Computer Architecture Embedded Computing

1
Computer Architecture Embedded Computing
2
Recap Multithreaded Processors
Simultaneous Multithreading
Multiprocessing
Superscalar
Fine-Grained
Coarse-Grained
Time (processor cycle)
Thread 1
Thread 3
Thread 5
Thread 2
Thread 4
Idle slot
3
Embedded Computing
Sensor Nets
Cameras
Games
Set-top boxes
Media Players
Printers
Robots
Smart phones
Routers
Aircraft
Automobiles
4
What is an Embedded Computer?

• A computer not used to run general-purpose
  programs, but instead used as a component of a
  larger system. Usually, user does not change the
  computer program (except for manufacturer
  upgrades).
• Example applications
• Toasters
• Cellphone
• Digital camera (some have several processors)
• Games machines
• Set-top boxes (DVD players, personal video
  recorders, ...)
• Televisions
• Dishwashers
• Car (some have dozens of processors)
• Internet router (some have hundreds to thousands
  of processors)
• Cellphone basestation
• .... many more

5
Early Embedded Computing Examples
6
Reducing Cost of Transistors Drives Spread of
Embedded Computing

• When individuals could afford a single
  transistor, the killer application was the
  transistor radio
• When individuals could afford thousands of
  transistors, the killer app was the personal
  computer
• Now individuals can soon afford thousands of
  processors, what will be the killer apps?
• In 2007
• human population growth per day gt200,000
• cellphones sold per day gt2,000,000

7
What is different about embedded computers?

• Embedded processors usually optimized to perform
  one fixed task with software from system
  manufacturer
• General-purpose processors designed to run
  flexible, extensible software systems with code
  from third-party suppliers
• applications not known at design time
• Note, many products contain both embedded and
  general-purpose processors
• e.g., smartphone has embedded processors for
  radio baseband signal processing, and
  general-purpose processors to run third-party
  software applications

8
Lesser emphasis on software portability in
embedded applications

• Embedded systems
• can usually recompile/rewrite source code for
  different ISA, and/or use assembler code for new
  application-specific instructions
• processor pipeline microarchitecture and memory
  capacity and hierarchy known to
  programmer/compiler
• mix of tasks known to writer of each task,
  usually static uses custom run-time system
• each task usually trusts others, can run in
  same address space
• General-purpose systems
• must have standard binary interface for
  third-party software
• compiler doesnt know about this particular
  microarchitecture or memory capacity or hierarchy
  (compiled for general model)
• unknown mix of tasks, tasks dynamically added and
  deleted from mix uses general-purpose operating
  system
• tasks written by various third-parties, mutually
  distrustful, need separate address spaces or
  protection domains

9
Embedded application requirements constraints

• Real-time performance
• hard real-time if deadline missed, system has
  failed (car brakes!)
• soft real-time missing deadline degrades
  performance (skipping frames on DVD playback)
• Real-world I/O with multiple concurrent events
• sensor and actuators require continuous I/O
  (cant batch process)
• non-deterministic concurrent interactions with
  outside world
• Cost
• includes cost of supporting structures,
  particularly memory
• static code size very important (cost of ROM/RAM)
• often ship millions of copies (worth engineer
  time to optimize cost down)
• Power
• expensive package and cooling affects cost,
  system size, weight, noise, temperature

10
What is Performance?

• Latency (or response time, or execution time)
• time to complete one task
• Bandwidth (or throughput)
• tasks completed per unit time

11
Performance Measurement

• Average rate A gt B gt C
• Worst-case rate A lt B lt C

Which is best for desktop performance?
_______ Which is best for hard real-time task?
_______
12
Processors for real-time software

• Simpler pipelines and memory hierarchies make it
  easier (possible?) to determine the worst-case
  execution time (WCET) of a piece of code
• Would like to guarantee task completed by
  deadline
• Out-of-order execution, caches, prefetching,
  branch prediction, make it difficult to determine
  worst-case run time
• Have to pad WCET estimates for unlikely but
  possible cases, resulting in over-provisioning of
  processor (wastes resources)

13
Power Measurement
I
V

• Energy measured in Joules
• Power is rate of energy consumption measured in
  Watts (Joules/second)
• Instantaneous power is Volts Amps
• Battery Capacity Measured in Joules
• 720 Joules/gram for Lithium-Ion batteries
• 1 instruction on Intel XScale processor takes
  1nJ
• ? 1 billion executed instructions weigh 1mg

14
Power versus Energy
Peak A
Integrate power curve to get energy
Peak B
Power
Time

• System A has higher peak power, but lower total
  energy
• System B has lower peak power, but higher total
  energy

15
Power Impacts on Computer System

• Energy consumed per task determines battery life
• Second order effect is that higher current draws
  decrease effective battery energy capacity
  (higher power also lowers battery life)
• Current draw causes IR drops in power supply
  voltage
• Requires more power/ground pins to reduce
  resistance R
• Requires thickwide on-chip metal wires or
  dedicated metal layers
• Switching current (dI/dt) causes inductive power
  supply voltage bounce ? LdI/dt
• Requires more pins/shorter pins to reduce
  inductance L
• Requires on-chip/on-package decoupling
  capacitance to help bypass pins during switching
  transients
• Power dissipated as heat, higher temps reduce
  speed and reliability
• Requires more expensive packaging and cooling
  systems
• Fan noise
• Laptop/handheld case temperature

16
Power Dissipation in CMOS
Short-Circuit Current
Diode Leakage Current
CapacitorCharging Current
CL
Gate Leakage Current
Subthreshold Leakage Current

• Primary Components
• Capacitor Charging (85 of active power)
• Energy is 1/2 CV2 per transition
• Short-Circuit Current (10 of active power)
• When both p and n transistors turn on during
  signal transition
• Subthreshold Leakage (dominates when inactive)
• Transistors dont turn off completely, getting
  worse with technology scaling
• For Intel Pentium-4/Prescott, around 60 of power
  is leakage
• Optimal setting for lowest total power is when
  leakage around 30-40
• Gate Leakage (becoming significant)
• Current leaks through gate of transistor
• Diode Leakage (negligible)
• Parasitic source and drain diodes leak to
  substrate

17
Reducing Switching Power

• Power ? activity 1/2 CV2 frequency
• Reduce activity
• Reduce switched capacitance C
• Reduce supply voltage V
• Reduce frequency

18
Reducing Activity

• Bus Encodings
• choose encodings that minimize transitions on
  average (e.g., Gray code for address bus)
• compression schemes (move fewer bits)
• Remove Glitches
• balance logic paths to avoid glitches during
  settling
• use monotonic logic (domino)

19
Reducing Switched Capacitance

• Reduce switched capacitance C
• Different logic styles (logic, pass transistor,
  dynamic)
• Careful transistor sizing
• Tighter layout
• Segmented structures

20
Reducing Frequency

• Doesnt save energy, just reduces rate at which
  it is consumed
• Some saving in battery life from reduction in
  rate of discharge

21
Reducing Supply Voltage

• Quadratic savings in energy per transition BIG
  effect
• Circuit speed is reduced
• Must lower clock frequency to maintain correctness

22
Voltage Scaling for Reduced Energy

• Reducing supply voltage by 0.5 improves energy
  per transition to 0.25 of original
• Performance is reduced need to use slower clock
• Can regain performance with parallel architecture
• Alternatively, can trade surplus performance for
  lower energy by reducing supply voltage until
  just enough performance
• Dynamic Voltage Scaling

23
Just Enough Performance

• Save energy by reducing frequency and voltage to
  minimum necessary (usually done in O.S.)

24
Voltage Scaling on Transmeta Crusoe TM5400
Frequency (MHz) Relative Performance () Voltage (V) Relative Energy () Relative Power ()
700 100.0 1.65 100.0 100.0
600 85.7 1.60 94.0 80.6
500 71.4 1.50 82.6 59.0
400 57.1 1.40 72.0 41.4
300 42.9 1.25 57.4 24.6
200 28.6 1.10 44.4 12.7
25
Chip energy versus frequency for various supply
voltages
MIT Scale Vector-Thread Processor, TSMC 0.18µm
CMOS process, 2006
26
Chip energy versus frequency for various supply
voltages
2x Reduction in Supply Voltage
4x Reduction in Energy
MIT Scale Vector-Thread Processor, TSMC 0.18µm
CMOS process, 2006
27
Parallel Architectures Reduce Energy at Constant
Throughput

• 8-bit adder/comparator
• 40MHz at 5V, area 530 km2
• Base power, Pref
• Two parallel interleaved adder/compare units
• 20MHz at 2.9V, area 1,800 km2 (3.4x)
• Power 0.36 Pref
• One pipelined adder/compare unit
• 40MHz at 2.9V, area 690 km2 (1.3x)
• Power 0.39 Pref
• Pipelined and parallel
• 20MHz at 2.0V, area 1,961 km2 (3.7x)
• Power 0.2 Pref
• Chandrakasan et. al. Low-Power CMOS Digital
  Design,
• IEEE JSSC 27(4), April 1992

28
CS252 Administrivia

• Next project meetings Nov 12, 13, 15
• Should have interesting results by then
• Only three weeks left after this to finish
  project
• Second midterm Tuesday Nov 20 in class
• Focus on multiprocessor/multithreading issues
• Well assume youll have worked through practice
  questions

29
Embedded memory hierarchies

• Scratchpad RAMs often used instead, or as well
  as, caches
• RAM has predictable access latency, simplifies
  execution time analysis for real-time
  applications
• RAM has lower energy/access (no tag access or
  comparison/multiplexing logic)
• RAM is cheaper than same size cache (no tags or
  cache logic)
• Typically no memory protection or translation
• Code uses physical addresses
• Often embedded processors will not have direct
  access to off-chip memory (only on-chip RAM)
• Often no disk or secondary storage (but printers,
  iPods, digital cameras, sometimes have hard
  drives)
• No swapping or demand-paged virtual memory
• Often, flash EEPROM storage of application code,
  copied to system RAM/DRAM at boot

30
Reconfigurable lockable caches

• Many embedded systems allow cache lines to be
  locked in cache to provide RAM-like predictable
  access
• Lock by set
• E.g., in an 8KB direct-mapped cache with 32B
  lines (213/2528256 sets), lock half the sets,
  leaving a 4KB cache with 128 sets
• Have to flush entire cache before changing
  locking by set
• Lock by way
• E.g., in a 2-way cache, lock one way so it is
  never evicted
• Can quickly change amount of cache that is locked
  (doesnt change cache index function)
• Can be used in both instruction and data caches
• Lock instructions for interrupt handlers
• Lock data used by handlers

31
Code Size

• Cost of memory big factor in cost of many
  embedded systems
• RISC core about same size as 16KB of SRAM

• Techniques to reduce code size
• Variable length and complex instructions
• Compressed Instructions
• Compressed in memory then uncompressed in cache
• compressed in cache

32KB
32KB
Intel Xscale (2001) 16.8mm2 in 180nm
32
Embedded Processor Architectures

• Wide variety of embedded architectures, but
  mostly based on combinations of techniques
  originally pioneered in supercomputers
• VLIW instruction issue
• SIMD/vector instructions
• Multithreading
• VLIW more popular here than in general-purpose
  computing
• Binary code compatibility not as important,
  recompile for new configuration OK
• Memory latencies are more predictable in embedded
  system hence more amenable to static scheduling
• Lower cost and power compared to out-of-order ILP
  core.

33
System-on-a-Chip Environment

• Often, a single chip will contain multiple
  embedded cores with multiple private or shared
  memory banks, and multiple hardware accelerators
  for application-specific tasks
• Multiple dedicated memory banks provide high
  bandwidth, predictable access latency
• Hardware accelerators can be 100x higher
  performance and/or lower power than software for
  certain tasks
• Off-chip I/O ports have autonomous data movement
  engines to move data in and out of on-chip memory
  banks
• Complex on-chip interconnect to connect cores,
  RAMs, accelerators, and I/O ports together

34
Block Diagram of Cellphone SoC(TI OMAP 2420)
35
Classic DSP Processors
36
TI C6x VLIW DSP
VLIW fetch of up to 8 operations/instruction
Dual symmetric ALU/Register clusters (each
4-issue)
37
TI C6x regfile/ALU datapath clusters
32b/40b arithmetic
32b arithmetic, 32b/40b shifts
16b x 16b multiplies
32b arithmetic, address generation
38
Intel IXP Network Processors
RISC Control Processor
Network 10Gb/s
Buffer RAM
DRAM0
Buffer RAM
DRAM1
Buffer RAM
DRAM2
Buffer RAM
SRAM0
Buffer RAM
Buffer RAM
SRAM1
Buffer RAM
SRAM2
SRAM3
16 Multithreaded microengines
39
Programming Embedded Computers

• Embedded applications usually involve many
  concurrent processes and handle multiple
  concurrent I/O streams
• Microcontrollers, DSPs, network processors, media
  processors usually have complex, non-orthogonal
  instruction sets with specialized instructions
  and special memory structures
• poor compiled code quality ( peak with compiled
  code)
• high static code efficiency
• high MIPS/ and MIPS/W
• usually assembly-coded in critical routines
• Worth one engineer year in code development to
  save 1 on system that will ship 1,000,000 units
• Assembly coding easier than ASIC chip design
• But much room for improvement

40
Discussion Memory consistency models

• Discussion Memory consistency models
• Tutorial on consistency models Mark Hills
  position paper
• Conflict between simpler memory models and
  simpler/faster hardware
