles.
• Ring puckering analysis (Cremer Pople)
• Example ?

17
(No Transcript)
18
Inter-Molecular

• Hydrogen Bonds (linear, bi- and trifurcated)
• Automatic analysis in terms of 1, 2 and 3-D
  networks (aggregates or cooperative)
• Search for pi-pi and C-H..pi interactions
• Example H-Bond Table ?

19
(No Transcript)
20
CALC ALL GEOMETRY LISTING

• With CALC ALL an exhaustive listing of derived
  intra-, inter- and coordination geometry etc. is
  produced, including a structure validation
  report.
• Two content identical files are produced.
  .lis and lps. The first is lineprinter style,
  the latter is suitable for either a PostScript
  printer or inspection with ghostview.
• We routinely provide this exhaustive listing to
  the chemist/client along with an ORTEP.

21
PLATON/ADDSYM ANALYSIS

• Example of a missed symmetry case from the CSD ?

22
BAMYEU Dalton Trans 2003,134-140 Cc
23
(No Transcript)
24
(No Transcript)
25
NEWSYM

• Companion to ADDSYM Analysis
• Structure factors calculated from current cell,
  symmetry and coordinate info.
• Determination of the Space Group from the
  systematic absences in F(calc)
• Extinctions in F(calc) may differ from those in
  F(obs) due to poor data.

26
(No Transcript)
27
(No Transcript)
28
QUATERNION FIT

• In many cases, an automatic molecule fit can be
  performed
• A) Identical atom numbering
• B) Sufficient Unique Atoms
• C) Manual picking of a few atom pairs

29
(No Transcript)
30
QUATERNION FIT
31
Cg1 0.946 0.234 0.592 Cg2 0.441 0.253 0.581
32
(No Transcript)
33
(No Transcript)
34
STRUCTURE VALIDATION

• Single crystal structure validation addresses
  three important questions
• 1 Is the reported information complete?
• 2 What is the quality of the analysis?
• 3 Is the Structure Correct?

35
IUCR-CHECKCIF

• IUCR-TESTS
• MISSING DATA, PROPER PROCEDURE, QUALITY
• PLATON TESTS
• SYMMETRY, GEOMETRY, DISPLACEMENT PARAMETERS
• ALERT LEVELS
• ALERT A - SERIOUS PROBLEM
• ALERT B - POTENTIALLY SERIOUS PROBLEM
• ALERT C - CHECK EXPLAIN

36
Problems Addressed by PLATON

• Missed Higher Space Group Symmetry
• Solvent Accessible Voids in the Structure
• Unusual Displacement Parameters
• Hirshfeld Rigid Bond test
• Miss-assigned Atom Type
• Population/Occupancy Parameters
• Mono Coordinated/Bonded Metals
• Isolated Atoms

37
Problems Addressed by PLATON

• Too Many Hydrogen Atoms on an Atom
• Missing Hydrogen Atoms
• Valence Hybridization
• Short Intra/Inter-Molecular Contacts
• O-H without Acceptor
• Unusual Bond Length/Angle
• CH3 Moiety Geometry

38
Validation with PLATON

• - Details www.cryst.chem.uu.nl/platon
• Driven by the file CHECK.DEF with criteria, ALERT
  messages and advice.
• Button VALIDATION on PLATON MAIN Menu
• Use platon u structure.cif
• Result on file structure.chk
• Applicable on CIFs and CCDC-FDAT
• FCF-Valid platon V structure.cif

39
Example of Misplaced Hydrogen Atom
40
Two ALERTS related to the misplaced Hydrogen Atom
41
Unsatisfactory Hydrogen Bond Network
42
(No Transcript)
43
(No Transcript)
44
Satisfactory Hydrogen Bond Network with new
H-position
45
(No Transcript)
46
Solvent Accessible Voids

• A typical crystal structure has only 65 of the
  available space filled.
• The remainder volume is in voids in-between atoms
  (to small to accommodate an H-atom)
• Solvent accessible voids are defined as regions
  in the structure that can accommodate at least a
  sphere with radius 1.2 Angstrom without
  intersecting with any of the van der Waals
  spheres assigned to each atom in the structure.

47
DEFINE SOLVENT ACCESSIBLE VOID
STEP 1 EXCLUDE VOLUME INSIDE THE VAN DER
WAALS SPHERE
48
DEFINE SOLVENT ACCESSIBLE VOID
STEP 2 EXCLUDE AN ACCESS RADIAL VOLUME TO
FIND THE LOCATION OF ATOMS WITH THEIR CENTRE AT
LEAST 1.2 ANGSTROM AWAY
49
DEFINE SOLVENT ACCESSIBLE VOID
STEP 3 EXTEND INNER VOLUME WITH POINTS
WITHIN 1.2 ANGSTROM FROM ITS OUTER BOUNDS
50
Cg
51
(No Transcript)
52
SQUEEZE

• Takes the contribution of disordered solvents
  into account by back-Fourier transformation of
  density found in the solvent accessible volume
  outside the ordered part of the structure.
• Filter Input shelxl.res shelxl.hkl
• Output solvent free shelxl.hkl

53
SQUEEZE PROCEDURE

• Refine structure including H-atoms
• Use .res and .hkl for the SQUEEZE calculation
• Continue refinement using the reflection file
  produced by SQUEEZE
• Calculate a final .fcf using the latest .res and
  .hkl (from SQUEEZE) using PLATON/FCF
• Append the .fsq file to the final .cif for
  publication.

54
Twinning

• Twinning results in overlap of reflections with
  different hkl
• Twinning can be detected during the data
  collection experiment
• Cases of (Pseudo) Merohedral twinning are
  generally detected during the structure
  determination

55
(Pseudo)Merohedral Twinning

• Options to handle twinning in L.S. refinement
  available in SHELXL, CRYSTALS etc.
• Problem Determination of the Twin Law that is in
  effect.
• Partial solution coset decomposition, try all
  possibilities
• (I.e. all symmetry operations of the lattice
  but not of the structure)
• ROTAX (S.Parson et al. (2002) J. Appl. Cryst.,
  35, 168.
• (Based on the analysis of poorly fitting
  reflections of the type F(obs) gtgt F(calc) )
• TwinRotMat Automatic Twinning Analysis as
  implemented in PLATON (Based on a similar
  analysis but implemented differently)

56
Example

• Structure refined to R 20 in P-3
• Run TwinRotMat on CIF/FCF
• Result Twinlaw with estimate of the twinning
  fraction and drop in R-value

57
(No Transcript)
58
(No Transcript)
59
Absolute Structure

• The absolute structure of a compound is normally
  determined with the refinement of the Flack
  parameter.
• The value of the Flack parameter can be
  inconclusive in view of a high su.
• A detailed scatter-plot may be more conclusive.

60
BIJVOET PAIR SCATTER PLOT
61
System S

• Automatic structure determination
• (Space group determination, solution,
  refinement, analysis)
• Build-in in PLATON (Unix only)
• Calls external programs including itself for
  various functions.
• Program runs in either guided or
  no-questions-asked mode

62
SYSTEM S

• INPUT HKL, CELL CONTENT data
• Interface to SHELX(S/L), DIRDIF,SIR97, SIR2002,
  POVRAY,RASTER3D etc.
• Internal PLATON Tools Space Group Det,
  Absorption Correction, Graphics, Validation,
  ADDSYM etc.
• Platon s compound.ins nqa

63
Finally

• Other features
• Structure Tidy (CIF input)
• Bond Valence
• Renaming of atoms, cif2res, asym-view
• More Info
• www.cryst.chem.uu.nl/platon
• Right mouse clicks gt help on menu item

64
Thanks

• Thanks to the users for their
• Complaints
• Bug reports (undocumented features ..)
• Suggestions
• And you for your attention
