Titius-Bode Law -

1
(No Transcript)
2
Titius-Bode Law -

• Mercury 0.4 AUs
• Venus 0.3 (0.7)
• Earth 0.6 (1.0)
• Mars 1.2 (1.6)
• A. B. 2.4 (2.8)
• Jupiter 4.8 (5.2)
• Saturn 9.6 (10.0)
• Uranus 19.2 (19.6) (Actually 19.2)
• Neptune 38.4 (38.8) (Actually 30)
• Pluto is at 39.5

3
The Titius-Bode law works very well for the first
six planets and the asteroid belt, but not very
well for the planets after that. The Titius-Bode
law is probably just a curious coincidence.
4
Mercurys orbit is always within 0.5 AU of the
Sun. It is always visually close to the Sun
therefore, it is only observed when low on the
horizon (or during a solar eclipse).
5
It is visible for at most 2 hours on any given
night.
6
(No Transcript)
7
Mercury was originally thought to be two planets.
The Greeks called it Apollo when seen in the
morning and Hermes when seen in the evening.
8
Mercurys surface is fairly reflective. Albedo
- the fraction of incident sunlight an object
reflects into space.
9
Mercurys albedo is only about 0.1, similar to
Earths Moon.However, Mercurys nearness to the
Sun makes it one of the brightest objects in the
night sky.
10
The best pictures of Mercury are taken by large
telescopes during the day.
11
(No Transcript)
12
Mercurys orbital period is 88 Earth days.As
viewed from the Earth, Mercury can pass over the
surface of the Sun.
13
This is called a transit (a smaller, darker
object passes across a larger, brighter one).
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Transits of the Sun by Mercury are fairly rare.
There are only twelve or so per century, always
occurring in Nov. or May.
20
Radius - 2450 km 0.38 Earth radiiMass - 3.3
x 1026 g 0.055 EarthsDensity - 5.4
g/cm3 slightly less than Earths
21
Mercury is now the smallest planet. (It is
larger than Pluto, so it was second smallest
before Plutos demotion to dwarf planet.)
22
Mercurys rotational period is 59 days, which is
2/3 of a Mercury year.
23
Mercury goes through three rotations for every
two revolutions.
24
There is a reason for this 2/3 ratio. Part of
the reason is Mercurys very eccentric orbit
(very elliptic).
25
This causes the orbital speed to vary greatly
throughout the orbit.
26
The orbital and rotational periods are
synchronous at perihelion (closest approach to
the Sun).
27
How would this appear from Mercury?
28
The Sun would move from east to west, except near
perihelion, where rotation is slightly slower
than orbital speed.
29
At this time the Sun would appear to stop and go
backward before it resumed its east to west
motion.
30
Mercurys equator is exactly in the orbital
plane, so Mercury has no axial tilt.
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
