Ultrasonic Nonlinear Imaging-Contrast Imaging
2
History
  • 1968 Gramiak et al published observation of echo
    signal from LV injection of indocyanine dye
  • Subsequent research showed this phenomenon
    occurred with just about any liquid injected
    through small needle

3
More History
  • First work was with free gas bubbles
  • bubbles didnt last very long
  • size too big to go through lungs, needed
    intra-arterial injection
  • Late 80s - early 90s - development of
    numerous agents
  • more stable
  • smaller size

4
Motivation
  • X-ray, CT, nuclear, and MR all need it.
  • Enhance backscatter signal from blood
  • Blood signal typically 40dB below tissue
  • Provide visualization of low velocity flow
    normally masked by tissue motion
  • measure of microvasculature important in many
    disease states

5
Desired Properties
  • Non-toxic/easily eliminated
  • Able to be injected intravenously
  • Small enough to pass through microcirculation
  • Physically stable
  • Acoustically active

6
Contrast Imaging
  • Contrast agents are used to provide higher
    contrast. The three commonly seen contrast agents
    are backscatter, attenuation and sound velocity.
  • Contrast agents could be solid particles,
    emulsion, gas bubbles, encapsulated gas, or
    liquid.

7
Contrast Imaging
  • Primary clinical benefits
  • Enhanced contrast resolution between normal and
    diseased tissues.
  • Outline of vessels or heart chambers.
  • Tissue characterization by using tissue specific
    agents.
  • Increasing blood flow signals.
  • Dynamic study using washout curve.

8
Example
9
More Examples
Bubbles Physiology
Portovenous phase at 45-90 seconds
Parenchymal phase at 90-120 seconds, can be up
to 5 min
Arterial phase starts 20-45 seconds after
injection
10
Tumor Detection
Liver Metastases- primary Breast Ca
Post
Pre
High MI, Harmonic B-mode using Levovist
11
Tumor Characterization
Focal Nodular Hyperplasia
Coded Harmonic Angio using Levovist
12
Tumor Characterization
Hepatocellular Carcinoma (HCC)
Coded Harmonic Angio using Levovist
13
Tumor Characterization
Low MI Harmonic using Sonovue
Images with non-approved agents for internal GE
training only
14
Tumor Detection
Late Phase
Early Phase
Low MI Harmonic - 2 using Definity
Images with non-approved agents for internal GE
training only
15
Tumor Detection/Characterization
Hemangioma
Pre
Post
High MI Fundamental Color using Levovist
16
Tumor Detection
Hemangioma?, Adenomatous Nodule?
High MI Harmonic Color using Levovist
17
Clinical Values (I)
  • Tumor Detection
  • presence or absence of liver, kidney or
    pancreatic masses
  • Tumor Characterization
  • avascular- cyst
  • hypovascular- metastasis, hemangioma
  • hypervascular- primary carcinoma, hypervascular
    met
  • Others
  • enhances vessels for RAS, Carotid stenosis,
    TCD, etc
  • better visualization of thrombus (IVC, TIPS)
  • post ablation follow up
  • trauma assessment

18
Clinical Values (II)
  • Endocardial border detection.
  • Left ventricle (LV) function.
  • Valvular regurgitation quantification.
  • LV flow patterns.
  • Perfusion area of coronary artery.
  • Assessment of surgery for ventricular septal
    defect.

19
Clinical Values (III)
  • Liver tumor enhancement.
  • Uro-dynamics and kidney functions.
  • Tubal function and placenta perfusion.
  • Transcranial Doppler enhancement.
  • LV pressure measurements.

20
Current Contrast Agents
  • Aerosomes (ImaRx, Tucson, AZ)
  • Albunex (MBI, San Diego, CA)
  • BY963 (Byk Gulden, Konstanz, Germany)
  • Echovist (Schering, Berlin, Germany)
  • EchoGen (Sonus, Bothell, WA)
  • DMP115 (DuPont-Merck, N. Billerica, MA)
  • Imagent US (Alliance, San Diego, CA)
  • Levovist (Schering, Berlin, Germany)
  • NC100-100 (Nycomed, Oslo, Norway)

21
Current Contrast Agents (Cont.)
  • Optison (MBI, San Diego, CA) approved in US for
    cardiac
  • Oralex (MBI, San Diego, CA)
  • PESDA (Univ of Nebraska, Omaha, NE)
  • SonoRx (Bracco, Princeton, NJ) US approved oral
    agent
  • Sonovist (Schering, Berlin, Germany)
  • Sonovue (Bracco, Milan, Italy)
  • ST68 (Drexel Univ, Philadelphia, PA)
  • Quantison (Andaris, Nottingham, UK)
  • Quantison Depot (Andaris, Nottingham, UK)
  • Many more,

22
Contrast Mechanisms
  • Strong backscattering produced by air bubbles.
  • The backscatter increases roughly linearly with
    the number of micro-bubbles.
  • A bubble in liquid acts as a harmonic oscillator.
    Acoustic resonance provides the major echo
    enhancement. In addition, strong harmonics are
    produced.

23
Contrast Mechanisms
  • Acoustic attenuation of soft tissues is typically
    represented by a constant (e.g., 0.5dB/cm/MHz).
  • Since contrast agents significantly change the
    scattering properties, attenuation measurements
    can also be used for contrast enhancement.

24
Contrast Mechanisms
  • Sound velocity is primarily determined by density
    and compressibility. Apparently, micro-bubble
    based contrast agents alter sound velocity.
  • Contrast enhancement based on sound velocity
    variations is still academic.

25
Contrast Mechanisms
  • Micro-bubbles produce strong harmonics when
    insonified near the resonance frequency.
  • If such harmonics are stronger than tissue
    harmonics, contrast can be improved.
  • Second harmonic signal is most useful due to
    limited transducer and system bandwidth.

26
(Encapsulated) Gas Bubbles
27
Bubble Characteristics
  • Size
  • Shell for stabilization
  • tune for desired acoustic properties
  • Gas
  • use high molecular weight, less soluble gas

28
Ultrasound-Induced Encapsulated Microbubble
Phenomena
  • Oscillation
  • Translation
  • Coalescence
  • Fragmentation
  • Sonic cracking
  • Jetting
  • ,

29
Optical Measurements
30
Optical Measurements
31
Optical Measurements
100 Mframes/s camera
32
Examples
33
Pressure Dependence of Expansion
MI 0.089
MI 0.15
MI 0.39
MI 0.25
34
Variations in Bubbles Reaction
35
Variations in Bubbles Reaction
36
Bubble Oscillation
37
Ultrasound-Induced Oscillation
  • Moderate Alternate expansions and contractions
    with the same amplitude and duration at low
    driving pressures (stable cavitation).
  • Violent At higher pressures, greater bubble
    expansion amplitude than contraction amplitude,
    and relatively slow expansion followed rapid
    contraction (inertial or transient cavitation).
  • Cavitation threshold Above which the bubbles
    maximum radius is larger than twice the
    equilibrium radius.

38
Modeling
  • Strength of backscatter signal depends on
    difference in acoustic properties between two
    materials...

39
Modeling
  • Now need to include shell effects...

For a shell encapsulated gas bubble of
instantaneous radius R
Keff elasticity of shell r density of
surrounding media
dtot total damping coefficient P(t)
incident acoustic energy
Accurate only at low pressures
40
Simulations
41
Simulations
Free
Encapsulated
42
Simulations
43
Measurements
44
Optical Measurements
MI 0.09
MI 0.67
45
Translation
46
Translation
  • Resulted from primary radiation force (pressure
    gradient across the bubble surface).
  • Maximal in contraction phase.
  • Used for active targeting.

47
Translation
48
Translation
  • Secondary radiation force The microbubbles
    translate toward each other (oscillating bubbles
    generate spatially varying pressure fields).

49
Coalescence
50
Coalescence
  • Fusion of two or more bubbles.
  • As bubbles expand, bubble surfaces flattens and
    thinning occurs.
  • When critical thickness is reached (around 0.1
    micron), bubbles rupture and merge with each
    other.

51
Coalescence
52
Fragmentation
53
Fragmentation
  • Fission of a bubble into smaller bubbles.

54
Fragmentation
55
Sonic Cracking
56
Sonic Cracking
  • Ultrasound induced formation of a shell defect
    causing gas to escape from the bubbles.
  • Mechanism not yet known.

57
Jetting
58
Jetting
  • During contraction near a boundary, collapse may
    be asymmetrical.

59
Potential Clinical Applications
60
Interference from Tissue Nonlinearities
61
Non-Linear Response
Contrast agents
Transmit freq. fo
fo
62
Various Contrast Modes
  • High MI B-Mode, Harmonic - optimized for SAE
    harmonic imaging
  • Low MI B-Mode, Harmonic 1 and 2 - optimized for
    nondestructive harmonic imaging
  • High MI colorflow fundamental - optimized for SAE
    destruction effect
  • High MI colorflow harmonic - optimized for SAE
    with reduced tissue flash artifact

63
Coded Harmonic Angio
  • Step 1

Tissue and Contrast
Utilizes Encoding Technique From Coded
Harmonics To Suppress Fundamental Signal
Step 2
Step 3
Uses decoding techniques similar to B Flow to
separate tissue contrast signal
64
Detecting Blood Reflectors
Problem Blood echoes are very weak and
sometimes moving too slow for Doppler techniques
Tissue
Blood
Noise
65
Detecting Blood Reflectors
Problem Blood echoes are very weak and
sometimes moving too slow for Doppler techniques
Solution Inject contrast agents to enhance
signal
Tissue
Agent
Noise
66
Detecting Blood Reflectors
Problem Blood echoes are very weak and
sometimes moving too slow for Doppler techniques
Solution Inject contrast agents to enhance
signal Use codes to 1) detect harmonic return
signal
Agent
Tissue
Noise
67
Detecting Blood Reflectors
Problem Blood echoes are very weak and
sometimes moving too slow for Doppler techniques
Solution Inject contrast agents to enhance
signal Use codes to 1) detect harmonic return
signal 2) Suppress tissue signal
Agent
Tissue
Noise
68
Harmonic Interference
  • In contrast imaging, in which the tissue harmonic
    signals are un-desirable, the amplitude of the
    propagating wave needs to minimized.
  • Large apertures (smaller f-numbers) may be used.
  • It was reported that tissue harmonic signal can
    be reduced by 3dB by doubling the aperture size.

69
Reduction of Interference from Tissue
  • Harmonic cancellation system.
  • Sub-harmonic imaging.
  • Pulse-inversion Doppler (clutter).
  • Pulse-inversion fundamental imaging.

70
Harmonic Cancellation System
71
Aperture Size vs. Harmonic Generation
72
Harmonic Cancellation Using a Pre-biased Signal
73
Harmonic Cancellation Using a Pre-biased Signal
74
Harmonic Cancellation Using a Pre-biased Signal
75
Sub-Harmonic Imaging
76
Sub-Harmonic Imaging
  • Tissue propagation does not generate significant
    sub-harmonic signals.
  • Sub-harmonic signals may be generated with
    microbubbles in proper acoustic fields.
  • Sub-harmonic imaging can thus be used for
    reduction of tissue nonlinear signals.

77
Sub-Harmonic Generation
0.6 MPa, 16 cycles
0.6 MPa, 64 cycles
78
Sub-Harmonic Generation
79
Sub-Harmonic Generation
0.23 MPa, Occurence
0.53 MPa, Growth
1.17 MPa, Saturation
80
Pulse Inversion Doppler (for Clutter Reduction)
81
Pulse Inversion Doppler
82
Pulse Inversion Doppler (Linear)
83
Pulse Inversion Doppler (Non-Linear)
84
Pulse Inversion Doppler
85
Pulse Inversion Doppler
86
Pulse Inversion Doppler
87
Pulse Inversion Fundamental Imaging
88
Effects of Transmission Phase
89
Pulse Inversion Fundamental Imaging
90
Pulse Inversion Fundamental Imaging
91
Pulse Inversion Fundamental Imaging
92
Pulse Inversion Fundamental Imaging
93
Pulse Inversion Fundamental Imaging
Write a Comment
User Comments (0)
About PowerShow.com
