Key benefits

• usage with protective glass up to 1cm thickness
• multi-touch function
• usage with gloves (latex, leather, rubber)
• maximising the range of utilisation
• high transmission ratio of 90
• automatic calibration drift compensation
  (freely definable)
• extended temperature range (-20C...70C)
• excellent EMC and EMI behaviour
• high flexibility integrating the touch controller
• low power consumption (5V x 20mA) independent of
  the size of the touch panel

2
3
Function

• The touch sensor consists of a multilayer
  ITO-foil(indium tin oxide)
• Couples of electrodes generate an electrical
  field.
• When a finger touches the panel the field
  coupling will change. The controller will
  detected the change and calculate the position.

4
Definition of the touch-area

• X and Y-lines are defining the touch area
  (matrix-structure).
• The numbers of measuring points is defined by the
  numbers of X- and Y-lines. E.g. 8 x 6 48 or 18
  x12 216 (depending on the controller and the
  design of the foil).
• By interpolation a theoretical resolution of 1024
  x 1024 is possible (10bit).
• The sensitivity of the touch could be adjusted by
  software.

5
Structure of Touch-Sensor
8.0
lt 8.0
6
Integration overview
7
Integration Mouse-Driver (easyTouch controller)
configuration-tool
customer application
USB
operation system
(Windows, XP, Vista, 7, CE, Linux)
API
X1,Y1 coordinates
Touch-Panel
easyTouch controlleror stamp and stamp master
driver
X1,Y1, X2,Y2 coordinates settings
CPU

• Interface only USB
• Touch Function
• 1 Finger (Mouse Function), 2 finger usage
  (gestures) possible via API
• 2 Finger usage (Win 7)
• Data Modul provides Mouse-Driver, API and
  configuration-tool for all common operating
  systems (Windows, XP, 7, CE (5.0, 6.0), Vista,
  Linux,)
• Easy calibration and linearization by software

8
Integration I²C (Chip-Integration on
custom-board)MOQ 5k pcs
configuration-tool
customer application
operation system
Atmel-Chip or stamp
I²C
Touch-Panel
driver
X,Y coordinates settings
Custom board
CPU

• No operating system necessary
• Interface I²C only
• Touch-Function real Multi-Touch-Function
• Customer has to take care of the chip integration
  by himself. Data Modul will provide an
  application note.
• Customer has to sign a NDA to get a
  protocolNDA_easyTouch S\Displaytechnik\Touch_Ea
  sy\Specifications\Controller\Atmel-Controller
  (single Chip)

9
Integration Windows 7 with DigitizerMOQ 5k pcs
customer application
Operationsystem
MS Touch-Kit
Mouse
USB
(Windows 7)
Touch-Panel
easyTouch controller orstamp stamp master
Multi-Touch
Digitizer-Daten
CPU

• Touch-Function 2 Finger Mouse Function, ,
  Multi-Touch via MS-Touch-Kit
• Windows 7 only
• Data Modul provides a configuration-tool to
  adjust the settings during the development phase
• For the MP, the touch controller could be
  preinstalled (e.g. sensibility) according to the
  requirements of the customer.

10
Sizes
10
11
Options of easyMaxTouch-Controller
Touch-Chip
USB-Chip
Touch-Panel
USB Connector
Connector
USB
1
easy(Max)Touch Controller
Touch-Chip
I²C
USB-Chip
Touch-Panel
USB Connector
Connector
2
USB
Stamp
Stamp Master
Touch-Chip
I²C
USB-Chip
Touch-Panel
Connector
3
USB
Stamp
Stamp Master
12
Options of easyMaxTouch-Controller
Touch-Chip
Touch-Panel
Connector
4
I²C
Stamp
I²C
Touch-Chip
Mikro-processor
Touch-Panel
Connector
5
SPI
Stamp
Stamp Master

• Advantage of the stamp concept
• Atmel touch chip is an BGA (ball grid array with
  a pitch of 0,65mm -gt difficult to solderStamp is
  easy to solder on the PCB board of the customer
• Stamp is logistic wise easy to handle (no MOQ)
• Flexible integration of the stamp on customers PCB

13
Controller overview
13
14
Sizes / outlook
NOW
Q211
Q410
Q411
MXT-224 14Y x 16X
18C11 6Y x 8X
MXT-768 24Y x 32X
OAKWOOD 42Y x 33X
XXX- WOOD
Single Chip solution with 3 Maxtouch
Same features like the MXT-224. More XY lines

• Next steps
• Atmel-Controller OAKWOOD, resolution 42x33
• Board Q4/2010
• Touch-sizes 15, 15.4 (15.6) 19 Q4/2010

Single Chip solution with 3 MXT-768
15
easyTouch driver and configuration tool

•
  Win XP / 7
• driver READY NOW
• API 2 Finger Touch and EEPROM r/w functionality
  READY NOW
• Configuration Tool to define sensitivity READY
  NOW
•
  LINUX
• driver READY NOW
• API 2 Finger Touch and EEPROM r/w functionality
  READY NOW
• Configuration Tool NOT PLANNED (customer could
  integrate API in its SW)
•
  WIN CE5.0 / 6.0
• driver READY END OF AUGUST
• API 2 Finger Touch and EEPROM r/w functionality
  READY END OF August
• Configuration Tool NOT PLANNED (customer could
  integrate API in its SW)

16
General advice when setup easyTouch

• Fixation of the easyTouch sensor on a table with
  adhesive tape (Tesa)
• Install the driver software first, then connect
  the hardware(check for latest driver updates on
  our website (support -gtdriver)
• Please note that the touch-cable is connected
  correctly
• Pay attention that the power supply is grounded,
  the computer runs by a battery or LAN-cable is
  connected to the computer
• Noise suppression could be done by Data Modul if
  the customer provides the complete system

16
17
Usage of a front foil
When using a front foil the foil must always
laminated on the touch or a glass to avoid air
gaps and malfunction
18
Mounting proposal
19
For further details, please contact Stefan
Worlitzer Produktmarketing sworlitzer_at_data-modul.
