SOAP

1
SOAP

• Kanda Runapongsa
• (krunapon_at_kku.ac.th)
• Dept. of Computer Engineering
• Khon Kaen University

2
Web Services Interaction Diagram
UDDI Registry
1
Request WSDL location
2
Download WSDL
WSDL
Send SOAP messages With XML documents
Web Services
3
3
Why Do We Need SOAP?

• An acceptable standard for routing and packaging
  XML data exchanged between two applications on a
  network
• No need to define our own networking, addressing,
  and routing protocols

4
What is SOAP?

• Simple Object Access Protocol
• It defines a standard packaging format for
  transmitting XML data between applications on a
  network
• It is not specific to any programming language,
  product, or hardware platform

5
What is SOAP?

• SOAP is not a programming language or a business
  application component for building business
  applications
• SOAP is intended for use as a portable
  communication protocol to deliver SOAP messages,
  which have to be created and processed by an
  application

6
A SOAP Message

• A SOAP message is just an XML document
• The message might be sent from one application to
  another to synchronize contact information on two
  different systems
• SOAP takes advantages of XML namespaces and XML
  schemas

7
Anatomy of a SOAP Message

• The structural format of a SOAP message contains
  the following elements
• Envelope
• Header (optional)
• Body
• Attachments (optional)

8
SOAP Envelope

• The SOAP envelope is the primary container of a
  SOAP messages structure
• It is the mandatory element of a SOAP message
• It is represented as the root element of the
  message as Envelope

9
SOAP Envelope Example

• ltSOAP-ENVEnvelope
• xmlnsSOAP-ENVhttp//schemas.xmlsoap.org/soap/e
  nvelope/
• xmlnsxsihttp//www.w3c.org/2001/XMLSchema-inst
  ance
• xmlnsxsdhttp//www.w3.org/2001/XMLSchema
• SOAP-ENVencodinghttp//schemas.xmlsoap.org/
  soap/encoding/gt
• lt! SOAP Header element --gt
• lt! SOAP Body element ---/gt
• lt/SOAP-ENVEnvelopegt

10
SOAP Header

• The SOAP header is represented as the first
  immediate child element of a SOAP envelope
• The Header element can also contain other
  attributes, such as
• mustUnderstand
• actor

11
SOAP Header Example

• ltSOAP-ENVHeadergt
• ltwileyTransaction
• xmlnswileyhttp//jws.wiley.com/2002/booktx
• SOAP-ENVmustUnderstand1gt
• ltkeyValuegt5lt/keyValuegt
• lt/wileyTransactiongt
• lt/SOAP-ENVHeadergt

12
SOAP Fault Example1

• ltSOAP-ENVFaultgt
• ltfaultcodegtSOAP-EnvMustUnderstandlt/faultcodegt
• ltfaultstringgtHeader element missinglt/faultstringgt

• ltfaultactorgthttp//jws.wiley.com/GetBookPricelt/fa
  ultactorgt
• ltdetailgtlt/detailgt
• lt/SOAP-ENVFaultgt

13
SOAP Body

• A SOAP envelope contains a SOAP body as its child
  element
• A Body block of a SOAP message can contain any of
  the following
• RPC method and its parameters
• Target application (receiver) specific data
• SOAP fault for reporting errors and status
  information

14
SOAP Body Example

• ltSOAP-ENVBodygt
• ltmGetBookPrice
• xmlnsmhttp//www.wiley.com/jws.book.priceList
  /gt
• ltbookname xsitypexsdstringgt
• Developing Java Web Serviceslt/booknamegt
• lt/mgetBookPricegt
• lt/SOAP

15
SOAP Fault

• In a SOAP message, the SOAP Fault element is used
  to handle errors and to find out status
  information.
• This element provides the error and /or status
  information
• It can be used within a Body element or as a Body
  entry

16
SOAP Fault

• It provides the following elements to define the
  error and status of the SOAP message
• Faultcode The faultcode element defines the
  algorithmic mechanism for the SOAP application to
  identify the fault
• Faultstring The faultstring element provides a
  readable description of the SOAP fault
• Faultactor The faultactor element provides the
  information about the ultimate SOAP actor
• Detail The detail element

17
SOAP Fault Example1

• ltSOAP-ENVFaultgt
• ltfaultcodegtSOAP-ENVServerlt/faultcodegt
• ltfaultstringgtServer OS Internal Failure Reboot
  serverlt/faultstringgt
• ltfaultactorgthttp//abzdnet.net/keysoap.asplt/fault
  actorgt
• lt/SOAP-ENVFaultgt

18
SOAP Fault Example2

• ltSOAP-ENVFaultgt
• ltfaultcodegtClientlt/faultcodegt
• ltfaultstringgtInvalide Requestlt/faultstringgt
• ltfaultactorgthttp//jws.wiley.com/GetCataloglt/faul
  tactorgt
• lt/SOAP-ENVFaultgt

19
SOAP mustUnderstand

• The SOAP understand attribute indicates that the
  processing of a SOAP header block is mandatory
  (the attribute value is 1) or optional (the
  attribute value is 0) at the target SOAP node
• ltSOAP-ENVHeadergt
• ltwileyCatalog SOAP-ENVmustUnderstand1/gt
• lt/SOAP-ENVHeadergt

20
SOAP Fault Example3

• ltSOAP-ENVBodygt
• ltSOAP-ENVFaultgt
• ltfaultcodegtSOAP- EnvMustUnderstandlt/faultcodegt

• ltfaultstringgtCould not understand Header
  elementlt/faultstringgt
• lt/SOAP-ENVFaultgt
• lt/SOAP-ENVFaultgt

21
SOAP Attachments

• A SOAP message contains the primary SOAP envelope
  in an XML format and SOAP attachments in any data
  format that can be ASCII or binary
• SOAP attachments are not part of the SOAP
  envelope but are related to the message

22
SOAP Attachments

• The SOAP attachment part of the message is
  contained to a MIME boundary (defined in the
  Context-Type header)
• Each MIME part in the structure of the SOAP
  message is referenced using either Content-ID or
  Content-Location as labels for the part

23
SOAP Attachments

• Both the SOAP header and body of the SOAP message
  also can refer to these labels in the message
• Each attachment of the message is identified with
  a Content-ID (typically an href attribute using a
  URL scheme) or Content-Location (a URI reference
  associated to the attachment)

24
SOAP Attachment in a MIME Structure

• MIME-Version 1.0
• Content-Type Multipart/Related
• boundaryMIME_boundary typetext/xml
• Content-Description SOAP message description

25
SOAP Attachment in a MIME Structure

• --MIME_boundary --
• Content-Type text/xml charsetUTF-8
• Content-Transfer-Encoding 8bit
• Content-ID lthttp//jws.wiley.com/coverpagedetails
  .xmlgt
• Content-Location http//jws.wiley.com/coverpagede
  tails.xml

26
SOAP Attachment in a MIME Structure

• lt?xml version1.0?gt
• ltSOAP-ENVEnvelope
• xmlnsSOAP-ENVhttp//schemas.xmlsoap.org/soap/e
  nvelope/gt
• ltSOAP-ENVBodygt
• lt/SOAP-ENVBodygt
• lt/SOAP-ENVEnvelopegt

27
SOAP Attachment in a MIME Structure

• -- MIME_boundary --
• Content-Type image/gif
• Content-Transfer-Encoding binary
• Content-ID lthttp//jws.wiley.com/DevelopingWebSer
  vices.gifgt
• Content-Location http//jws.wiley.com/Developing
• lt!-- binary GIF image --gt
• --MIME_boundary --

28
What is MIME?

• MIME Multipurpose Internet Mail Extension
• A standard system for identifying the type of
  data contained in a file based on its extension.
• MIME is an Internet protocol that allows you to
  send binary files across the Internet as
  attachments to e-mail messages. This includes
  graphics, photos, sound and video files, and
  formatted text documents.

29
SOAP Encoding

• The SOAP Encoding defines a set of rules for
  exposing its data types
• SOAP encoding also defines serialization rules
  for its data model using an encodingStyle
  attribute
• SOAP encoding supports both simple- and
  compound-type values

30
SOAP Encoding Example

• Simple Type Values
• The definition of simple type values is based on
  the W3C XML Schema specification
• Examples
• ltintgt98765lt/intgt
• ltdecimalgt98675.43lt/decimalgt
• ltstringgtJava Ruleslt/stringgt

31
SOAP Encoding Example

• Array Types example
• ltMyPortfolio xmlnshttp//www.w3.org/2001/XMLSchem
  a xmlsenchttp//schemas.xmlsoap.org/soap/encodi
  ng encarrayTypexsstring2gt
• ltsymbolgtSUNWlt/symbolgt
• ltsymbolgtIBMlt/symbolgt
• lt/MyPortfoliogt

32
SOAP Message Exchange Model

• SOAP is a stateless protocol used to exchange
  messages between SOAP applications on a network,
  usually an intranet or the Internet
• A SOAP application is simply any piece of
  software that generates or processes SOAP
  messages

33
SOAP Message Exchange Model

• For example, any Java application or J2EE
  component that uses JAX-RPC would be considered a
  SOAP application
• Because JAX-RPC is used to generate and process
  SOAP message
• The application sending a SOAP message is called
  the sender and the application receiving it is
  called the receiver

34
SOAP Message Exchange Model

• As a SOAP message travels along the message path,
  its header blocks may be intercepted and
  processed by any number of SOAP intermediaries
  along the way
• A SOAP intermediary is both a receiver and a
  sender

35
SOAP Message Exchange Model

• The applications along the message path (the
  initial sender, intermediaries, and ultimate
  receiver) are called SOAP nodes

Initial Sender
Sender
Intermediaries
36
SOAP Message Exchange Model
Intermediaries
Ultimate receiver
Initial Sender
SOAP
SOAP
SOAP
Customer Node
Sales Node
Inventory Node
Shipping Node
37
SOAP Actor

• The SOAP actor global attribute with a URI value
  can be used in the Header element
• SOAP defines an actor with a URI value, which
  identifies the name of the SOAP receiver node as
  an ultimate destination

38
SOAP Actor Example

• ltSOAP-ENVHeadergt
• ltbName xmlnsbhttp//www.wiley.com/BookService
  / SOAP-ENVactorhttp//www.wiley.com/jws/
  SOAP-ENVmustUnderstand1gtWebServiceslt/bNamegt
• lt/SOAP-ENVHeadergt

39
SOAP Communication

• To enable communication between SOAP nodes, SOAP
  supports the following two types of communication
  models
• SOAP RPC It defines a remote procedural
  call-based synchronous communication
• SOAP Messaging It defines a document-driven
  communication where SOAP nodes send and receive
  XML-based documents using synchronous and
  asynchronous messaging

40
SOAP RPC

• The SOAP RPC representation defines a tightly
  coupled communication model based on requests and
  responses
• Using RPC conventions, the SOAP message is
  represented by method names with zero or more
  parameters and return values

41
SOAP Request RPC-Based

• ltSOAP-ENVBodygt
• ltmGetBookPrice
• xmlnsmhttp//www.wiley.com/jws.book.priceList
  gt
• ltbookname xsitypexsdstringgtDeveloping Java
  Web Serviceslt/booknamegt
• lt/mgetBookPricegt
• lt/SOAP-ENVBodygt

42
SOAP Response RPC-Based

• ltSOAP-ENVBodygt
• ltmGetBookPriceResponse xmlnsmhttp//www.wiley
  .com/jws.book.priceListgt
• ltpricegt50.00lt/pricegt
• lt/mGetBookPriceResponsegt
• lt/SOAP-ENVBodygt

43
SOAP Messaging

• SOAP Messaging represents a loosely coupled
  communication model based on message notification
  and the exchange of XML documents
• The SOAP sender node sends a message with an XML
  document as its body message and the SOAP
  receiver node processes it

44
SOAP Message-Based

• ltenvEnvelope xmlnsenvhttp//www.w3.org/2001/12
  /soap-envelopegt
• ltenvHeadergt
• ltnInventoryNotice xmlnsnhttp//jws.wiley.com/
  Inventorygt
• ltnproductCodegtJ687lt/nproductCodegt
• lt/nInventoryNoticegt
• lt/enveHeadergt

45
SOAP Message-Based

• ltenvBodygt
• ltmproduct xmlnsmhttp//jws.wiley.com/product
  gt
• ltmnamegtDeveloping Java Web Serviceslt/mnamegt
• ltmquantitygt25000lt/mquantitygt
• ltmdategt2002-07-01lt/mdategt
• lt/envBodygt
• lt/envEnvelopegt

46
SOAP Bindings for Transport Protocols

• The SOAP specifications do not specify and
  mandate any underlying protocols between the SOAP
  nodes
• SOAP can be used over a variety of transport
  protocols, such as HTTP, SMTP, POP3 and FTP

47
SOAP Request Message Using HTTP

• POST /GetBookPrice HTTP/1.1
• User Agent Mozilla/4.0 (Linux)
• Host krunapon8080
• Content-Type text/xml charsetutf-8
• Content-length 546
• SOAPAction /GetBookPrice
• lt?xml version1.0?gtltSOAP-ENVEnvelopegt....
• lt/SOAP-ENVEnvelopegt

48
SOAP Response Message Using HTTP

• HTTP/1.1 200 OK
• Connection close
• Content-Length 524
• Content-Type text/xml charsetutf-8
• Date Fri, 3 May 2002 050504 GMT
• Server Apache/1.3.0
• lt?xml version1.0?gt
• ltSOAP-ENVEnvelopegt
• lt/SOAP-ENVEnvelopegt

49
SOAP Message Exchange Patterns

• The most common SOAP messaging patterns are as
  follows
• One-way message. The SOAP client application
  sends SOAP messages to its SOAP server without
  any response being returned
• Request/response exchange. In this pattern, the
  SOAP client sends a request message that results
  in a response message from the SOAP server to the
  client

50
SOAP Message Exchange Patterns

• Common SOAP messaging patterns
• Request/NResponse pattern. It is similar to a
  request/response pattern, except the SOAP client
  sends a request that results in zero to many
  response messages from the SOAP server to the
  client
• Notification pattern. The SOAP server sends
  messages to the SOAP client like an event
  notification, without regard to a response

51
SOAP Message Exchange Patterns

• Common SOAP messaging patterns
• Solicit-response pattern. The SOAP server sends
  a request message to the SOAP client like a
  status checking or an audit and the client sends
  out a response message

52
SOAP Message Exchange Patterns
SOAP Client
SOAP Client
SOAP Client
Request/Response pattern
53
SOAP Message Exchange Patterns
SOAP Request Message
SOAP Response Message
SOAP Client
SOAP Server
SOAP Response Message
Request/NResponse pattern
54
SOAP Message Exchange Patterns
SOAP Message(s)
SOAP Server
SOAP Client
Notification pattern
SOAP Message
SOAP Server
SOAP Response Message
Solicit-response pattern
