1
(No Transcript)
2
(No Transcript)
3

•  Etiological Agents Causing Myocarditis
•   Viral (Most Common)
•  Adenovirus
•  Coxsackie virus/Enterovirus
• Cytomegalovirus
• Parvovirus B19
• Hepatitis C virus
•  Influenza
• Human immunodeficiency virus
• Herpes virus
•  Epstein-Barr virus
• Mixed infections

4

• Bacterial
• Mycobacterial species
• Chlamydia pneumoniae
•  Streptococcal species
• Mycoplasma pneumoniae
• Treponema pallidum
• Fungal
• Aspergillus
• Candida
•  Coccidioides
• Cryptococcus
• Histoplasma
• Protozoal   Trypanosoma cruzi
• Parasitic   Schistosomiasis   Larva migrans

5

• Toxins
• Anthracyclines
• Cocaine
• Hypersensitivity
• Clozapine
• Sulfonamides
• Cephalosporins
• Penicillins
• ricyclic antidepressants

• Autoimmune Activation
•   Smallpox vaccination
•  Giant cell myocarditis
• Churg-Strauss syndrome
• Sjögren syndrome
•  Inflammatory bowel disease
• Celiac disease
•  Sarcoidosis
• Systemic lupus erythematosus
• Takayasu arteritis
• Wegener granulomatosis

6

•     Expanded Criteria for Diagnosis of
  Myocarditis
• Suspicious for myocarditis 2 positive
  categoriesCompatible with myocarditis 3
  positive categories
• High probability of being myocarditis all 4
  categories positive(Any matching feature in
  category positive for category)
• Category I Clinical Symptoms
• Clinical heart failure
• Fever
•  Viral prodrome
•  Fatigue
•  Dyspnea on exertion
• Chest pain
• Palpitations
•  Presyncope or syncope

7

• Category II Evidence of Cardiac
  Structural/Functional Perturbation in the Absence
  of Regional Coronary Ischemia
•  Echocardiography evidence
• Regional wall motion abnormalities
•  Cardiac dilation
• Regional cardiac hypertrophy
• Troponin release   High sensitivity (gt0.1 ng/ml)

• Positive indium-111 antimyosin scintigraphy   and
    Normal coronary angiography or   Absence of
  reversible ischemia by coronary distribution on
  perfusion scan

8

• Category III Cardiac Magnetic Resonance Imaging
    I
• ncreased myocardial T2 signal on inversion
  recovery sequence
•  Delayed contrast enhancement following
  gadolinium-DTPA infusion
• Category IV Myocardial BiopsyPathological or
  Molecular Analysis
• Pathology findings compatible with Dallas
  criteria
• Presence of viral genome by polymerase chain
  reaction or in situ hybridization

9

• Comparison of Efficacy of Various Diagnostic
  Modalities for Myocarditis
• Diagnostic Modality Sensitivity
  Range Specificity Range
• ECG changes (e.g., AV block, Q, ST
  changes) 47 ?
• Troponin (lower threshold of gt0.1
  mg/ml) 34-53 89-94
• CK-MB 6 ?
• Antibodies to virus or myosin 25-32 40
• Indium-111 antimyosin scintigraphy 85-91 34-53

• Echocardiography (ventricular dysfunction) 69 ?
• Cardiac magnetic resonance imaging 86 95
• Myocardial biopsy (Dallas criteria of
  pathology) 35-50 78-89
• Myocardial biopsy (viral genome by
  PCR) 38-65 80-100
• ? indeterminant or poor AV atrioventricular
  CK-MB cytosine kinase isoenzyme ECG
  electrocardiogram PCR polymerase chain
  reaction.

10
(No Transcript)
11
(No Transcript)
