Analysis of frequency counts with Chi square

1
Analysis of frequency counts with Chi square

• Dr David Field

2
Summary

• Categorical data
• Frequency counts
• One variable chi-square
• testing the null hypothesis that frequencies in
  the sample are equally divided among the
  catgegories
• varying the null hypothesis
• Two variable chi-square
• testing the null hypothesis that status on one
  categorical variable is independent from status
  on another categorical variable
• Limitations and assumptions of chi-square
• Andy Field chapter 18 covers chi-square
• There is also a guide online at
• http//davidmlane.com/hyperstat/
• Chi-square is topic 16 in the list

3
Categorical data
18.2

• Each participant is a member of a single
  category, and the categories cannot be
  meaningfully placed in order
• e.g., nationality French, German, Italian
• Sometimes chi-square is used with ordered
  categories, e.g. age bands
• To perform statistical tests with categorical
  data each participant must be a member of only
  one category
• Category membership must be mutually exclusive
• You cant be a smoker and a non-smoker
• This allows frequency counts in each category to
  be calculated

4
Chi square

• If you can express the data as frequency counts
  in several categories, then chi square can be
  used to test for differences between the
  categories
• You will also see chi square written as a Greek
  letter accompanied by the mathematical symbol
  indicating that a number should be squared

5
Chi square with a single categorical variable

• Suppose we are interested in which drink is most
  popular
• We ask a sample of 100 people if they prefer to
  drink coffee, tea, or water
• each respondent is only allowed to select one
  answer
• this is important if each person can have
  membership of more than one category you cant
  use Chi square
• By default, the null hypothesis for chi-square is
  that each of the categories is equally frequent
  in the underlying population
• it is possible to modify this (see later)

6
One variable chi-square example

• Lets say that the preferences expressed by the
  sample of 100 people result in the following
  observed frequency counts
• tea 39
• coffee 30
• Water 31
• SUM 100
• The null hypothesis assumes that each category is
  equally frequent, and thus provides a model that
  the data can be used to test
• Based on the null hypothesis, the expected
  frequency counts would 100 / 3 33.3 per
  category
• The Chi square statistic works out the
  probability that the observed frequencies could
  be obtained by random sampling from a population
  where the null hyp is true

7
One variable chi-square example
Observed Expected Difference Difference squared Divide by expected
39 33.3
30 33.3
31 33.3
100 100

8
One variable chi-square example
Observed Expected Difference Difference squared Divide by expected
39 33.3 5.7
30 33.3 -3.3
31 33.3 -2.3
100 100

9
One variable chi-square example
Observed Expected Difference Difference squared Divide by expected
39 33.3 5.7 32.49
30 33.3 -3.3 10.89
31 33.3 -2.3 5.29
100 100

10
One variable chi-square example
Observed Expected Difference Difference squared Divide by expected
39 33.3 5.7 32.49 0.98
30 33.3 -3.3 10.89 0.33
31 33.3 -2.3 5.29 0.16
100 100

11
One variable chi-square example
Observed Expected Difference Difference squared Divide by expected
39 33.3 5.7 32.49 0.98
30 33.3 -3.3 10.89 0.33
31 33.3 -2.3 5.29 0.16
100 100 SUM 1.47

12
Converting Chi square to a p value

• SPSS will do this for you
• Chi square has degrees of freedom equal to the
  number of categories minus 1
• 2 in the example this is because if you knew the
  frequencies of preference for tea and coffee and
  the sample size, the frequency of preference for
  water would not be free to vary
• The chi square value of 1.47, df 2 had an
  associated p value of 0.48, so the null
  hypothesis that preferences for drinking tea,
  coffee and water in the population are equal
  cannot be rejected.

13
One variable chi square with unequal expected
frequencies

• By default, the expected frequencies are just the
  sample size divided equally among the number of
  categories.
• But, sometimes this is inappropriate
• For example, we know that the of the population
  of the UK that smokes is less than 50
• Lets assume for purposes of illustration that
  25 of the UK population are smokers
• We might hypothesise that the smoking rate is
  higher in Glasgow than the UK average rate
• The null hypothesis is that it is the same

14
One variable chi square with unequal expected
frequencies

• We ask 200 adults in Glasgow if they smoke.
• 80 say yes
• 120 say no
• We know that the UK average rate is 25, and 80
  is rather more than 25 of 200
• Chi square can be used to assess the probability
  of the above frequencies being obtained by random
  sampling if the real smoking rate in Glasgow was
  actually 25

15
One variable chi-square example with unequal
expected frequencies
Observed Expected Difference Difference squared Divide by expected
120 150 -30 900 6
80 50 30 900 18
200 200 SUM 24
16
One variable chi square with unequal expected
frequencies

• 80 of the sample of 200 people from Glasgow
  classified themselves as smokers. This resulted
  in a chi square value of 24.0, df 1 with an
  associated p value of lt 0.001, so the null
  hypothesis that smoking rates in Glasgow are
  equal to the UK average of 25 can be rejected.

17
Chi square with two variables
18.3

• Usually, it is more interesting to use Chi square
  to ask about the relationship between 2
  categorical variables.
• For example, what is the relationship between
  gender and smoking?
• gender can be male or female
• smoking can be smoker or non-smoker
• If you have smoking data from just men, you can
  only use chi-square to ask if the proportion of
  smokers and non-smokers is different
• If you have smoking data from men and women you
  can use chi-square to ask if the proportion of
  men who smoke differs from the proportion of
  women who smoke

18
What 22 chi square does not do

• It is important to realise that in the 22 chi
  square, having a big imbalance between the number
  of men and the number of women will not increase
  the value of the chi-square statistic
• Also, having a big imbalance between the number
  of smokers and non-smokers will not increase the
  value of the chi-square statistic
• This contrasts with the one variable chi-square,
  where an imbalance in the numbers of men vs
  women, or smokers vs. non-smokers does increase
  the value of chi-square.
• The value of chi-square for two variables is high
  if smoking frequency is contingent on gender, and
  low if smoking frequency is independent of gender

19

• The key to understanding 22 chi square is how
  the expected frequencies are calculated
• The expected frequencies provide the null
  hypothesis, or null model, that the chi square
  statistic tests
• If there are 200 participants, the simplest null
  model would be to expect 50 female smokers, 50
  male smokers, 50 female non smokers, and 50 male
  non smokers
• but we already know that it is implausible to
  expect an equal split of smokers and non-smokers
• the expected frequencies will have to allow for
  the imbalance of smokers vs non smokers and a
  possible imbalance of men vs women in the sample
• A sample with 20 male smokers, 10 female smokers,
  80 male non-smokers and 40 female non-smokers has
  an imbalance of gender and smoking status, but
  smoking status does not depend on gender and
  there is no deviation from the null model

20
The contingency table of observed frequencies
Men Women Row totals
Smoke 13 31 44

Dont smoke 29 86 115

Column totals 42 117 159
21
Calculating the expected frequencies

• The key step in the calculation of chi-square is
  to estimate the frequency counts that would occur
  in each cell if the null hypothesis that the row
  frequencies and column frequencies do not depend
  upon each other were true
• To calculate the expected frequency of the male
  smokers cell, we first need to calculate the
  proportion of participants that are male, without
  considering if they smoke or not
• This proportion is 42 males out of 159 (the total
  number of participants)
• 42 / 159 0.26

22
Calculating the expected frequencies

• If the null hyp is true, and the proportion of
  female smokers and male smokers is equal, then
  the proportion of the smokers in the sample that
  are male should be equal to the overall
  proportion of the sample that is male
• Total number of smokers in sample (44)
  proportion of sample that is male (0.26)
• 44 0.26 11.62

23
Calculating the expected frequencies
Men Women Row totals
Smoke 13 31 44
Expected smokers 11.62
Dont smoke 29 86 115
Expected non smoke
Column totals 42 117 159
24
Calculating the expected frequencies
Men Women Row totals
Smoke 13 31 44
Expected smokers 11.62 32.37
Dont smoke 29 86 115
Expected non smoke
Column totals 42 117 159
0.74
25
Calculating the expected frequencies
Men Women Row totals
Smoke 13 31 44
Expected smokers 11.62 32.37
Dont smoke 29 86 115
Expected non smoke 30.37
Column totals 42 117 159
26
Calculating the expected frequencies
Men Women Row totals
Smoke 13 31 44
Expected smokers 11.62 32.37
Dont smoke 29 86 115
Expected non smoke 30.37 84.62
Column totals 42 117 159
27
Calculating the value of chi square

• Each cell in the contingency table makes a
  contribution to the total chi-square
• For each cell you calculate
• (Observed Expected) and square it
• You then divide by the Expected
• Do this for each cell individually and add up the
  results

28
Calculating chi square
Men Women Row totals
Smoke 13 31 44
Expected smokers 11.62 32.37
Dont smoke 29 86 115
Expected non smoke 30.37 84.62
Column totals 42 117 159
(13-11.62)2 1.90 1.90 / 11.62 0.16
29
Converting chi-square to a p value

• The degrees of freedom for a two way Chi square
  depends upon the number of categories in the
  contingency table
• (num columns -1) (num rows -1)
• SPSS will calculate the DF and p value for you
• The chi square value of 0.31, df 1 had an
  associated p value of 0.58, so the null
  hypothesis that the proportion of men and women
  that smoke is equal cannot be rejected.
• Also see

18.5.7
30
Larger contingency tables

• You can perform chi-square on larger contingency
  tables
• For example, we might be interested in whether
  the proportion of smokers vs. non smokers differs
  according to age, where age is a 3 level
  categorical variable
• 20-29 years old
• 30-39 years old
• 40-49 years old
• This results in a 2 3 contingency table
• However, there is some uncertainty as to what a
  significant chi-square means in this case

31
Partitioning chi-square

• A statistically significant 2 3 chi-square
  might have occurred for one of these 3 reasons
• The proportion of 20-29 year olds who smoke
  differs from the proportion of 30-39 year olds
  that smoke
• The proportion of 20-29 year olds that smoke
  differs from the proportion of 40-49 year olds
  that smoke
• The proportion of 30-39 year olds that smoke
  differs from the proportion of 40-49 year olds
  that smoke
• Or all 3 of the above might be true
• Or 2 of the above might be true
• As a researcher, you will want to distinguish
  between these possibilities

32
Partitioning chi-square

• The solution is to break the 2 3 contingency
  table into smaller 2 2 contingency tables to
  test each of the comparisons in the list
• The proportion of 20-29 year olds who smoke
  differs from the proportion of 30-39 year olds
  that smoke
• The proportion of 20-29 year olds that smoke
  differs from the proportion of 40-49 year olds
  that smoke
• The proportion of 30-39 year olds that smoke
  differs from the proportion of 40-49 year olds
  that smoke
• Run 3 separate 2 2 chi-square tests

33
Partitioning chi-square

• However, running 3 tests results in 3 chances of
  a type 1 error occurring
• To maintain the probability of a type 1 error at
  the conventional level of 5 you divide the alpha
  level by the number of chi-square tests you run
• Effectively, you share the 5 risk of rejecting
  the null hypothesis due to sampling error equally
  among the tests you perform
• For a single chi-square, it is significant if
  SPSS reports that p is less than 0.05
• For two chi-square tests, they are significant at
  the 0.05 level individually if SPSS reports that
  p is less than 0.025
• For three chi-square tests, they are significant
  at the 0.05 level individually if SPSS reports
  that p is less than 0.0166

34
Warnings about chi-square

• The expected frequency count in any cell must not
  be less than 5
• If this occurs then chi-square is not reliable
• If the contingency table is 2 2 or 2 3 you
  can use the Fisher exact probability test instead
• SPSS will report this
• For bigger contingency tables the only solution
  is to collapse across categories, but only
  where this is meaningful
• If you began with age categories 0-4, 5-10,
  11-15, 16-20 you could collapse to 0-10 and
  11-20, which would increase the expected
  frequencies in each cell
• Finally, remember that the total of frequencies
  is equal to the number of participants you have
• each person must only be a member of one cell in
  the table
