4903 Morena Blvd., Suite 1213

1
OFFSHORE
The 3rd annual Maritime Business Technology
Summit
4903 Morena Blvd., Suite 1213 San Diego,
California 92117 Voice 858-866-0816 or
-0817 Fax [phone] e-mail
nbrown_at_floatinc.com
Don Innis, President Neal Brown, VP Technology
Susie Bryant, Treasurer
2
Floating LNG/Energy Terminal
3
(No Transcript)
4
LNG Development Co.
5
GE 7FA 262 MW - COGAS
6
Up to 80,000 tonnes/day Fresh Water from the sea
Weir Entropie TCD 4-10,000 thermal-compression
distillation units
7
Why Co-Generation?

• Here, steam is extracted from power turbines
  before exit to condensers evaporates sea water
  in distillation units. Hot drains of fresh water
  and brine then deliver heat to re-gasify LNG.
• Overall efficiency of utilities is enhanced
• Much less waste heat is rejected to the ocean
• Fresh water is produced economically
• No natural gas need be burned to re-gasify LNG
• Closed-Loop re-gasification no sea water
  is subjected to cryogenic temperatures

8
Co-Generation
relative heat/energy flows with water and
re-gasification
9
1/2MMbbl Marginal Field Floater TM
10
MFFTM Drilling w/BLC Protection
High Seas Afloat, LLC
11
Natural Gas Liquefaction Offshore Nigeria
12
The 3rd annual Maritime Business Technology
Summit
from
TechConnect World 2011 16 June 2011 Boston,
MA Offshore Wave Wind Together - Afloat Neal
A. Brown, PhD Float Incorporated San Diego,
CA 548
13
20 30
14
1/6th scale Rho-Cee being prepd for
absorption test at Ohmsett facility
15
The Rho-Cee WEC is a Critical Part of an
Offshore Ocean Energy SYSTEM centered on the
Pneumatically Stabilized Platform (PSP)
16
Extending the Wind Turbine support provided by
the Rho-Cee PSP
span 1040m WT spacing 200m
(extendable-leeward) rotor diameter 90m ?C
length 1200m WT rating 3MW ?C rating
30kW/m 200m dock struts 200m x 15
concrete culvert pipe, w/rails estimated total
foundation cost 1677/kW
PE Storage 12MW-Hr, cold
calm
calm
Total Power Rating 72MW WAG Total Cap
Cost Est 300M
Waves, Wind 60
17
The Stone Age Did Not End for Want of Stones
