NIKON NPL-332 TOTAL STATION

1
NIKON NPL-332 TOTAL STATION

• CE 201
• ENGINEERING SURVEYING

2
NIKON NPL-332TOTAL STATION

• SETUP INSTRUMENT
• Turn On

• Rotate Alidade

• Tilt Telescope

3
NIKON NPL-332MEASUREMENT SETTINGS

• MSR1 or MSR2
• Hold down key for 1 sec
• Target N-Prism/Prism
• Const 30 mm
• Mode Normal/Precise
• Ave 0 to 99 - 3
• Rec Confirm/All/ MSR

4
NIKON NPL 332INITIAL SETTINGS
MENU
3 Settings

• 1 Angle
• VA Zero Vert 0
• ANG Reso 1/5/10
• HA 0 to BS/AZIMUTH
• 2 Dist
• Scale 1.00000
• T-P On
• Sea Level On
• CR 0.132
• 3 Coord.
• Cord. NEZ/ENZ
• Label XYZ/YXZ/NEZ
• AZ ZERO North
• 4 Power
• Main OFF
• EDM OFF
• Sleep OFF

• 7 Units
• Angle DEG
• Dist US-FT
• Input decimal-Ft
• Temp degF
• Press inHg
• 8Recording
• 9 Other Settings
• XYZ disp
• 2nd Unit
• Sig Beep
• Split St.
• CD Input
• Owner Detail

5
NIKON NPL 332

• HOT KEY
• 1 HT - Input Height of Target
• 2 T-P - Input Temperature Pressure
• 3 Target Prism 30 mm - Prism Offset
• 4 Notes 50 characters
• BUBBLE INDICATOR (0) KEY
• Graphical Check

6
NIKON NPL 332

• MEASURING DISTANCE
• Sight Target
• Press MSR1 or MSR2
• if ave. count 0, cont. measurement
• if ave. count set to gt0 , SDx
• DISPLAY - DSP Key
• toggle between displays
• 1/4, 2/4, 3/4, 4/4

7
NIKON NPL 332

• HORIZONTAL ANGLE
• ANGLE KEY
• 1 0-Set
• 2 Input ddd.mmss
• 3Rept angle repetitions
• 4F1/F2 Face Left/Right
• 5Hold hold horizontal angle

8
NIKON NPL 332

• RDM Remote Distance Measurement
• Indirect Distance Measurement
• PROGRAMS (4 Key)
• CONTINUOUS (4)

9
NIKON NPL 332 Remote Distance Measurement
10
NIKON NPL 332

• DISPLAY
• Sight 1st Pt
• MSR1 or MSR2
• Sight 2nd Pt
• MSR1 or MSR2

MAGNETIC AZIMUTH
11
NIKON NPL 332

• REM REMOTE ELEVATION MEASUREMENT
• PROGRAMS (4 Key)
• REM (5)

12
NIKON NPL 332

• REM REMOTE ELEVATION
• Enter HT Target Height
• Sight Target
• MSR1
• Sight Vertical Point
• Read Vh

13
NIKON NPL 332

• JOB SETUP
• MENU 1 JOB
• OPEN EXISTING JOB - enter
• Or
• CREATE NEW JOB
• 8 Characters - GRP
• Enter Create Job
• Abrt (Soft Key)
• Sett (Soft Key)
• OK (Soft Key)

Current Job
14
NIKON NPL 332

• STATION STN / 7 KEY
• 1 Known
• ST Enter Station Pt -10
• INPUT N,E,Z
• N 1,000.00
• E 1,000.00
• Z 100.00
• HI ________
• CD _______

15
NIKON NPL 332
OLIN

• STATION
• BACK SIGHT
• 2 ANGLE
• BS PT - No Entry
• AZ Mag Azimuth Flag Pole
• SIGHT BS ENT

STATION 10
ENTRANCE
16

• POINT GUIDANCE
• Traverse Points Single Digit
• Instrument/Setup Pts Double Digit
• Sideshots/BM Triple Digits

B-BALL 5
MILLER 3
OLIN 2
ENTRANCE 1
ENTRANCE 7
PARKING 6
17
NIKON NPL 332
OLIN

• Bench Mark Survey
• STN / 7 KEY
• 4 RBM
• Input BM Point (Flag Pole)
• PT 0 - Enter
• N No Entry
• E No Entry
• Z 561.00
• HT ________
• CD FLAG

STATION 10
ENTRANCE

• Sight Benchmark
• MSR
• ENT
• HI ______

18
NIKON NPL-332POINT SURVEY

• SIGHT POINT
• MSR1
• RECORD PT _____
• CD _____
• ENT
• Comments
• Left Cursor Delete Entry
• Right Cursor Overwrite Mode
• Auto Point Advance Next Pt Pt 1

19
NIKON NPL 332
STATION 11

• New Instrument Station
• STN / 7 KEY
• 2 RESECTION
• PT 1ST POINT
• Input Point ENTER
• HT
• Sight 1st POINT
• MSR
• PT 2ND POINT
• Input Point ENTER
• HT
• Sight 2nd POINT
• MSR

B-BALL
MILLER
OLIN
ENTRANCE
PARKING
20
NIKON NPL 332
STATION 11

• New Instrument Station
• (Continued)
• ?N (small number good)
• ?E (small number good)
• ?Z (small number good)
• REC
• ST 11
• HI ______
• CD STATION 11
• BS _____(Default 1st PT)
• ENT

B-BALL
MILLER
OLIN
ENTRANCE
PARKING
