Tools and Processes for Testing VoIP

1
Tools and Processes for Testing VoIP Chris
Bajorek, DirectorCT Labswww.ct-labs.com
2
About the Speaker Chris Bajorek, Director and
Founder, CT Labs Chris Bajorek is a 25-year
veteran of computer telephony and converged
communications. Bajorek has led the company to
its industry-leading position in testing services
which include real-world performance testing,
interoperability verification, and usability and
quality analysis. Customers include first-tier
enterprise and carrier-grade next-generation
network product manufacturers. Prior to
founding CT Labs, Bajorek founded Telephone
Response Technologies, Inc. (TRT), which
developed and sold turnkey voice response and
unified messaging products as well as
award-winning toolkits for rapid development of
voice-based applications. Prior to TRT he worked
for Integrated Office Systems and Time and Space
Processing where he performed pioneering work on
voicemail and digital voice communications
products. Bajorek holds a B.S.E.E. from Cal
Poly, San Luis Obispo.
3
For Todays Talk Taking a Developers
Perspective to VoIP Test

• Much of CT Labs business is with RD and QA
  groups of VoIP product manufacturers
• Would like to provide a window into some of our
  VoIP test experiences, including
• Common VoIP test myths
• Testing tips and suggestions
• Focus on voice quality testinghot area for VoIP

4
Myths around VoIP Deployment

• Voice quality is a given
• VoIP is easy to deploy
• VoIP is inexpensive to deploy
• All VoIP-enabled phones are created equal
• Once you have your VoIP network set up, you can
  leave it alone

5
VoIP Requires a Lifecycle Approach

• Lack of a proper lifecycle will
• Drive Costs Up
• Reduce VoIP Reliability / Availability
• Risk Complete Failure of Deployment

Should design new VoIP products with this in mind
6
VoIP Troubleshooting Areas The Big Picture

• Call Processing (i.e. call connectivity, service
  availability)
• Voice Quality
• Interoperability / Feature Interaction
• Configuration / Registration
• Routing
• Security
• Applications (conferencing, IVR, voicemail, )

7
Troubleshooting example

• Symptom sporadic call failures
• Common causes
• Gateway and switch mis-configuration
• Interoperability issues between equipment
• Capacity limitations
• Performance issues and delays triggering
  timeouts
• Feature interaction issues such as conflicting
  call-forwarding settings

8
VoIP Deployment Segments

• Residential (Voice over Broadband)
• Enterprise
• Next-Gen Network Carriers and Service Providers
• All three areas are quite active now

9
VoIP Products, by Segment(products that touch
the media stream)

• Residential
• Analog terminal adapters, VoIP softphones,
  residential routers
• Enterprise
• IP PBXs, IP Contact Centers, VoIP phones
  softphones, firewalls/ALGs, media servers
  (conferencing, voice mail)
• Next-Gen Carriers and Service Providers
• Session border controllers, media servers, media
  gateways, transcoding/VQ enhancement processors

10
VoIP Testing Areas of Focus

• Service reliability
• i.e. Availability of service, Call connectivity
• Voice quality
• Includes measurement of VQ, latency, levels, echo
  can., etc.
• Phone features
• CLASS features, such as call park, transfer, etc.
• VoIP Access to enhanced services
• Voice mail, conferencing, IVR, etc.
• Each of these areas has its own set of testing
  challenges, but one thing is clear all relate
  to the end-user Quality Experience and must be
  validated

11
Active versus Passive VoIP Testing

• Active tests
• Involves driving real 2-way calls thru the VoIP
  network
• Benefits more accurate, uses mature standards
  (PESQ, etc.) for automated quality assessment
• Negatives consumes network resources
• Passive tests
• Involves passive evaluation of call-based packet
  flows
• Ignores (or models) VoIP endpoint-specific
  behaviors to network conditions

12
Post-Deployment, Passive Testing is Key

• Deployed VoIP networks should
• Continuously monitor passive VQ, call completion
  rates, network packet loss, jitter, latency
• Set alarming thresholds for VoIP call performance
  that degrades below adaptive-corrective levels
• Assumption Pre-deployment tests resulted in
• Clean bill of network health
• Baseline characterization of network during peak,
  off-peak times

13
Passive Monitoring Embedded Components for
Product Developers

• Products incorporating these can quickly adapt to
  changing IP network conditions
• Real-time access to estimated MOS, round-trip
  latency
• Access to level and echo information for estimate
  of MOS-Conversational Quality
• VQMon from Telchemy (www.telchemy.com)
• PsyVoIP -- from Psytechnics (www.psytechnics.com)


14
A few things about Codecs

• Waveform codecs
• Produces waveform as identical as possible to the
  original (G.711 PCM, G.726 ADPCM)
• Source codecs
• Uses a model of how speech is generated
• Can significantly alter the time-domain waveform
  while sounding very similar to the input
  (G.729a/729, G.723.1)

15
A few things about Codecs

• Hybrid codecs
• Combine techniques from waveform and source
  codecs
• Uses different modes and bit rates depending on
  network conditions
• AMR
• Bit rate 4.75-12.2 kbps MIPS complexity
  15-20
• AMR-WB / G.722.2 (wideband7kHz signal bw)
• Bit rate 6.6-28.3 kbps MIPS complexity 38
  (incl. VAD and CNG)
• Why knowledge of codec method(s) is useful for VQ
  analysis

16
Devices that can affect a Users VoIP
Experience
SBCs (Border Controllers) Media Servers
Firewalls/ALGs Messaging Servers Conference
Bridges

• IP PBXs
• IP Phones VoIP endpoints
• Media Gateways
• IVR / Voice portals

17
Voice Quality versus Intelligibility

• Voice quality the acceptability of speech
• Intelligibility the clarity of speech
• Subjective tests Diagnostic Rhyme Test, Modified
  Rhyme Test
• Higher frequencies more important for
  intelligibility, a good benefit of wideband
  codecs
• Lower quality affects intelligibility but not
  necessarily vice versa

18
Voice Quality Measurement A Hot Topic

• What is considered the gold standard way to
  measure voice quality?
• Answer with humans, and the more of them in a
  listening session the better the resolution of
  the resulting quality scores
• However, conducting a live-listener test is not
  as easy or cheap as you may think

19
MOS Subjective Testing

• Its a Standard ITU-T P.800 (1996)
• The technique rates quality using absolute
  category rating method (ACR) 5-grade scale
  5excellent 4good 3fair 2poor
  1bad

20
MOS Subjective Testing

• How its done
• Requires use of a group of 32-64 naive
  listeners
• Standardized male, female, and child phrases are
  used
• Calibrating reference degraded conditions are
  intermixed with actual samples
• The identical speech sample sets are played to
  all listeners
• Listeners judge the quality of each phrase using
  ACR scale

21
MOS Subjective Testing

• Strengths
• Provides the definitive answer to which sounds
  best?
• Weaknesses
• High cost, especially when many different test
  conditions or sample sets must be evaluated
• Takes time to schedule test and get results

22
Objective VQ Standards

• All automated VQ measurement techniques are
  designed to estimate the way humans perceive
  voice quality
• PSQM P.861 (1996)
• PSQM handled higher distortion levels than PSQM
• PESQ P.862 (2001)
• Solved variable delay (alignment) problem of
  PSQM

23
What PESQ VQ Testing is designed for

• PESQ is a way to quickly and cost-effectively
  estimate the effects of one-way speech distortion
  and noise on speech quality
• PESQ is endpoint-agnostic can be used for
  VoIP-to-VoIP, VoIP-to-PSTN calls, etc.
• PESQ can be used for VQ assessment of wideband
  codecs if your test platform supports it (if not,
  3.1kHz signal bandwidth applies)

24
PESQ Narrowband vs. Wideband
25
What PESQ VQ Testing is not designed for

• PESQ does not evaluate the effects of loudness
  loss, fixed latency, sidetone, or echo as related
  to two-way caller interactions
• PESQ can not safely be used to declare a VQ
  winner when the PESQ score differential is
  small (i.e. lt.25)
• Opposite conclusion errors are very possible,
  so the bigger the score differential the better
• Especially true when comparing samples with more
  than a single changed variable

26
Objective VQ Testing

• Strengths
• Provides excellent estimate of voice quality
• Tests can be performed quickly
• Tests are very repeatable
• Weaknesses
• Not good for reliably resolving small differences
  in quality scores

27
Troubleshooting VQ Issues

• Must look at all the metrics of VoIP calls
  exactly as transmitted on the network

• Packet Loss ?
• Jitter ?
• Delay ?
• Voice Quality ?

Measurement is critical for problem resolution
Jitter distribution graph
28
Tip How to test end-to-end VQof VoIP phones

• 1 Its usually not enough to evaluate VQ by
  just looking at the packet streams (i.e. E-model)
• 2 Must evaluate quality all the way to the
  phones earpiece and microphone wires
• So can evaluate the proper operation of the
  phones internal VoIP gateway, including
  automatic gain (AGC), voice activity detection
  (VAD), comfort noise generation (CNG), echo
  cancellation, codecs, jitter buffer management,
  and packet loss concealment algorithms.
• In other words, there is much that can go wrong.

29
Tip How to test end-to-end VQof VoIP phones

• 3 Must evaluate under expected LAN/WAN
  impairment conditions
• Packet loss, Jitter, Latency
• Effective bandwidth of IP connection
• i.e. Broadband versus Dialup
• 4 Dont forget interoperability testing against
  other VoIP devices
• Verify VQ against other expected manufacturers
  devices

30
Testing end-to-end VQ of VoIP phones

• The automated VQ test
• Important for verifying VQ under many conditions
• Vary one dimension at a time during subsequent
  test runs
• The manual VQ real user test
• Conduct 2-way calls with real users who are
  familiar with potential echo cancellation and
  other 2-way effects
• Include handset and speakerphone test calls

31
Testing end-to-end VQ of VoIP phones

• Test setup examples
• Softphone to softphone test
• VoIP Phone to VoIP Phone test (in lab)
• VoIP Phone to PSTN call test
• Variations on these themes easily set up
• Wideband codecs used? If so, be sure to verify
  that all test equipment in the audio/media signal
  path can support 8 kHz.

32
Testing Softphone-to-Softphone
Media may flow peer-to-peer or through the VoIP
Network component
PESQ evaluated off-line via batch process
33
Testing VoIP Phone-to-VoIP Phone
Good setup when isolated device performance test
is needed.Phone calls are manually placed with
this setup.
34
Testing VoIP Phone to PSTN calls
35
Example WAN Impairment Conditionsfor VQ
TestConditions suitable for emulation of
overseas Internet dialup conditions
Broadband and Dialup IP bandwidths for each condition below
Packet Loss 0Latency / Jitter 10/30 mSec (uniform distributed latency model)
Packet Loss Random 2.5, Latency / Jitter 10/30 mSec
Packet Loss Burst 5.0, 1-5 packet burst size Latency / Jitter 50/80 mSec
Packet Loss Burst 10.0, 1-8 packet burst size Latency / Jitter 125/250 mSec

36
Watch out for

• Do not try to compare MOS scores derived from
  different sources or evaluation engines
• Even the numeric ranges from worse to best
  can vary (i.e. best 4.5, not 5.0)
• Especially, dont compare passive with active VQ
  results

37
Real-World Next-Gen NetworkProduct Testing
www.ct-labs.com 916-577-2100 Chris
Bajorekchris_at_ct-labs.com916-577-2110 direct line
