Title: PowerPoint Presentation to accompany Hole


1
PowerPoint Presentation to
accompanyHoles Human Anatomy and
Physiology, 9/e
byShier, Butler, and Lewis
2
Chapter 5
  • Tissues

3
Tissues
  • Cells are organized into layers or groups called
    tissues.
  • There are four major tissue types found in the
    body epithelial, connective, muscle, and
    nervous.
  • These tissues associate and interact to form
    organs and specialized functions.

4
Epithelial Tissue
  • Epithelium functions in protection, secretion,
    absorption, and excretion.
  • It is composed of tightly packed cells anchored
    to a basement membrane.
  • Epithelium lacks blood vessels and rapidly
    divides.
  • Epithelial tissues are classified by cell shape
    and number of cell layers.

5
Simple Squamous Epithelium
  • Simple squamous epithelium consists of a single
    layer of thin, flat cells that fit tightly.

Figure 5.1
6
Simple Squamous Epithelium
  • It functions in filtration, diffusion, osmosis,
    and covers surfaces.
  • It is found in air sacs of the lung, walls of
    capillaries, lines blood vessels, and covers the
    membranes that line body cavities.

7
Simple Cuboidal Epithelium
  • Simple cuboidal epithelium consists of a single
    layer of cube-shaped cells.

Figure 5.2
8
Simple Cuboidal Epithelium
  • It functions in secretion and absorption.
  • It is found on the surface of the ovaries,
    linings of kidney tubules, linings of the ducts
    of certain glands.

9
Simple Columnar Epithelium
  • Simple columnar epithelium is a single layer of
    elongated, column-shaped cells.

Figure 5.3
10
Simple Columnar Epithelium
  • It functions in protection, secretion, and
    absorption.
  • It can be ciliated or nonciliated.

11
Simple Columnar Epithelium
  • Specialized goblet cells secrete mucus.
  • It is found lining the uterus, stomach, and
    intestines.

12
Pseudostratified Columnar Epithelium
  • Pseudostratified columnar epithelium is a single
    layer of elongated cells that appears to be more
    than one layer.

Figure 5.5
13
Pseudostratified Columnar Epithelium
  • It is often ciliated and contains goblet cells.
  • It functions in protection, secretion, and
    movement of mucus and cells.
  • It is found lining the respiratory passages.

14
Stratified Squamous Epithelium
  • Stratified squamous epithelium consists of many
    layers of cells with flat cells on the outer
    layers.

Figure 5.6
15
Stratified Squamous Epithelium
  • It functions in protection.
  • It is found in the outer layer of the skin,
    linings of the oral cavity, throat, vagina, and
    anal cavity.

16
Stratified Cuboidal Epithelium
  • Stratified cuboidal epithelium consists of two to
    three layers of cubed-shaped cells.

Figure 5.7
17
Stratified Cuboidal Epithelium
  • It functions in protection.
  • It is found in the linings of the mammary glands,
    sweat glands, salivary glands, and pancreas.

18
Stratified Columnar Epithelium
  • Stratified columnar epithelium consists of a top
    layer of elongated cells, and lower layers of
    cube-shaped cells.

Figure 5.8
19
Stratified Columnar Epithelium
  • It functions in protection and secretion.
  • It is found in the vas deferens, part of the male
    urethra, and parts of the pharynx.

20
Transitional Epithelium
  • Transitional epithelium consists of many layers
    of cube-shaped and elongated cells.

Figure 5.9a
21
Transitional Epithelium
  • It functions in distensibility and protection.
  • It is found in the inner lining of the urinary
    bladder, ureters and part of the urethra.

Figure 5.9b
22
Glandular Epithelium
  • Glandular epithelium is composed of cells that
    produce and secrete substances.
  • Exocrine glands secrete products into ducts.
  • Endocrine glands secrete products into tissue
    fluid or blood.
  • A unicellular exocrine gland is the
    mucous-secreting goblet cell.

23
(No Transcript)
24
Multicellular Glands
  • A simple gland communicates with the surface
    through one unbranched duct.

Figure 5.10
25
Multicellular Glands
  • A compound gland communicates with the surface
    through a branched duct.
  • Tubular glands are epithelial-lined tubes.
  • Alveolar (acinar) glands have saclike endings.

26
Glandular Secretion
  • Merocrine glands release fluid through
    exocytosis. Ex salivary glands.

Figure 5.11
27
Glandular Secretion
  • Apocrine glands release cellular product by
    pinching off the free end of the cell. Ex
    mammary glands.

28
Glandular Secretion
  • Holocrine glands secrete the entire cell full of
    the secretory product. Ex sebaceous glands.

29
Merocrine Secretion
  • Most exocrine glands are merocrine.
  • There are two types of merocrine cells, serous
    and mucous.
  • Serous fluid is watery with a high enzyme
    concentration.
  • Mucous cells secrete a mucus, a thick fluid rich
    in the glycoprotein, mucin.

30
Connective Tissues
  • Connective tissue is the most abundant tissue in
    the body.
  • Extracellular material, matrix, makes up the bulk
    of the tissue.
  • Matrix is composed of fibers and ground
    substance.
  • Connective tissue cells usually can divide.

31
Connective Tissue Cell Types
  • Fibroblasts secrete protein into the matrix.

Figure 5.13
32
Connective Tissue Cell Types
  • Macrophages originate as white blood cells. They
    can move and phagocytize foreign particles.

Figure 5.14
33
Connective Tissue Cell Types
  • Mast cells release heparin, which prevents blood
    clotting, and histamine, which aids in the
    inflammatory response.

Figure 5.15
34
Connective Tissue Fibers
  • Collagenous fibers, white fibers, are made of
    thick threads of collagen. They are strong,
    flexible, and inelastic.

Figure 5.16
35
Connective Tissue Fibers
  • Elastic fibers, yellow fibers, are made of
    bundles of elastin.
  • Reticular fibers are thin,collagenous fibers that
    form branched networks for support.

36
Loose Connective Tissue
  • Loose connective tissue or areolar tissue binds
    organs together and holds tissue fluids.

Figure 5.18
37
Loose Connective Tissue
  • It is cells (fibroblasts) in a fluid-gel matrix.
  • It forms thin membranes found beneath the skin,
    between muscles, and beneath epithelial tissue.

38
Adipose Tissue
  • Adipose tissue protects, insulates, and stores
    fat in droplets inside the cells.

Figure 5.19
39
Adipose Tissue
  • It consists of cells (adipocytes) in a fluid-gel
    matrix.
  • It is found beneath the skin, around the kidneys,
    behind the eyes, and on the heart.

40
Reticular Connective Tissue
  • Reticular connective tissue supports organs.

Figure 5.20
41
Reticular Connective Tissue
  • It is composed of thin, collagenous fibers and
    cells in a fluid-gel matrix.
  • It is found in the walls of the liver, spleen,
    and lymphatic organs.

42
Dense Connective Tissue
  • Dense connective tissue binds organs together.

Figure 5.21
43
Dense Connective Tissue
  • It is composed thick collagenous fibers, thin
    elastic fibers and fibroblasts in a fluid-gel
    matrix.
  • It is found in tendons, ligaments, and the dermis
    of the skin.

44
Elastic Connective Tissue
  • Elastic connective tissue supports, protects, and
    provides a flexible framework.

Figure 5.22
45
Elastic Connective Tissue
  • It consists of elastic fibers and fibroblasts in
    a solid-gel matrix.
  • It connects vertebrae and is found in the walls
    of arteries and airways.

46
Cartilage
  • Cartilage is a rigid connective tissue.
  • The matrix consists of collagenous fibers in a
    gel-like ground substance.
  • Cartilage cells, chondrocytes, are found in small
    chambers, lacunae.
  • Cartilage is covered with a thin layer of
    connective tissue, the perichondrium.
  • Cartilage lacks blood vessels.

47
Cartilage
  • Cartilage cells, chondrocytes, are found in small
    chambers, lacunae.
  • Cartilage is covered with a thin layer of
    connective tissue, the perichondrium.
  • Cartilage lacks blood vessels.

48
Hyaline Cartilage
  • Hyaline cartilage supports, protects, and
    provides a framework.
  • It is the most common type of cartilage.

Figure 5.23
49
Hyaline Cartilage
  • It is found in the ends of bones, nose, and
    rings in the respiratory passages.
  • Hyaline cartilage provides the embryonic model
    for the skeleton.

50
Elastic Cartilage
  • Elastic cartilage supports, protects, and
    provides a flexible framework.

Figure 5.24
51
Elastic Cartilage
  • Its matrix contains many elastic fibers.
  • It is found in the outer ear and part of the
    larynx.

52
Fibrocartilage
  • Fibrocartilage supports, protects, and absorbs
    shock during body movement.

Figure 5.25
53
Fibrocartilage
  • It is the toughest type of cartilage.
  • It is found between the vertebrae (intervertebral
    discs), in the knee and parts of the pelvic
    girdle.

54
Bone
  • Bone supports, protects, provides a framework for
    muscle attachment.

Figure 5.26
55
Bone
  • It is composed of cells (osteocytes) in a hard
    calcified matrix. The osteocytes are located in
    layers, lamellae, organized into osteons.

56
Bone
  • It is found in the skeleton and middle ear.

57
Blood
  • Blood transports gases, nutrients, and wastes,
    defends against disease, and acts in clotting.

Figure 5.27
58
Blood
  • It is composed of cells and platelets in a fluid
    matrix, the blood plasma.
  • It is found within the blood vessels.

59
Muscle Tissue
  • Muscle tissue is contractile.
  • Muscle fibers can shorten and thicken.
  • There are three types of muscle tissue skeletal,
    smooth, and cardiac.

60
Skeletal Muscle
  • Skeletal muscles attach to bones and are
    controlled by conscious effort.

Figure 5.28
61
Skeletal Muscle
  • It is also called voluntary muscle.

62
Skeletal Muscle
  • The muscle cells have many nuclei and exhibit
    light and dark banding patterns called
    striations.
  • Skeletal muscles contract in response to nerve
    signals.

63
Smooth Muscle
  • Smooth muscle appears smooth because it lacks
    striations.
  • Smooth muscle action is not under conscious
    control and it is called involuntary.

Figure 5.29
64
Smooth Muscle
  • The cells are spindle-shaped with a central
    nucleus.
  • Smooth muscle is found in the stomach,
    intestines, uterus, and blood vessels.

65
Cardiac Muscle
  • Cardiac muscle tissue is found only in the heart.

Figure 5.30
66
Cardiac Muscle
  • The striated cells are joined end to end with a
    specialized intercellular junction called an
    intercalated disk.
  • Cardiac muscle is under involuntary control.

Figure 5.30
67
Nervous Tissues
  • Nervous tissues are found in the brain, spinal
    cord, and peripheral neurons.

Figure 5.31
68
Nervous Tissues
  • Nerve cells or neurons sense changes and transmit
    signals.

69
Nervous Tissues
  • Neuroglia are cells that support and bind nervous
    tissue. They supply nutrients, carry on
    phagocytosis, and play a role in cell to cell
    communication.

70
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
