General knowledge about cardiovascular system

1
General knowledge about cardiovascular system
2
5 Classes of Blood Vessels

• Arteries
• carry blood away from heart
• Arterioles
• Are smallest branches of arteries

3
5 Classes of Blood Vessels

• Capillaries
• are smallest blood vessels
• location of exchange between blood and
  interstitial fluid

4
5 Classes of Blood Vessels

• Venules
• collect blood from capillaries
• Veins
• return blood to heart

5
The Largest Blood Vessels

• Attach to heart
• Pulmonary trunk
• carries blood from right ventricle
• to pulmonary circulation
• Aorta
• carries blood from left ventricle
• to systemic circulation

6
The Smallest Blood Vessels

• Capillaries
• Have small diameter and thin walls
• Chemicals and gases diffuse across walls

7
The Anatomy of Blood Vessels

• Arteries, veins, and capillaries
• Have different functions
• Have different structures

8
Structure of Vessel Walls
9
Arteries and Veins

• Walls have 3 layers
• tunica intima
• tunica media
• tunica externa

10
The Tunica Intima

• Is the innermost layer
• Includes
• the endothelial lining
• connective tissue layer

11
Internal Elastic Membrane

• In arteries, is a layer of elastic fibers in
  outer margin of tunica intima

12
Tunica Media

• Is the middle layer
• Contains concentric sheets of smooth muscle in
  loose connective tissue
• Binds to inner and outer layers

13
Tunica Media

• Exterman elastic membrane of the tunica media
• separates tunica media from tunica externa

14
Tunica Externa

• Is outer layer
• Contains connective tissue sheath
• Anchors vessel to adjacent tissues

15
Tunica Externa

• In arteries
• contain collagen
• elastic fibers
• In veins
• contain elastic fibers
• smooth muscle cells

16
Vasa Vasorum

• Small arteries and veins
• In walls of large arteries and veins
• Supply cells of tunica media and tunica externa

17
Arteries vs. Veins

• Arteries and veins run side-by-side
• Arteries have thicker walls and higher blood
  pressure
• Collapsed artery has small, round lumen
• Vein has a large, flat lumen

18
Arteries vs. Veins

• Vein lining contracts, artery lining does not
• Artery lining folds
• Arteries more elastic
• Veins have valves

19
Arteries and Pressure

• Elasticity allows arteries to absorb pressure
  waves that come with each heartbeat

20
Contractility

• Arteries change diameter
• Controlled by sympathetic division of ANS

21
Structure of Blood Vessels
Figure 21-2
22
Artery Characteristics

• From heart to capillaries, arteries change
• from elastic arteries
• to muscular arteries
• to arterioles

23
Elastic Arteries

• Also called conducting arteries
• Large vessels (e.g., pulmonary trunk and aorta)
• Tunica media has many elastic fibers and few
  muscle cells
• Elasticity evens out pulse force

24
Muscular Arteries

• Also called distribution arteries
• Are medium-sized (most arteries)
• Tunica media has many muscle cells

25
Arterioles

• Are small
• Have little or no tunica externa
• Have thin or incomplete tunica media

26
Artery Diameter

• Small muscular arteries and arterioles
• changes with sympathetic or endocrine stimulation
• constricted arteries oppose blood flow

27
Resistance (R)

• The force opposing blood flow
• Resistance vessels
• arterioles

28
Aneurysm

• A bulge in an arterial wall
• Is caused by weak spot in elastic fibers
• Pressure may rupture vessel

29
Capillaries

• Are smallest vessels with thin walls
• Microscopic capillary networks permeate all
  active tissues

30
Capillary Function

• Location of all exchange functions of
  cardiovascular system
• Materials diffuse between blood and interstitial
  fluid

31
Capillary Structure

• Endothelial tube, inside thin basal lamina
• No tunica media
• No tunica externa
• Diameter is similar to red blood cell

32
Capillary Structure
Figure 21-4
33
2 Types of Capillaries

1. Continuous capillaries
2. Fenestrated capillaries

34
Continuous Capillaries

• Have complete endothelial lining
• Are found in all tissues except epithelia and
  cartilage

35
Functions of Continuous Capillaries

• Permit diffusion of
• water
• small solutes
• Lipid-soluble materials
• Block
• blood cells
• plasma proteins

36
Specialized Continuous Capillaries

• Are in CNS and thymus
• Have very restricted permeability
• e.g., the bloodbrain barrier

37
Fenestrated Capillaries

• Have pores in endothelial lining
• Permit rapid exchange of water and larger
  solutes
• between plasma and interstitial fluid

38
Fenestrated Capillaries

• Are found in
• choroid plexus
• endocrine organs
• kidneys
• intestinal tract

39
Sinusoids

• Areas in
• liver
• spleen
• bone marrow
• endocrine organs
• Have gaps between adjacent endothelial cells

40
Sinusoids

• Permit free exchange
• of water and large plasma proteins
• between blood and interstitial fluid
• Phagocytic cells monitor blood at sinusoids

41
Capillary Networks
Figure 21-5
42
Capillaries Networks

• Capillary bed or capillary plexus
• Connect 1 arteriole and 1 venule

43
Thoroughfare Channels

• Direct capillary connections between arterioles
  and venules
• Controlled by smooth muscle segments
  (metarterioles)

44
Collaterals

• Multiple arteries that contribute to 1 capillary
  bed
• Allow circulation if 1 artery is blocked
• Arterial anastomosis
• fusion of 2 collateral arteries

45
Arteriovenous Anastomoses

• Direct connections between arterioles and venules
• Bypass the capillary bed

46
Capillary Sphincter

• Guards entrance to each capillary
• Opens and closes, causing capillary blood to flow
  in pulses

47
Veins

• Collect blood from capillaries in tissues and
  organs
• Return blood to heart

48
Veins vs. Arteries

• Are larger in diameter
• Have thinner walls
• Carry lower blood pressure

49
3 Vein Categories

• Venules
• very small veins
• collect blood from capillaries

50
3 Vein Categories

• Medium-sized veins
• thin tunica media and few smooth muscle cells
• tunica externa with longitudinal bundles of
  elastic fibers

51
3 Vein Categories

• Large veins
• have all 3 tunica layers
• thick tunica externa
• thin tunica media

52
Valves in the Venous System
Figure 21-6
53
Vein Valves

• Folds of tunica intima
• Prevent blood from flowing backward
• Compression pushes blood toward heart

54
Venous Blood Distribution

• 1/3 of venous blood is in the large venous
  networks of the liver, bone marrow, and skin

55
Veins Response to Blood Loss

• Vasomotor centers stimulate sympathetic nerves
• systemic veins constrict (venoconstriction)
• veins in liver, skin and lungs redistribute
  venous reserve

56
What are the principle blood vessels and
functional characteristics of the special
circulation to the brain, heart, and lungs?
57
Special Circulation

• Through organs with separate mechanisms to
  control blood flow
• brain
• heart
• lungs

58
Blood Flow to the Brain

• Is top priority
• Brain has high oxygen demand
• When peripheral vessel constrict, cerebral
  vessels dilate, normalizing blood flow

59
Heart Attack

• A blockage of coronary blood flow
• Can cause
• angina
• tissue damage
• heart failure
• death

60
Pulmonary Blood Pressure

• In pulmonary capillaries
• is low to encourage reabsorption
• If capillary pressure rises
• pulmonary edema occurs

61
Circulation Patterns
Figure 21-18
62
3 Distribution Patterns

• Peripheral artery and vein distribution
• is the same on right and left, except near the
  heart

63
3 Distribution Patterns

• The same vessel
• may have different names in different locations

64
3 Distribution Patterns

• Tissues and organs usually have multiple arteries
  and veins
• vessels may be interconnected by anastomoses

65
What are the major arteries and veins of the
pulmonary circuit and the areas they serve?
66
The Pulmonary Circuit
Figure 21-19
67
The Pulmonary Circuit (1 of 3)

• Deoxygenated blood arrives at heart from systemic
  circuit
• passes through right atrium and ventricle
• enters pulmonary trunk

68
The Pulmonary Circuit (2 of 3)

• At the lungs
• CO2 is removed
• O2 is added

69
The Pulmonary Circuit (3 of 3)

• Oxygenated blood
• returns to the heart
• is distributed to systemic circuit

70
Pulmonary Vessels

• Pulmonary arteries
• carry deoxygenated blood
• Pulmonary veins
• carry oxygenated blood

71
Pulmonary Arteries

• Pulmonary trunk
• branches to left and right pulmonary arteries
• Pulmonary arteries
• branch into pulmonary arterioles
• Pulmonary arterioles
• branch into capillary networks that surround
  alveoli

72
Pulmonary Veins

• Capillary networks around alveoli
• join to form venules
• Venules
• join to form 4 pulmonary veins
• Pulmonary veins
• empty into left atrium

73
What are the major arteries and veins of the
systemic circuit and the areas they serve?
74
Major Systemic Arteries
Figure 21-20
75
The Systemic Circuit

• Contains 84 of blood volume
• Supplies entire body
• except for pulmonary circuit

76
Arteries of the Chest and Upper Limbs
77
Systemic Arteries

• Blood moves from left ventricle
• into ascending aorta
• Coronary arteries
• branch from aortic sinus

78
The Aorta

• The ascending aorta
• rises from the left ventricle
• curves to form aortic arch
• turns downward to become descending aorta

79
Branches of the Aortic Arch

• Deliver blood to head and neck
• brachiocephalic trunk
• left common carotid artery
• left subclavian artery

80
The Brachiocephalic Trunk

• Branches to form
• right subclavian artery
• right common carotid artery

81
The Subclavian Arteries

• Branches within thoracic cavity
• internal thoracic artery
• vertebral artery
• thyrocervical trunk

82
The Subclavian Arteries

• Leaving the thoracic cavity
• become axillary artery in arm
• and brachial artery distally

83
The Brachial Artery

• Divides at coronoid fossa of humerus
• into radial artery and ulnar artery

84
Radial and Ulnar Arteries

• Fuse at wrist to form
• superficial and deep palmar arches
• which supply digital arteries

85
Arteries of the Neck and Head
86
The Common Carotid Arteries

• Carry blood to head and neck
• Each common carotid divides into
• external carotid artery
• internal carotid artery

87
The External Carotid

• Supplies structures of
• neck
• lower jaw
• face

88
Arteries of the Brain
89
The Internal Carotid Artery

• Enters skull and divides into
• opthalmic artery
• anterior cerebral artery
• middle cerebral artery

90
The Vertebral Arteries

• Also supply brain with blood supply
• Left and right vertebral arteries
• arise from subclavian arteries
• enter cranium through foramen magnum
• fuse to form basilar artery

91
The Basilar Artery

• Branches to form posterior cerebral arteries
• Posterior cerebral arteries
• become posterior communicating arteries

92
Anastomoses

• The cerebral arterial circle interconnects
• the internal carotid arteries
• and the basilar artery

93
Arteries of the Trunk
94
The Descending Aorta

• Is divided by diaphragm into
• thoracic aorta
• abdominal aorta

95
Arteries of the Trunk
96
Branches of the Thoracic Aorta

• Are anatomically grouped into
• visceral
• parietal

97
4 Visceral Branches

• Supply organs of the chest
• bronchial arteries
• pericardial arteries
• esophogeal arteries
• mediastinal arteries

98
2 Parietal Branches

• Supply chest wall
• intercostal arteries
• superior phrenic arteries

99
The Abdominal Aorta

• Divides at terminal segment of the aorta into
• left common iliac artery
• right common iliac artery

100
Branches of the Abdominal Aorta

• Unpaired branches
• major branches to visceral organs
• Paired branches
• to body wall
• kidneys
• urinary bladder
• structures outside abdominopelvic cavity

101
Arteries of the Abdominopelvic Organs
102
3 Unpaired Branches of the Abdominal Aorta

• Celiac trunk, divides into
• left gastric artery
• splenic artery
• common hepatic artery
• Superior mesenteric artery
• Left mesenteric artery

103
5 Paired Branches of the Abdominal Aorta

• Inferior phrenic arteries
• Suprarenal arteries
• Renal arteries
• Gonadal arteries
• Lumbar arteries

104
The Abdominal Aorta

• Divides to form
• right and left common iliac arteries
• middle sacral artery

105
The Common Iliac Arteries

• Divide to form
• internal iliac artery
• external iliac artery

106
Arteries of the Lower Limbs
107
The External Iliac Arteries

• Pass through abdominal wall
• Becomes femoral arteries

108
The Femoral Artery

• Branches to
• deep femoral artery
• Becomes popliteal artery
• posterior to knee

109
The Popliteal Artery

• Branches to form
• posterior tibial artery
• anterior tibial artery

110
The Anterior Tibial Artery

• Becomes dorsalis pedis artery at the ankle

111
The Posterior Tibial Artery

• Gives rise to the fibular artery
• Divides at ankle to form
• medial and lateral plantar arteries
• Dorsal arch and plantar arch
• supply distal foot and toes

112
Major Systemic Veins
113
Complementary Arteries and Veins

• Run side by side
• Branching patterns of peripheral veins are more
  variable

114
Differences in Artery and Vein Distribution

• In neck and limbs
• 1 set of arteries (deep)
• 2 sets of veins (1 deep, 1 superficial)
• Venous system controls body temperature

115
All Systemic Veins

• Drain into either
• superior vena cava (SVC)
• or inferior vena cava (IVC)

116
Veins of the Head, Neck, and Brain
117
The Superior Vena Cava (SVC)

• Receives blood from
• head
• neck
• chest
• shoulders
• upper limbs

118
The Dural Sinuses

• Superficial cerebral veins and small veins of the
  brain stem
• empty into network of dural sinuses

119
5 Cerebral Sinuses

1. Superior and inferior sagittal sinuses
2. Petrosal sinuses
3. Occipital sinus
4. Left and right transverse sinuses
5. Straight sinus

120
Cerebral Veins

• Great cerebral vein
• drains to straight sinus
• Other cerebral veins
• drain to cavernous sinus
• which drains to petrosal sinus

121
The Left and Right Transverse Sinuses

• Converge to form sigmoid sinus
• which leaves skull as internal jugular vein

122
Vertebral Veins

• Empty into brachiocephalic veins of chest

123
Superficial Veins of the Head

• Converge to form
• temporal, facial, and maxillary veins

124
Veins of the Neck

• Temporal and maxillary veins
• drain to external jugular vein
• Facial vein
• drains to internal jugular vein

125
Veins of the Abdomen and Chest
126
Veins of the Hand

• Digital veins
• empty into superficial and deep palmar veins
• which interconnect to form palmar venous arches

127
Superficial Veins of the Forearm

• Superficial arch empties into
• cephalic vein
• median antebrachial vein
• median cubital vein

128
Deep Veins of the Forearm

• Deep palmar veins drain into
• radial and ulnar veins
• which fuse above elbow to form brachial vein

129
The Brachial Vein

• Merges with basilic vein
• To become axillary vein

130
Veins of the Upper Arm

• Cephalic vein joins axillary vein
• to form subclavian vein

131
The Subclavian Vein

• Merges with external and internal jugular veins
• to form brachiocephalic vein
• which enters thoracic cavity

132
Veins of the Thoracic Cavity

• Brachiocephalic vein receives blood from
• vertebral vein
• internal thoracic vein

133
The Left and Right Brachiocephalic Veins

• Merge to form the superior vena cava (SVC)

134
Tributaries of the SVC

• Azygous vein and hemiazygous vein which receive
  blood from
• intercostal veins
• esophageal veins
• veins of other mediastinal structures

135
Tributaries of the Superior Vena Cava
136
Tributaries of the Inferior Vena Cava
137
The Inferior Vena Cava (IVC)

• Collects blood from organs inferior to the
  diaphragm

138
Veins of the Lower Limbs
139
Veins of the Foot

• Capillaries of the sole
• drain into a network of plantar veins
• which supply the plantar venous arch

140
The Plantar Network

• Drains into deep veins of leg
• anterior tibial vein
• posterior tibial vein
• fibular vein

141
Deep Veins of the Leg

• Join to become popliteal vein
• anterior tibial vein
• posterior tibial vein
• fibular vein

142
The Dorsal Venous Arch

• Collects blood from
• superior surface of foot
• digital veins

143
The Dorsal Venous Arch

• Drains into 2 superficial veins
• 1. great saphenous vein
• which drains into femoral vein
• 2. small saphenous vein
• which drains into popliteal vein

144
The Popliteal Vein

• Becomes the femoral vein
• At the femur

145
The Femoral Vein

• Before entering abdominal wall, receives blood
  from
• great saphenous vein
• deep femoral vein
• femoral circumflex vein
• Inside the pelvic cavity
• becomes the external iliac vein

146
The External Iliac Veins

• Are joined by internal iliac veins
• to form right and left common iliac veins

147
The Right and Left Common Iliac Veins

• Merge to form the inferior vena cava

148
Veins of the Abdomen
149
6 Major Tributaries of the Abdominal Inferior
Vena Cava

• Lumbar veins
• Gonadal veins
• Hepatic veins
• Renal veins
• Suprarenal veins
• Phrenic veins

150
The Hepatic Portal System
151
The Hepatic Portal System

• Connects 2 capillary beds
• Delivers nutrient-laden blood
• from capillaries of digestive organs
• to liver sinusoids for processing

152
5 Tributaries of the Hepatic Portal Vein

• Inferior mesenteric vein
• drains part of large intestine
• Splenic vein
• drains spleen, part of stomach, and pancreas
• Superior mesenteric vein
• drains part of stomach, small intestine, and part
  of large intestine

153
5 Tributaries of the Hepatic Portal Vein

• Left and right gastric veins
• drains part of stomach
• Cystic vein
• drains gallbladder

154
Blood Processed in Liver

• After processing in liver sinusoids, blood
  collects in hepatic veins and empties into
  inferior vena cava

155
Fetal Circulation

• Embryonic lungs and digestive tract nonfunctional
• Respiratory functions and nutrition provided by
  placenta

156
Placental Blood Supply
Figure 21-33a
157
Placental Blood Supply

• Blood flows to the placenta
• through a pair of umbilical arteries
• which arise from internal iliac arteries
• and enter umbilical cord

158
Placental Blood Return

• Blood returns from placenta
• in a single umbilical vein
• which drains into ductus venosus
• Ductus venosus
• empties into inferior vena cava

159
The Neonatal Heart
Figure 21-33b
160
Before Birth

• Fetal lungs are collapsed
• O2 provided by placental circulation

161
At Birth

• Newborn breathes air
• Lungs expand
• Pulmonary circulation provides O2

162
2 Fetal Pulmonary Circulation Bypasses

• Foramen ovale
• interatrial opening
• covered by valve-like flap
• directs blood from right to left atrium
• Ductus arteriosus
• short vessel
• connects pulmonary and aortic trunks

163
Cardiovascular Changes at Birth

• Pulmonary vessels expand
• Reduced resistance allows blood flow
• Rising O2 causes ductus arteriosus constriction
• Rising left atrium pressure closes foramen ovale

164
Congenital Cardiovascular Problems
Figure 21-34
165
Congenital Cardiovascular Problems

• Develop if proper circulatory changes do not
  occur at birth
