INTRODUCTION TO BIOECONOMIC MODELS

1
INTRODUCTION TO BIOECONOMIC MODELS FOR FISHERY
- THE SCHAEFER-GORDON MODEL
Dr. Mahfuzuddin Ahmed International Center for
Living Aquatic Resources Management
2
What is a Fishery?
Fishery is a stock or stocks of fish and the
enterprises that have the potential of exploiting
them
3
Fish Stock and Fishery Management
Influence of socioeconomic and institutional
factors
A complex process of integration of resource
biology and ecology
Behavior of fishers and policymakers
4
Syndrome of Overexploitation
Both biological and economic overexploitation
Failure of market (under unrestricted access)
from optimally allocating fishery resources
Unclear property rights regime
5
Syndrome of Overexploitation . . .

• Conflicting interest over rights and duties can
  lead to fisheries collapse

• Generate externalities between resource-users
  (Seijo et al 1998)

? stock externalities ? crowding
externalities ? technological externalities ? ecol
ogically based externalities ? techno-ecological
externalities
6
Developing Country Syndrome

• High exclusion cost
• Social trap and the free rider behavior
• High transaction cost

? information cost ? enforcement
cost ? contractual cost

• Inadequate legal and institutional framework

7
Fishery Management

• Decisionmaking aiming at a sustainable management
  of fish stocks
• Biological, ecological, economic, social and
  legal analysis
• Identify and quantify the objectives and goals of
  management
• Select appropriate combination of performance
  variables and determine the control variable

8
Fishery Management . . .

• Determine alternative management strategies and
  implementation mechanism
• Monitor and evaluate the impacts of alternative
  management strategies and plans
• Revise and redo plans, if necessary

9
Bioeconomic Model

• Assumes allocation of property rights as a way to
  mitigate risks of stock overexploitation
• Bioeconomic Model allows the evaluation of the
  fishery in biological, economic and ecological
  sense
• Provide an optimal allocation of efforts and
  output and help achieve the desired level of
  performance criteria

10
The Basic Biological Model
Assumptions

• Single fish stock
• Stock growth over time (logistic growth)
• Model

G dP f(P) dt
(1)
G growth P initial population
11
The Basic Biological Model . . .
The growth of population is proportional to
initial population, i.e.,
G aP
(2)
a intrinsic growth
12
The Basic Biological Model . . .
There must be a maximum size of population that
can be supported. It is called Environmental
Carrying Capacity (ECC) denoted by K. Hence,
G aP(K-P)/k aP(1 - P) K
(3)
13
The Basic Biological Model . . .
Maximum growth occurs when population size is
half of ECC, i.e.,
G a(1 - 2P) 0 K
Hence,
P K/2
(4)
14
The Basic Biological Model . . .

The biological productivity curve
15
The Effect of Fishing the Short-Run
Once fishing is introduced yield or catch at any
period will depend on

• size of fish population
• amount of fishing effort

(5)
Y y (P,f)
Y yield f fishing effort
16
The Fishing Effort
Economic measure

• boat, gear, crew and other inputs required for
  fishing
• called as nominal effort (f) and is calculated by
  using standardized measure such as
  vessel-ton-days

17

The Fishing Effort ...
Biological measure

• Effective effort (F) the fraction of the average
  population taken by fishing
• F is often calculated as the negative of natural
  logarithm of proportion of fish surviving fishing
  in a year

18

The Fishing Effort ...

• Both nominal and effective efforts are related by

F qf
(6)

q catchability coefficient represents
the state of technical efficiency
19
The Fishing Effort .

• Using nominal effort we can define yield
  equation for short-run as

(7)
Y qfP
20

Yield and population size

Short-run yield as a function of population size

• for a given level of nominal effort, yield will
  vary with population size

21


Diminishing returns to population size

Short-run yield with diminishing returns to
population
22

This gives a short-run yield equation as
Y qPfa
(8)

Where 0 lt alt 1
23

Diminishing Returns to Nominal Effort
- upper limit to yield in the short run
(9)
Y qfbP

Short-run yield with diminishing returns to
nominal effort
24
The Long-Run Equilibrium in a Fishery
Combining biological production with the yield
function
G aP(K-P)/k aP(1 - P) K
Y qfbP
(3)
(9)

We obtain
G aP(1-P)-qfbP K
(10)
25
The Long-Run Equilibrium

The impact of fishing on the population size
For an effort level f1, a population P2 and a
yield of Y2 may be sustained into the long run,
because yield from fishing, Y2 will be balanced
by the growth of stock. G2
26
The Long-Run Equilibrium .
To find equilibrium let us set equation (10) to
zero which gives

P K(1-qfb) a
(11)
27
The Long-Run Equilibrium . . .
For the chosen effort level, equation (11) tells
us the sustainable population Different effort
levels will produce different sustainable
yield We can now derive a sustainable yield
function by using equations (9) and (11)

(11)
P K(1-qfb) a
Y qfbP (9)
28
The Long-Run Equilibrium . . .
These give us
(12)
Ys Kfqb (1-qfb) a

If b 1, sustainable yield is a simple quadratic
function of effort. In this case the sustainable
yield curve will simply be the mirror image of
the biological productivity curve.
29
The Long-Run Equilibrium . . .
The relationship between biological productivity
curve and sustainable yield curve for various
values of b (0 lt b lt 1) is shown by

Sustainable yield curves
The greater are diminishing returns (lower b )
the longer it takes to reach a maximum
30
The Long-Run Equilibrium . . .
Setting equation (12) to zero and solving for f
gives
(13)
fmax (a/q) 1/b
- can be referred to as the effort that reduces
sustainable yield to zero (extinction of stock)
31
The Long-Run Equilibrium . . .
MSY - Differentiate (13) with respect to effort
and set it to zero
(14)
fmsy (a/2q) 1/b
If b 1, MSY is half of fmax
In general, fmsy (1/2)1/bfmax
(15)
32
The Economics of Fishing - Revenue

Revenue as a function of fishing effort
33
Long-run total revenue function
TRf pYs
Which by substitution from equation (12) gives
TRf pKqfb(1-qfb) a
(16)
Which is a function of f
ARf TRf f
(17)
MRf d(TRf) df
(18)
34
The Economics of Fishing - Cost
TCf cf
ACf MCf

Cost as a function of fishing effort
35
The Bioeconomic Equilibrium

The open-access equilibrium
36
Model Limitations
1. All processes affecting stock productivity
(e.g. growth, mortality and recruitment) are
subsumed in the effective relationship between
effort and catch. 2. The catchability coefficient
q is not always constant, and may differ due to
e.g. different aggregation behavior of pelagic
and sedentary resources. - factors related to
differential gear selectivity by age/lengths are
not taken into account
37
Model Limitations . . .
3. CPUE is not always an unbiased index of
abundance. - relevant to sedentary resources with
patchy distribution and without the capacity of
redistribution in the fishing ground once fishing
effort is exerted - sequential depletion of
patches also determines a patchy distribution of
resource users, precluding model applicability
4. Variations in spatial distribution of the
stock are usually ignored, as well as the
biological processes that generate biomass, the
intra/interspecific interactions, and stochastic
fluctuations in the environment and in population
abundance.
38
Model Limitations . . .
5. Ecological and technological interdependencies
and differential allocation of fishing effort in
the short term are not usually taken into
account. 6. Improvement in technology and fishing
power determines that q often varies through
time. 7. It becomes difficult to distinguish
whether population fluctuations are due to
fishing pressure or natural processes. - in some
fisheries, fishing effort could be exerted at
levels greater than twice the optimum.
39
Other Models
1. Dynamic Bioeconomic Model (Smith) 2.
Yield-Mortality Models - exponential -
precautionary
3. Age Structured Bioeconomic Model 4.
Intertemporal Analysis
40
Other considerations for extension of bioeconomic
models 1. Ecological and technological
interdependence 2. Social and institutional
factors
41
(No Transcript)
42
Overview of Models

Differing impacts of diminishing returns to
nominal effort on sustainable yield
43
Overview of Models

The impact of fishing when diminishing returns to
population are present
44
Overview of Models

The sustainable yield curve when diminishing
returns to population are present
45
Overview of Models

The effect of shifting revenue curves on the
open-access equilibrium
46
Overview of Models
Fundamental relationship between catch, effort
and costs in a fishery
47
Overview of Models

Market equilibrium of fishery sector in a
supply-demand model
48
Overview of Models
Gordon-Schaefer Model
Sustainable a) biomass, b) yield and c) total
sustainable revenues (TSR) and costs (TC).
49
Overview of Models
Population logistic growth model for K 3.5
million tonnes and r 0.36
50
Overview of Models
Open access regime. A) Sustainable average and
marginal yields b) average and marginal costs
and revenues, as a function of effort under open
access conditions
51
Gulf of Thailand

Market equilibrium of fishery sector in a
supply-demand model
52
Gulf of Thailand

53
Gulf of Thailand

54
Gulf of Thailand
