Elaboration or: Semantic Analysis

1
Elaborationor Semantic Analysis

• Compiler
• Baojian Hua
• bjhua_at_ustc.edu.cn

2
Front End
lexical analyzer
source code
tokens
abstract syntax tree
parser
semantic analyzer
IR
3
Elaboration

• Also known as type-checking, or semantic analysis
• context-sensitive analysis
• Checking the context-sensitive property of
  programs (AST)
• every variable is declared before use
• every expression has a proper type
• function calls conform to definitions
• all other possible context-sensitive info
  (highly language-dependent)

4
Elaboration Example

• // Sample C code
• void f (int p)
• x 4
• p (23)
• hello world
• int main ()
• f () 5
• break

What errors can be detected here?
5
Conceptually
Elaborator
AST
Intermediate Code
Language Semantics
6
Semantics

• Traditionally, semantics takes the form of
  natural language specification
• e.g., for the operator, both the left and
  right operands should be of integer type
• refer to various specifications
• But recent research has revealed that semantics
  can also be addressed via math
• rigorous and clean

7
Semantics

• Now lets turn to Macqueens note
• How to implement these rules?

8
Language S

• // Lets make the SLP typed
• prog -gt decs stm
• decs -gt type ID decs
• -gt
• type -gt bool int
• stm -gt stm stm
• ID exp
• print (exp)
• printBool (exp)
• exp -gt ID NUM expexp expexp
• true false

variable declarations followed by statements
two types bool and int
print an integer value
print a bool value
both the two sub-expressions must be booleans
9
Symbol Tables

• In order to keep track of the types and other
  infos wed maintain a finite map of program
  symbols to info
• symbols variables, function names, etc.
• Such a mapping is called a symbol table, or
  sometimes an environment
• Notation x1 b1, x2 b2, , xn bn
• where bi (1i n) is called a binding

10
Type System

• Next, we write the symbol table as ?
• ?ty x1 ty x2 ty x3
• a list of (ty var) tuples
• may be empty
• Each rule takes the form of

? ? P1 ty
? ? Pn ty
?? ? C ty
11
Type System exp
ty x ? ?
?? ? n int
?? ? x ty
?? ? true bool
?? ? false bool
? ? e1 int
? ? e2 int
?? ? e1e2 int
? ? e1 bool
? ? e2 bool
?? ? e1e2 bool
12
Type System stm
? ? x ty
? ? e ty
??- xe OK
? ? e int
?? ? print(e) OK
? ? e bool
?? ? printBool(e) OK
13
Type System dec, prog
id ? dom(?)
? type id ? decs ?
?? ? type id decs ?
?? ? ?
? ? stm OK
? decs ?
? ? decs stm OK
14
Example
// Whether or not the following program is //
well-typed? int x int y print (xy)
int x ? ?
int y ? ?
? ? x int
? ? y int
int x int y ? ?
? ? xy int
int x ? int y ?
? int x int y ?
? ? print(xy) OK
? ? int x int y print(xy) OK
15
Elaboration of Expressions
? ? n int

• type elab_exp (sigma, n)
• return int

16
Elaboration of Expressions
? ? true bool

• type elab_exp (sigma, true)
• return bool

17
Elaboration of Expressions
? ? false bool

• type elab_exp (sigma, false)
• return bool

18
Elaboration of Expressions
ty x ? venv
? ? x ty

• type elab_exp (sigma, x)
• type ty Table_lookup (sigma, x)
• if (tyNULL)
• error (variable not declared)
• return ty

19
Elaboration of Expressions

• type elab_exp (sigma, e1e2)
• type t1 elab_exp (sigma, e1)
• type t2 elab_exp (sigma, e2)
• switch (t1, t2)
• case (Int, Int) return Int
• case (Int, _) error (e2 should be int)
• case(_, Int) error (e1 should be int)
• default error (should both be int)

20
Elaboration of Expressions
? ? e1 bool
? ? e2 bool
? ? e1e2 bool

• type elab_exp (sigma, e1e2)
• type t1 elab_exp (sigma, e1)
• type t2 elab_exp (sigma, e2)
• switch (t1, t2)
• case (Bool, Bool) return Bool
• case (Bool, _) error(e2 should be bool)
• case(_, Bool) error(e1 should be bool)
• default error (should both be bool)

21
Elaboration of Statements
? ? x ty
? ? e ty
? ? xe OK

• void elab_stm (sigma, xe)
• type t1 elab_exp (sigma, x)
• type t2 elab_exp (sigma, e)
• if (t1 ! t2)
• error (different types in assigment)

22
Elaboration of Statements
? ? e int
? ? print(e) OK

• void elab_stm (sigma, print(e))
• type ty elab_exp (sigma, e)
• if (ty ! INT)
• error (type should be INT)

23
Elaboration of Statements
? ? e bool
? ? printBool(e) OK

• void elab_stm (sigma, printBool(e))
• type ty elab_exp (sigma, e)
• if (ty ! BOOL)
• error (type should be BOOL)

24
Elaboration of Declarations
ID ? dom(?)
? type ID? ? decs ?
? ?? type ID decs ?
?? ? ?

• Sigma elab_decs (sigma, decs)
• if (decs)
• return sigma
• // decs type ID decs
• if (ID\in sigma) error (duplicated decl)
• new_sigma enter_table (sigma, type ID)
• return elab_decs(new_sigma, decs)

25
Elaboration of Programs
?? decs ?
? ?? stm OK
? ? ?? decs stm OK

• void elab_prog (decs stm)
• sigma elab_decs (decs)
• elab_stm (sigma, stm)

26
Moral

• There may be other information associated with
  identifiers, not just types, say
• Scope
• Storage class
• Access control info
• All these details are handled by symbol tables
  (?)!

27
Implementation

• Must be efficient!
• lots of variables, functions, etc
• Two basic approaches
• Functional
• symbol table is implemented as a functional data
  structure (e.g., red-black tree), with no tables
  ever destroyed or modified
• Imperative
• a single table, modified for every binding added
  or removed
• This choice is largely independent of the
  implementation language

28
Functional Symbol Table

• Basic idea
• when implementing s2 s1 xt
• creating a new table s2, instead of modifying s1
• when deleting, restore to the old table
• A good data structure for this is BST or
  red-black tree

29
BST Symbol Table
?
?
c int
c int
e int
a char
b double
30
Possible Functional Interface

• signature SYMBOL_TABLE
• sig
• type a t
• type key
• val empty a t
• val insert a t key a -gt a t
• val lookup a t key -gt a option
• end

31
Imperative Symbol Tables

• The imperative approach almost always involves
  the use of hash tables
• Need to delete entries to revert to previous
  environment
• made simpler because deletes follow a stack
  discipline
• can maintain a stack of entered symbols, so that
  they can be later popped and removed from the
  hash table

32
Possible Imperative Interface

• signature SYMBOL_TABLE
• sig
• type a t
• type key
• val insert a t key a -gt unit
• val lookup a t key -gt a option
• val delete a t key -gt unit
• val beginScope unit -gt unit
• val endScope unit -gt unit
• end

33
Implementation of Symbols

• For several reasons, it will be useful at some
  point to represent symbols as elements of a
  small, densely packed set of identities
• fast comparisons (equality)
• for dataflow analysis, we will want sets of
  variables and fast set operations
• It will be critically important to use bit
  strings to represent the sets
• For example, your liveness analysis algorithm
• More on this later

34
Scope

• How to handle lexical scope?
• Many choices
• One table insert and remove bindings during
  elaboration, as we enters and leaves a local
  scope
• Stack of tables insertion and removal always
  operated on stack-top
• dragon compiler makes use of this

35
One-table approach

• int x sxint
• int f () s1 s f xint, f
• if (4)
• int x s2 s1 xint x, f, x
• x 6
• s1
• else
• int x s4 s1 xint x, f, x
• x 5
• s1
• x 8
• s1

Shadowing is not commutative!
36
Name Space

• struct list
• int x
• struct list list
• list
• void walk (struct list list)
• list
• printf (d\n, list-gtx)
• if (list list-gtlist)
• goto list

37
Name Space

• Its trivial to handle name space
• one symbol table for each name space
• Take C as an example
• Several different name spaces
• labels
• tags
• variables
• So

38
Types

• The representation of types is highly
  language-dependent
• Some key considerations
• name vs. structural equivalence
• mutually recursive type definitions
• errors handling

39
Name vs. Structural Equivalence
struct A int i x struct B int i
y x y

• In a language with structural equivalence, this
  program is legal
• But not in a language with name equivalence
  (e.g., C)
• For name equivalence, can generate a unique
  symbol for each defined type
• For structural equivalence, need to recursively
  compare the types

40
Mutually recursive type definitions

• To process recursive and mutually recursive type
  definitions, need a placeholder
• in ML, an option ref
• in C, a pointer
• in Java, bind method (read Appel)

struct A int data struct A next struct
B b struct B
41
Error Diagnostic

• To recover from errors, it is useful to have an
  any type
• makes it possible to continue more type-checking
• In practice, use int or guess one
• Similarly, a void type can be used for
  expressions that return no value
• Source locations are annotated in AST!

42
Summary

• Elaboration checks the context-sensitive
  properties of programs
• must take care of semantics of source programs
• and may translate into more low-level forms
• Usually the most big (complex) part in a compiler!
