Storing and Organizing Data

1
Storing and Organizing Data
2
Why Do I Need to Understand How Data Is
Represented?

• In order to install, program,maintain, and
  troubleshoot todays PLCs, you must understand
  the different methods by which internal data is
  represented.

3
Objectives

• Identify the commonly used number systems used in
  PLCs.
• Convert binary data to decimal.
• Examine how data is stored in PLC data tables.
• Describe how BCD field devices interface.

4
PLC Words

• One measure of a computers capabilities is the
  length of the data words on which it can operate.
• Many current PLCs use 16-bit words.
• Many newer PLCs use 32-bit words.
• SLC 500 and PLC 5 family PLCs are 16-bit
  computers.
• Control Logix is a 32-bit computer.

5
Number Systems Typically Used with PLCs
6
We Use Words to Represent Information

• Our words are groups of characters grouped
  together to represent something.
• The words we use are of different lengths.
• Controller
• The
• Monday

7
We Use Symbols Called Numbers to Represent Data

• Everyday numbers are decimal.
  12,345

8
Computers Do Not Understand

• Computers do not understand the words and numbers
  humans use.
• Computers have their own language called binary.

9
Binary Concept

• Two-state devices are described as either
  discrete or digital devices.
• Discrete or digital devices are simply either on
  or off.
• Binary is based on two states, on or off.

10
Binary Language

• Binary information is also represented in groups
  of characters.
• A group of binary digits called bits can be
  organized into words.
• Binary bits consist of only two characters
• 1 and 0

11
Binary Words

• 16 bits grouped together is called a word.
• A binary word might look like
• 1010 1010 1010 1010 1010

12
Information Represented as Combinations of Bits
13
Decimal Numbers

• Ten digits
• 0,1,2,3,4,5,6,7,8,9
• Base or radix
• 10
• Weights
• 1, 10, 100, 1000

14
Decimal Number System
15
The Binary Number System Has the Following
Characteristics

• Two digits
• 0 or 1
• Base or radix
• 2
• Weights
• 1, 2, 4, 8, 16, 32, 64

16
16-bit Binary Word Bit Weighting

• MSB LSB
• LSB least significant bit
• MSB most significant bit

17
Binary Numbers Place Values
18
Binary Number Weighting
19
Decimal 0 through 7 Represented with Binary Bits
20
Comparison of Decimal to Binary Numbers
21
Parts of a 16-bit Word
22
Bytes, Nibbles, and Bits
23
PLC Data Formats

• Two 8-bit unsigned bytes of data
• 16-bit unsigned integer
• 16-bit signed integer
• 32-bit signed integer
• Binary coded decimal
• Hexadecimal

24
Two 8-bit Unsigned Bytes of Data
25
Hexadecimal
26
16-bit Signed Integer
27
16-bit Unsigned Integer
28
32-bit Signed Integer (1 of 2)
Double Word
0 1 1 1 0 0 0 1 1 1 1 1 1 0 0 0
0 1 1 1 0 0 0 1 1 1 1 1 1 0 0 0
Lower 31 bits contain the value
Sign bit
32 bit signed integer data range
-2,147,483,648 to 2,147,483,647
29
32-bit Signed Integer (2 of 2)
Double Word
0 1 1 1 0 0 0 1 1 1 1 1 1 0 0 0
0 1 1 1 0 0 0 1 1 1 1 1 1 0 0 0
Byte
Byte
Byte
Byte
Word
Word
30
Basic PLC Data Types
Data Type Description Size Range
Bool Single bit Bit 1 ON 0 OFF
Sint 8 bits Byte -128 to 127
Int 16 bits Word -32,768 to 32,767
Dint 32 bits Double Word -2,147,483,648 2,147,483,647
Real Floating point Real or floating Point Larger than Dint or with Decimal point
31
Data Table Format

• Words are 16 bits.
• Bits 0 through bit 15
• First word or bit is always 0.
• SLC 500 data tables can contain up to 256 words
  (0 to 255).
• PLC 5 data tables can contain up to 1,000 words
  (0 to 999).

32
Words Arranged in a Data Table
33
Status Table Words Assigned by Module
Requirements

• The number of status table words assigned depend
  on what a specific module needs.
• 16-point module equals 16 bits.
• 32-point module equals 32 bits.
• Four-channel analog equals four words.
• Eight-channel analog needs eight.

34
SLC 500 I/O Configuration
35
16-point Modules I/O Points Represented in a
Word
36
Physical Input Conditions and the Corresponding
Input Data Word
37
8-Point Input Module Represented in a Word
38
SLC 500 Input Status Table
39
24-point I/O Module Represented in Two Words
40
Two Words Representing Inputs for a 32-bit Module
41
Output Status File Correlation to Module
42
SLC 500 Digital Outputs
43
Four Words Representing a Four-channel Analog
Module
15 14 13 12 11 10 9
8 7 6 5 4 3
2 1 0
Channel 0
0 1 1 1 1 1 0 1 0 1 0 1 1 1 1 1
0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0
Channel 1
Channel 2
Channel 3
44
SLC 500 Analog Input Channels
45
SLC 500 Output Analog Channels
46
So, Whats in It for ME??

• I need to be able to work with different number
  systems.
• PLC configuration
• PLC troubleshooting
• Program interpretation
• Error code interpretation
• Data conversion to different hardware

47
SLC 500 Analog Input Module Configuration

• You need to configure a 1747sc-INI4i analog input
  module.
• Module configuration specifications are listed
  below.

48
Channel Configuration Word
Channel Data Word
SLC 500 Processor
Analog Input Module
Channel Status Word
Analog Input Signal
Channel Configuration
49
Specifications

• Enable the input channel
• 4- to 20-mA input range
• Work in engineering units
• Pump to run maximum if open input
• 60-Hz input filter
• Auto calibration disabled

50
What Do You Need to Do?

• Determine the 16-bit data word for the
  configuration.
• Convert the binary word into decimal.
• Program a move instruction on your SLC 500 ladder
  to move the configuration data to each analog
  channel.

51
Input Channel Configuration Word
52
(No Transcript)
53

• What value will you enter into the move
  instructions source?

54
Understanding Binary Coded Decimal (BCD)
55
Single-digit BCD Thumb-wheel Interfaced to a PLC
56
Binary Coded Decimal Number Bit Patterns
57
Binary Coded Decimal
58
Two-digit BCD Thumb-wheel Interface
59
Four-digit BCD Thumb-wheel
60
Output Module Connected to Seven-segment Display
61
Comparison of BCD to Decimal and Binary Numbers
62
BCD Invalid Codes
63
Decimal, Hexadecimal, and BCD Comparisons
64
SLC 500 Conversion from BCD
65
SLC 500 Converting to BCD
66
PLC 5 Converting from BCD
67
PLC 5 Converting to BCD
