Title: Computer Systems


1
COM509 Computer Systems
Lecture 2. Chipset and PCIe
Prof. Taeweon Suh Computer Science
Education Korea University
2
x86-based Computer System
CPU
Main Memory (DDR2)
FSB (Front-Side Bus)
North Bridge
Graphics card
South Bridge
Hard disk
BIOS ROM
USB
PCIe card
3
Q35 Chipsets System Block Diagram
4
Chipsets
  • Chipsets include MCH and ICH in the x86-based
    system
  • There are PCIe devices inside the MCH and the ICH
  • Backbone of MCH and ICH is based on PCI express
  • Q35 (North Bridge)
  • Device 0 Function 0
  • DRAM Controller Registers
  • Device 1 Function 0
  • PCIe Registers associated with x16 root port
  • Device 2 Function 0, 1
  • Integrated Graphics Devices Registers
  • Device 3 Function 0, 1, 2, 3
  • Intel Management Engine (ME) subsystem registers

5
Chipsets
  • ICH9 (South Bridge)
  • D30F0
  • PCI-to-PCI Bridge Register
  • D31F0
  • LPC (Low Pin Count) Interface Bridge Registers
  • D31F2
  • SATA (Serial ATA) Controller Registers
  • D31F3
  • SMBus Controller Registers
  • .

6
PCI Express
  • 3rd generation high-performance I/O bus
  • Used to interconnect peripheral devices
  • Point-to-point connection as opposed to bus
  • PCIe interconnect consists of either a x1, x2,
    x4, x8, x12, x16 or x32 point-to-point link
  • if you have x16 link, there are 64 physical lines
    (16 2 (both directions) 2 (differential
    signaling))
  • 1st generation
  • ISA, EISA, VESA and Micro Channel buses
  • 2nd generation
  • PCI, PCI-X, and AGP

7
PCI Express
8
PCI Bus Based Platform
9
PCIe-based System Topology
  • Root Complex
  • Denote the root of I/O hierarchy that connects
    the CPU/memory subsystem to the I/O
  • May support one or more PCIe ports as shown
  • Endpoint
  • devices other than root complex and switches that
    are requesters or completers of PCIe transactions

Souce PCIe specification 2.0
10
PCIe Example Topology
  • Switch
  • Can be thought of as consisting of 2 or more
    logical PCI-to-PCI bridges
  • One port of a switch pointing in the direction of
    the root complex is an upstream port
  • All other ports pointing away from the root
    complex are downstream ports

Souce PCIe specification 2.0
11
PCIe Topology
12
PCIe Address Space
  • PCIe supports the same address spaces as PCI
  • Memory space
  • IO space
  • Configuration space
  • PCIe provides a 4KB space per a function as
    opposed to 256B in PCI
  • PCIe support up to 256 buses, 32 devices, and 8
    functions

13
PCIe Configuration Registers
14
PCIe Configuration Registers
15
PCIe Configuration Registers
16
PCIe Configuration Registers
  • Vendor ID
  • Identify the manufacturer of the function
  • The value is assigned by a central authority (PCI
    SIG) that controls issuance of the numbers
  • Device ID
  • Assigned by the function manufacturer
  • Identify the type of the function

17
PCIe Configuration Registers
  • Class code

18
How to Access Configuration Registers?
  • In x86-based platform, there are 2 ways to access
    configuration registers
  • I/O transaction with 0xcf8 and 0xcfc
  • PCI compatible configuration mechanism
  • 0xcf8 and 0xcfc are IO port addresses implemented
    within root complex
  • It means you have to use in or out
    instructions in x86
  • 0xcf8 Configuration address port
  • 0xcfc Configuration data port

19
How to Access Configuration Registers?
  • MMIO (Memory-Mapped IO) transaction
  • Each functions 4KB config. space starts at a
    4KB-aligned address with the 256MB memory space
    set aside as configuration space
  • For example, you can use mov instruction in x86
    to access the config. space

20
PCIe Memory Space
21
PCIe I/O Space
22
PCIe Transaction Routing
23
PCIe Transaction Routing
TLP Transaction Layer Packet
24
PCIe Transaction Routing
25
PCIe Transaction Routing
26
PCIe Transaction Routing
27
PCIe Transaction Routing
28
PCIe Transaction Routing
29
PCIe Transaction Routing
30
PCIe Transaction Routing
31
PCIe Enumeration
  • At power up time, the configuration software only
    knows of the existence of bus 0
  • Bus 0 is the bus that resides on the downstream
    side of the Host/PCI bridge
  • The configuration S/W does not even know what
    devices reside on bus 0
  • So how does the system discover the various
    buses, devices, and functions on the computer
    system?
  • Answer Via the enumeration process
  • BIOS is doing the enumeration

32
PCIe Enumeration
33
PCIe Enumeration
34
Example Before PCIe Enumeration
35
PCIe Enumeration Process
36
PCIe Enumeration Process
37
PCIe Enumeration Process
38
PCIe Enumeration Process
39
PCIe Enumeration Process
40
PCIe Enumeration Process

41
Example After PCIe Enumeration
