Solutions for an Unsettled World
A Homeland Security Integration Architecture
Session id 40129

• Stan DefilippiSenior Director
• Oracle Corporation

3
Foundations of Homeland Security

• Law
• Science and Technology
• Information Sharing
• International Cooperation
• -National Strategy for Homeland Security, July
  2002

4
Foundations of Homeland Security

• Law
• Science and Technology
• Information Sharing
• International Cooperation
• -National Strategy for Homeland Security, July
  2002

5
Guiding PrinciplesInformation Sharing

• Balance security with privacy
• View federal, state and local as one entity
• Capture information once at the source
• Create trusted databases
• -National Strategy for Homeland Security, July
  2002

6
Oracles VisionNational Information Sharing
Vertical Horizontal Integration
Transportation
DoD/Intel
Cargo Tracking
Surveillance Data
Manifests
Threat Data
FEDERAL
Watch Lists
Intelligence Data
Secure, Integrated, National Homeland Security
Information
Criminal Justice
Public Health
Bio Surveillance
Medical Records
Investigative Data
Criminal Records
Syndromic Indicators
Wanted Lists
STATE
Emergency Management
Physical Infrastructure
ER Availability
Asset Availability
Pipeline Gas/Water,
Road Networks
Volunteer Data
National Landmarks
MUNICIPAL
Consolidate Simplify Integrate Secure
7
Oracles Approach

• Common Solution Pattern for Integration
• Solution Sets to solve specific business problems

8
The Oracle Technology Solution simple, yet
elegant
Oracle Application Server 10G
Oracle 10G Database
9
Oracle Applications Server 10G
Management Security
Portals
e-Business Integration
J2EE, Web Services
Wireless
BusinessIntelligence
Performance Caching
10
Oracles Solution Architecture

Users
Presentation

Applications
Integration/ Web Services
Connected Legacy Systems

11
Integration Solution Sets for Homeland Security

• Integrated Justice
• Intelligence
• Bioterrorism
• Identification
• Biometrics-based National Drivers License
• Visitor Entry/Exit
• Transportation
• Global Cargo Tracking
• Inter-modal Tracking of BNICE Substances within
  our borders
• Protection of Critical Infrastructure

12
(No Transcript)
13
The Historic Business Problem
87,000 jurisdictions
100,000s systems
14
The Oracle Integrated Justice Solution
Public Defender
Courts
Parole/Probation
15
Data Exchange Types
Courts
Public Defender
Push
Query
Prosecutor
Corrections
Pull
Publish
Subscribe
Parole/Probation
Push
Law Enforcement
Subscribe
Citizens
Emergency Management
16
A look inside the Justice iHub
Justice iHub
Defender App
Courts App
Corrections App
Prosecutor App
Police App
Parole App
17
A look inside the Justice iHub
InterConnect
Workflow
Defender Application
Courts Application
BusinessProcessManagement
SemanticTransformation
Adapter
Adapter
Corrections Application
Prosecutor Application
Reliable Messaging
Adapter
Adapter
Business Partner Connect
Police Application
Adapter
Adapter
Parole Application
18
Justice iHub is built upon Justice XML
Law Enforcement
Prosecutor
Public Defender
Corrections
Probation Parole
Courts
XML Protection Order XML Sentencing Order XML
Arrest Warrant
XMLCharging Document
XML Disposition Order
Query
XML Disposition Order
XML Arrest/ Incident Report
XML RAP Sheet
XML DDS
Any user can query
19
Justice iHub enables Wireless Spatial
Any Device

• Any Content
• Geo-coding
• Routing
• Mapping

Gateway
Justice iHub

• Any Content
• Field Reports
• Incident Reports
• Accident Reports
• E-mail

20
Security
Division Chief
Watch Commander
Network
Shift Supervisor
Patrol Officer
21
Integrated Justice Network

• An iHub may be networked with other iHubs across
  a network, based upon
• Transaction volume
• System Management decisions

Central iHub
22
(No Transcript)
23
Trends/Visions

• Open standards
• Virtualization
• National Information Grid
• Network Centric Operations

24
On Standard

• Federal Enterprise Architecture
• Interagency Common Reference Model
• Common Criteria for Information Technology
  Security Evaluation
• Open Computing - Linux, J2EE, XML
• Spatial Standards - NSDI

25
Virtual Private Database (VPD)
Record A Record B
User 1
Record A Record B Record C Record D
Record A Record C Record D
User 2
Record B Record D

• Several VPDs within a single instance
• Role-based security access

User N
26
Virtual Private Network (VPN) Concept
VPN
DB
DB
VPD
VPD
DB
DB
VPD
VPD
VPD
VPD

• Virtual single instance
• Over distributed physical network

27
National Information Grid Concept
Western Jurisdiction
Central Jurisdiction
Eastern Jurisdiction
Grid Fabric
28
National Information Grid Concept

• iHub pushes/pulls information per business rules
• Query from virtual database
• User provisioning across grid
• Hosting allows for utility pricing model
• If Hosted iHub experiences heavy transactional
  load, then
• Dynamic reallocation of transaction processing to
  another Hosted iHub
• 10G RAC clusters for high availability
• Add blade clusters for scalability as the demand
  grows

29
Network Centric Operations

• 21st century information age operations
• Networked sensors, infrastructure and operators
• System of systems
• Mass of effects rather than physical forces
• Speed of command/decision
• 3D arena
• Global/national awareness
• Self-synchronization

State
National
International
Local
30
Network Centric Homeland Security (NCS)
States
DOT
Gov.
Counties
State Police
Courts
Hub
Court
Sheriff
Public Health
Emergency Mgmt
Cities
Police
Hub
Hospital
Emergency Mgmt
Fire
Hub

• At each level
• Public Safety
• Justice
• Intelligence
• Emergency Management
• Public Health
• Transportation
• Executive agencies

EMS
DoD
Hub
FEMA
Hub
Hub
CIA
INS
FBI
TSA
Federal
31
NCS Solution Architecture

Users
Presentation

Applications
Standards-Based Web Services
Grid Services
Grid Fabric
32
NCSBuilding a Common Operational Picture
Emergency Management
BioTerrorism
Judiciary
Law Enforcement
Citizen Interaction
Critical Infrastructure Tracking
Risk Assessment
Geo-spatial information
Border Security
Natl Comms
Common data model
Security
Infrastructure deployment
Role-based user access
33
Al Qaeda
means
the network
34
(No Transcript)
35
Integration Solution Sets for Homeland Security

• Integrated Justice
• Intelligence
• Bioterrorism
• Identification
• Biometrics-based National Drivers License
• Visitor Entry/Exit
• Transportation
• Global Cargo Tracking
• Inter-modal Tracking of BNICE Substances within
  our borders
• Protection of Critical Infrastructure

36
Watch List iHub
Watch List Transaction Base
37
Law Enforcement Intel iHub

• Information Sharing for
• Investigative Targets
• Alerts
• Hotline Tips
• Extremist Groups
• Emergency Contacts
• Equipment Training

Boston
Detroit
Chicago
NYC
DC
Los Angeles
Dallas
38
Drivers License iHub
One State
DMV
AAMVAnet
Biometrics License Trans Base
To other 49 States
State WAN
CCH
NLETS
AFIS
To other 49 States
39
Global Transportation iHub
Carrier
Broker
Port of Origin
Port of Destination

• Real-time tracking from point of origin
• People
• Cargo

Coast Guard
Customs
EPA
INS
40
D E M O N S T R A T I O N
Justice iHub
41
Next Steps.

• To request a complimentary 1-on-1 consultation to
  begin a personalized assessment of the potential
  benefits of an Oracle solution based on your
  organizations environment, stop by the Oracle
  Consultations area in the Oracle DEMOgrounds
  section of the Exhibit Hall.
• For information on our services, visit the Oracle
  Consulting booth in the Oracle Services area in
  the Oracle DEMOgrounds section of the Exhibit
  Hall.

42
Reminder please complete the OracleWorld
online session surveyThank you.
