A General Introduction to Tomography

1
A General Introduction to Tomography Link Delay
Inference with EM Algorithm

• Presented by Joe, Wenjie Jiang
• 21/02/2004

2
Outline of Talk

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

3
Terminology Tomography
Brain Tomography Access is difficult!
Network Tomography Access is difficult!
Vardi 1996
4
Why tomography?

• What is the
• Bandwidth?
• Loss rate?
• Link Delay?
• Traffic demands?
• Connectivity of links in the network? (Topology
  Inference)

Path a connection between two end nodes, each
consisting of several links. Link a direct
connection with no intermediate routes/hosts.
5
Motivation

• Identify congestion points and performance
  bottlenecks
• Dynamic routing
• Optimized service providing
• Security detection of anomalous/malicious
  behavior
• Capacity planning

6
Why tomography - Difficulty

• Decentralized, heterogeneous and unregulated
  nature of the internal network.
• No incentive for individuals to collect and
  distribute these info freely.
• Collecting all statistics impose an impracticable
  overhead expense
• ISP regards the statistics highly confidential
• Relaying measurements to decision-making point
  consumes bandwidth.

7
Why tomography - Solution

• Widespread internal network monitoring is
  expensive and infeasible
• Edge-based measurement and statistical analysis
  is practical and scalable

8
Brain Tomography
9
Network Tomography
10
Where are you?

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

11
Introduction to tomography

• Use a limited number of measurements to infer
  network (link) performance parameters, using
• -- Maximum Likelihood Estimator
• -- Estimation Maximization
• -- Bayesian Inference
• and assuming a prior model.
• Categories of problems
• -- Link level parameter estimation
• -- Sender-Receiver traffic intensity.
• -- Topology Inference

12
Introduction to tomography (2)

• Two forms of network tomography
• -- link-level metric estimation based on
  end-to-end, traffic measurements (counts of
  sent/received packets, time delays between
  sent/received packets)
• -- path level (sender-receiver path) traffic
  intensity estimation based on link-level
  measurements (counts of packets through nodes)
• Passive or Active measurements?
• Multicast or Unicast?

13
Problem Description

• To solve the linear system
• A, ? and ehave special structures.
• Goal to maximize the likelihood function

14
Problem Description (2)

• A routing matrix (graph)
• ? packet queuing delays for each link
• y packet delays measured at the edge
• e noise, inherent randomness in traffic
  measurements

Statistical likelihood function
15
Problem Description (3)
l1
l2
l3
l4
l5
l6
l7
l1
l2
l3
l4
l5
l6
l7
Y1
Y2
Y3
Y4
An virtual multicast tree with four receivers
Y1X1X2X4
16
Where are you?

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

17
Physical Topology
Measure end-to-end (from sender to receiver)
delays
18
Logical Topology
Logical topology is formed by considering only
the branching points in the physical topology
Infer the logical link-level queuing delay
distributions!
19
The basic idea of internal link delay tomography
Send a back-to-back packet pair from a sender,
each packet heading to a different receiver
Use the fact that delays are highly correlated on
shared links
Queuing delay difference between these two end
can be attributed to the unshared links
20
Delay Estimation

• Measure end-to-end delay of packet pairs

Packets experience the same delay on link1
d2dmin0
d3gt0
Extra delay on link 3!
21
Packet-pair measurements

• Key Assumptions
• Fixed known routes
• Temporal independence
• Spatial independence
• Packet-pair delays are identical on share links.

N delay measurements in all
22
Parameters
ai parameter of delay pmf on link i
a1
a3
a2
a6
a4
a5
a7
a9
a8
23
Link delay model

• ai delay pmf on link i
• Link delay model could be multinomial
• quantized delay model delay 0, 1, 2, 3,,L,8
• ai ai0,ai1,ai2,...,aiL,ai 8
• aijP delay(link i) j
• ai0ai1ai2,...,aiLai 81

24
Goal
is the probability of the event of n-th
measurement
is the probability of the event of all
measurements
Our goal find
25
Where are you?

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

26
Review of MLE (Maximum Likelihood Estimation)
27
Review of MLE (Maximum Likelihood Estimation)

• The basic idea of MLE God always let the event
  with the biggest probability happen the most
  likely -- The MLE of ? is to make the sample
  occur the most likely
• Note we assume Xx1,xN to be i.i.d
• The solution could be easy or hard depending on
  the form of p(?X)
• e.g. p(?X) is a single Gaussian ?(µ, s2), we
  can set the derivative of logL(?X) to zero and
  solve it directly.

28
Complete Data

• The sample Xx1,xN together with the missing
  (or latent) data Y is called complete data.
• The complete likelihood is
• where p(x, y?) is the joint density of X and Y
  given the parameter ?.
• The complete log-likelihood is

29
Complete MLE

• By the definition of conditional density,
• where p(yx,?) is the conditional density of Y
  given Xx and ?
• The complete MLE

30
Basic idea of EM

• Given Xx and ? ?t-1, where ?t-1 is the current
  estimates the unknown parameters
• log p(x,Y ?) is a function of Y whose unique
  best Mean Squared Error (MSE) predicator is

31
EM steps
32
The magic of EM

• the direct MLE of
• is relatively hard to solve
• But the MLE of complete log-likelihood is
  relatively easier to obtain
• since is a function of x and y, (y is hidden),
  we use the expectation of y under x and
• So

E-step
M-step
33
Where are you?

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

34
EM in link delay inference
Note that here notation x and y have opposite
meaning of x, y stated in previous EM algorithm
a1
x1
x2
x3
a3
a2
a6
x6
x4
x5
x7
x9
a4
a5
a7
a9
x8
a8
35
EM in link delay inference (2)

• Complete data Z(X,Y)
• the complete data log-likelihood
• PaYX has nothing to do with a
• mi,j is the total number of packets experience a
  delay j on link i over N measurements.

36
EM in link delay inference (3)
The MLE of awould be
37
EM in link delay inference (4)
MLE
which is the frequency of event mi
A simple example is that we toss a die, P( the
result i)ai (i1,26) mi how many times we see
result i
38
EM in link delay inference (5)

• We notice that is similar to
• only different that should be replaced by
• So the MLE

39
EM in link delay inference (6)
Probability Propagation
40
A simple example
0
delay on each link fall into 0,1,2,3
x1
1
x2
x3
2
3
aijP delay (link i) j
y2
y1
41
A simple example (2)

• Suppose there are 5 measurements
• (3,2), (4,2), (6,5), (0,0), (4,1)

0
x1
1
x2
x3
2
3
y2
y1
42
A simple example (3)
0
x1
1
Bayes Formula
x2
x3
2
3
y2
y1
43
A simple example (4)
0
x1
1
x2
x3
2
3
y2
y1
44
A simple example (5)
0
x1
similarly
1
x2
x3
2
3
y2
y1
45
A simple example (6)
j i 0 1 2 3
1 4/3 11/6 5/6 1
2 1 1/3 5/6 17/6
3 17/6 5/6 4/3 0
mi,j computed in the first iteration.
46
A simple example (7)
the physical meaning of a1,0 is that the number
of packets that experience delay 0 on link i
divided by the total number of packets that
travel through link i
47
A simple example (8)
j i 0 1 2 3
1 4/15 11/30 1/6 1/5
2 1/5 1/15 1/6 17/30
3 17/30 1/6 4/15 0
ai,j computed in the first iteration
48
A simple example (9)
Iteration iterate E-step and M-step, until some
termination criteria is satisfied!
j i 0 1 2 3
1 0.4 0.4 0 0.2
2 0.2 0 0 0.8
3 0.4 0.2 0.4 0
After 6 iterations, ai,j converges to a fixed
value.
49
A simple example (9)

• (3,2), (4,2), (6,5), (0,0), (4,1)

0
x1
1
x2
x3
2
3
y2
y1
50
Complexity
51
Where are you?

• Why tomography?
• Introduction to tomography
• Internal Link Delay Inference
• Basic EM
• A simple example to infer internal link delay
  using EM algorithm
• Conclusion

52
Conclusion

• The field is just emerging.
• Deploying measurement/probing schemes and
  inference algorithms in larger networks is the
  next key step.

53
Problems

• The spatial-temporally stationary and independent
  traffic model has limitations, especially in
  heavily loaded networks.
• A trend for highly uncooperative environment for
  active probing passive traffic monitoring
  techniques, for example based on sampling TCP
  traffic streams

54
The End

• Thank you!
