DST-1 Introduction

1
DENSO EUROPE TECHNICAL TRAINING
DST-1 Introduction
2
Possibilities of the DST1

• Basic checks
• Oscilloscope and Multimeter function
• Reading / Erasing Diagnostic Codes
• Data Monitor with 4 trigger functions and save
  mode
• Active test (Activating actuators of the system)
• Troubleshooting chart
  (Completed with workshop
  manual)

3
GENERAL
Overview hardware
4
GENERAL
Overview adapter cables
5
GENERAL
Overview
Power Indicator
ON/OFF Switch
Shift Indicator
RS232C Connector
IC - Cardslot
6
GENERAL
Voltmeter Oscilloscope INPUT
Pulse Signal INPUT
Ohmmeter Speed simulator OUTPUT
Vehicle Link Cable
AC-DC Adapter
7
Oscilloscope
Channel 2 Volt range
Channel 1 Volt range
Channel 1/2 Signal name
Trigger mode
Time Axis Range
Trigger slope
RUN/HOLD
Trigger Level
Trigger- Level mark
Channel 1
Channel 2
Trigger position
8
Multi use
Vehicle- compartment
Engine- compartment
9

• IC-Module
• OBD I Toyota V3
• OBD II Others

Reset
IC-Card for downloading
10
Applications available for the DST-1 Make Model
Engine Denso dieselsystem ) Suzuki Vitara R
F V3 Mazda 323, 626, Premacy RF-MDT V5 323,
626, Premacy RF-MDT (Euro 3) V5 Mitsubishi Galant
, Space Runner 4D68 V3 Canter 4D34T V4 Nissan
X-Trail YD22 U2P Opel Corsa-C Y17DT-Y17DTL V
5 pilot Astra-G Y17DT (M.Y.2000) V5
pilot Astra-G Y17DT (M.Y.2001) V5
pilot Toyota Landcruiser 90 1KZ-TE V3 Corolla
2C-E V3 Carina E 2C-TE V3 ROM Avensis
(Corona) 2C-TE V3 ROM Picnic 3C-TE V3
ROM Landcruiser 100 1HD-FTE V4 Avensis 1CD-F
TV U2P Corolla 1CD-FTV U2P Landcruiser
90/95 1KD-FTV U2P Previa 1CD-FTV U2P Avensi
s Verso 1CD-FTV U2P Dyna 2KD-FTV U2P RAV4
1CD-FTV U2P
11
Applications coming available end of
2002 Make Model Engine Denso
dieselsystem ) Toyota Coaster 15B-FTE V4 Dy
na S05C U2 Landcruiser 100 1HD-FTE V4
pre-stroke Hiace 2KD-FTV U2P Hiace-semivan 2
KD-FTV U2P Hilux 2KD-FTV U2P Corolla
Verso 1CD-FTV U2P Nissan Primera YD22 U2P Rena
ult Vel Satis Isuzu V6 U2P Saab 9.5 Isuzu
V6 U2P ) V3,V4,V5 Electronic controlled
rotary pumps. U2/U2P common rail systems.
12
General
Function Keys Menu - Shift - Enter - Select -
Back
13
Outline of functions (display flowchart)
1. Basic check 2. Trouble shooting 3. ECU data
monitor 4. Active test 5. General analysis

• (1) ECD
• Battery check
• Fuel leak test
• Heater control check

• (2) ECT
• Throttle pos. sensor check
• Switch signal check
• Shift position switch check
• Gear change solenoid check
• Travel test

1. Basic check (1) ECD (2) ECT
14
Outline of functions (display flowchart)
1. Basic check 2. Trouble shooting 3. ECU data
monitor 4. Active test 5. General analysis

• (1) Diag code
• Mode select
• Diag code check
• Diag code erase

• (2) Troubleshooting chart
• Troubleshooting procedures
• corresponding to
• diag codes

2. Troubleshooting (1) Diag code (2)
Troubleshooting chart
15
Outline of functions (display flowchart)
1. Basic check 2. Trouble shooting 3. ECU data
monitor 4. Active test 5. General analysis

• (2) Data record
• Manual
• Auto trigger
• Single
• Snap shot

3. ECU data monitor (1) Data monitor (2) Data
record (3) ata replay (4) Save (5) Call
16
Outline of functions (display flowchart)
1. Basic check 2. Trouble shooting 3. ECU data
monitor 4. Active test 5. General analysis
4. Active test
17
Outline of functions (display flowchart)
1. Basic check 2. Trouble shooting 3. ECU data
monitor 4. Active test 5. General analysis
5. General analysis (1) Digital tester (2)
Oscilloscope
18
Multimeter
2- Channel Oscilloscope
Pulse and Speedmeter
Voltmeter Ohmmeter
19
Start up DST-1
DST-1
Trouble shooting program card e.g. NISSAN ECD-U2P
system
NextEnter
20
Troubleshooting with DST-1
Select vehicle model
e.g. X-TRAIL YD
Select NextEnter
Troubleshooting
Diag code
Data monitor Freeze frame data Active test
Select NextEnter
21
Troubleshooting with DST-1
Diag code
Diag code Diag code erase
Troubleshooting chart
Select NextEnter
Troubleshooting chart
P0110 Engine coolant temp. sensor
P0120 Accelerator position sensor
Select DiagEnter
22
Outline troubleshooting flowchart
ECU data check _at_Engine coolant temp Standard
value -40C lt THW lt 130C THW C NG- OK
P0110 Engine coolant temp. sensor
NG
OK
Resistance check Disconnect connector _at_ Engine
ECU Measure resistance between terminals on
wiring _at_THW-E2 Standard value _at_C
W Measured value W NG- OK
DTC (Diagnostic Trouble Code) detection
Possible past malfunction Try to reproduce
malfunction EndEnter
Connector diagram indication
Functions 1 Measurement data values are
indicated in the troubleshooting flowchart. 2
Failure judgment criteria values are
indicated. 3 The area to be measured is clearly
indicated. A connector diagram is indicated.
OK
NG
Unit check Disconnect connector _at_engine coolant
temp. sensor Measure resistance between
terminals _at_THW-E2 Standard value _at_C
W Measured value W NG- OK
Repair or replace malfunction part _at_ENGINE
ECU EndEnter
Connector diagram indication
NG
OK
Repair or replace malfunction part _at_engine
coolant temp. sensor EndEnter
Repair or replace malfunction part _at_W/H EndEnter
23
Datamonitor
1.
Troubleshooting
Enter
Diag code
Data monitor
Freeze frame data Active test
Select NextEnter
24
1.
Trigger start condition
Enter
Signal name ENG SPD
Condition
1850.0 rpm or more
To switch to graph Select key
To change view Menu key
25
Trigger mode selection
1. Simple setting mode
2. Advanced setting mode
Select EnterENTER
26
Software download
SELECTION MENU
Select Function with DIGITAL
TESTER OSCILLOSCOPE SYSTEM MENU
DOWNLOAD

• Start up DST-1 with IC-Card
• While logo is shown, press MENU

• Choose Download
• press Enter

27
Software download
Execute Download.exe from CD-ROM.
28
Recorded data replay
Recorded data replay
1. No record
2. No record 3. No record
Select SetupEnter
Possibility of making 3 records and store on IC
Card
29
BEDANKT
ENDE
DOMO ARIGATO
FIN
THANKS
THE END
DANKE
MOLTE GRAZIE
EINDE
30
And now Gents, Time to use your hands!
