MAE 552 Heuristic Optimization

1
MAE 552 Heuristic Optimization

• Instructor John Eddy
• Lecture 17
• 3/4/02
• Taguchis Orthogonal Arrays

2
S/N Ratio

• Why use the signal / noise ratio?
• Given a product or process with a target
  performance, deviation from that performance can
  typically be expressed in terms of (i.t.o)
  statistics (Taguchi Quality loss).
• Two things you want are for your mean to be on
  target and for your variance to be low. Take
  the example of a machine that throws darts.

3
S/N Ratio

• Here are the results of 4 such machines

Good Mean Bad Var.
Good Mean Good Var.
Bad Mean Good Var.
Bad Mean Bad Var.
4
S/N Ratio

• Noise can be interpreted as the variance observed
  in the process (since variance is commonly a
  direct result of noise).
• The signal can be interpreted as the desired
  value (the value you would like your mean to
  take).
• The S/N ratio is then

5
S/N Ratio

• Another means of calculating the S/N ratio is to
  take -10log(d) where d represents the mean
  squared deviation from the target.
• So in our example, the target is 0 defects, and
  the squared deviation for each count is the
  square of the count itself.

6
S/N Ratio

• Should we always use an S/N ratio?
• Taguchi says yes because it accounts for both the
  mean and standard deviation.
• Will it always be a maximize situation?
• Yes it will, assuming that it is always desirable
  to achieve the target value with very little
  deviation.

7
Back to our Example
A B C D
1 1 1 1 1
2 1 2 2 2
3 1 3 3 3
4 2 1 2 3
5 2 2 3 1
6 2 3 1 2
7 3 1 3 2
8 3 2 1 3
9 3 3 2 1
8
Taguchi Example

• Continuing with our example

Factor Levels Levels Levels
Factor 1 2 3
A Temperature -20 -45 -60
B Pressure -30 -40 -55
C Settling Time -50 -35 -40
D Clean Method -45 -40 -40
All the level averages for our example problem.
9
Example

• Using the values for the level averages, we can
  plot the factor effects and see visually which
  factors have the greatest influence on the
  performance of our product or process.

10
Example
Overall Mean
11
Example

• Considering the effects visualized in the
  previous figure, which levels do you think are
  optimal?
• Recall that we want to maximize our S/N ratio, so
  we choose the levels that cause the greatest
  positive deviation from our mean. Since our
  deviation was
• mfactor, level m

12
Example

• We clearly want to choose those levels with the
  largest values because we have a negative overall
  mean and we will therefore be adding that value
  to our level means.
• Consider Factor A, our deviation from the mean
  cause by factor A at level 1 is
• -20 (-41.67) 21.67

13
Example

• And our deviation from the mean cause by factors
  2 and three are
• -45 (-41.67) -3.33
• -60 (-41.67) -18.33
• So by comparison, level 1 causes the greatest
  positive deviation from the mean, and will be
  chosen as our optimal setting.

14
Example

• Likewise, for the remaining factors, we will
  choose the following levels as optimal
• B) Pressure - Level 1
• C) Settling Time - Level 2
• D) Cleaning Method - Level 2 or 3
• The resulting equivalent experiment is then
• 1 1 2 2/3 - does not appear in our array!!

15
Example

• The final step would then be to run a validation
  experiment to see that the optimal solution is
  actually the best thus far.
• If it is not, then you would perhaps do one of
  two things
• Choose the best configuration of any of the
  experiments you did run.
• Refine your system and re-run the experiments.
  (could mean changing level settings to hone in
  on good regions, etc.

16
Comparison

• What if we didnt use the Taguchi approach, what
  else might we do to estimate factor effects?
• One approach is a one-at-a-time method in which
  all but one factor are held constant while the
  other is varied throughout its levels. How many
  experiments does this require?

17
Comparison

• Answer
• For N factors each having L levels, we would
  need
• L x N experiments
• That would be 12 in our example (and it turns out
  that we would not achieve the same accuracy in
  our estimate of the level means).

18
Comparison

• Another approach is the brute-force full
  factorial method. That is, conduct every
  possible experiment for the factors and levels.
• How many experiments would this require?

19
Comparison

• Answer
• For N factors each having L levels, we would
  need
• LN experiments
• That would be 81 experiments in our example. The
  only good thing is that we would be guaranteed to
  find the best configuration for our levels.

20
ANOM

• The approach we have taken with this problem is
  called the analysis of means.
• This approach relies on 2 assumptions for its
  validity
• Use of an additive model is appropriate
• Use of an orthogonal array is appropriate.

21
Additive Model

• What do we mean by additive model?
• First, lets define a short hand for our factor
  effects
• Let ai represent the deviation from the mean
  caused by setting factor a to level i. So i.t.o.
  our previous example,
• b2 mb2 - m

22
Additive Model

• We are going to show that the procedure we
  applied to our example is equivalent to applying
  an additive model of the individual factor
  effects to determine performance.
• This means that by using such an additive model,
  we should be able to predict the performance of
  our product or process based on the factor
  effects.

23
Additive Model

• Our additive model is stated as follows
• ?(Ai, Bj, Ck, Dl) m ai bj ck dl e
• Where e is an error term that accounts for the
  error incurred by using the additive model and
  the error incurred by any lack of repeatability
  of measuring ? for any given experiment.

24
Additive Model

• As in most subject areas, an additive model is
  also sometimes called a superposition model or a
  variables separable model.
• It is possible for our factor effects to be
  non-linear (quadratic, cubic, etc.) but cross
  product terms (between factors) are not allowed.
• Cross correlation would be like The effect of
  factor A at level 2 while factor C is at level 3
  is

25
Additive Model

• According to our previous definition of factor
  level effects, we can show that the sum of the
  effects of all the levels of a given factor is
  equal to 0. That is (in our example)
• a1 a2 a3 0
• b1 b2 b3 0
• c1 c2 c3 0
• d1 d2 d3 0
• We will show this for factor a.

26
Additive Model

• Recall that ai mAi m

v
27
Additive Model

• Now, recall our representation of the observation
  value i.t.o the overall mean, factor effects, and
  error term
• ?(Ai, Bj, Ck, Dl) m ai bj ck dl e
• We can represent factor effects i.t.o this
  equation as shown on the following slide.

28
Additive Model
29
Additive Model

• So from the previous result, we see that
• mA3 m a3 some error term
• This is sensible enough, recall that our
  representation of ai was originally mAi m.
• So mA3 as we have derived it here, is an estimate
  of m a3 and thus our approach was in fact the
  use of an additive model.

30
Additive Model

• A note on the error term.
• We have shown that the error is actually the
  average of 3 error terms (one corresponding to
  each experiment).
• We typically treat each of the individual
  experiment error terms as having zero mean and
  some variance.

31
Additive Model

• Define Replication Number nr
• The replication number is the number of times a
  particular factor level is repeated in an
  orthogonal array.
• It can be shown that the error variance of the
  average effect of a factor level is smaller than
  the error variance of a single experiment by a
  factor equal to its nr.

32
Additive Model

• So, to obtain the same accuracy in our factor
  level averages using a one-factor-at-a-time
  approach, we would have to conduct 3 experiments
  at each of the 3 levels of each factor for a
  total of 36 experiments.
