Development of a Model to Calculate Fuel Tank Flammability

1
Development of a Model to Calculate Fuel Tank
Flammability

• Ivor Thomas
• Consultant to FAA
• 1-425 455 1807
• fuelsguy_at_msn.com

2
Presentation Agenda

• Concept
• Approach
• Assumptions
• Results
• Conclusions

3
Initial Problem

• Need To be able to assess flammability in
  airplane fuel tanks so that safety enhancements
  could be assessed against each other.
• Problem Flights all over the world create widely
  varying conditions and times when a tank may be
  flammable, but FAA needed to assess the overall
  safety benefits of any enhancement

4
Concept

• Create a computer model to
• Assess tank flammability for a large number of
  flights throughout the world,
• Assess the impact of any enhancements on reducing
  overall flammability,
• look at risks in specific conditions,
• (and make it simple enough to run quickly).

5
Approach

• Monte Carlo technique to create several thousand
  flights in worldwide atmospheric conditions with
  critical variables such as flash point of the
  fuel also varying to represent the real world.
• This approach required several sub-models
• The airplane performance
• The tank thermal response
• The atmosphere
• The fuel
• The system enhancement proposed

6
Monte Carlo Analysis

• Technique to allow a statistical analysis of a
  problem with a number of independent variables
• Technique uses known distribution probabilities
  for variables and runs 1000s of cases with
  randomly selected values for each variable in
  each case.
• End result is a large amount of data, but
  typically the fleet average exposure is used as a
  reference for the tank in question.
• Specific high risk areas can be examined, such as
  days above 80 deg F

7
Airplane Performance

• An airplane performance model was developed to
  allow various airplanes to be studied, which
  included
• Time on the ground
• Fuel load
• Climb Time/Speed schedule
• Cruise Alt. And Mn. including step climbs on
  longer flights
• Descent and Landing Time/Speed schedule in
  Descent
• Mission Length Distribution

8
(No Transcript)
9
(No Transcript)
10
Tank Thermal Response

• Tank treated as simple object with thermal
  response characteristics determined from separate
  thermal modeling or flight test.
• Characteristics defined by
• Exponential time constant for full and empty
  conditions both ground and flight
• Equilibrium temperature the tank would reach
  (given enough time) relative to total air
  temperature for both ground and flight

11
(No Transcript)
12
Atmospheric model

• Any flight uses two inputs,
• Ground ambient, and
• Ambient temperature above the Tropopause.
• For any given flight, the two values are picked
  randomly to match the known world temperature
  distribution

13
(No Transcript)
14
Atmospheric model

• The Temperature Profile versus Altitude is the
  determined, using a standard lapse rate to the
  tropopause, and constant above, with a
  temperature inversion effect if the ground
  ambient is below 00 F.

15
(No Transcript)
16
(No Transcript)
17
Fuel Variability and Flammability

• The FAA has surveyed the fuels being used by the
  fleet and determined the flash point range and
  distribution,
• Fuel Air Ratio at the Flash Point has been
  measured for a number of these fuels, and this
  has been used to correlate Flammability range to
  Flash Point

18
(No Transcript)
19
(No Transcript)
20
Flammability Assessment

• A Computer model was created to integrate all the
  factors discussed to predict fuel tank
  flammability
• Model can run one flight to look at specific
  risk, or
• Model can run several thousand flights to
  determine fleet average fuel tank flammability
  exposure.
• Model can determine flammability for specific
  ranges of conditions

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
Potential Mitigating Effects

• The model can be used to assess mitigating
  systems
• Reduced heat flow to the tank
• Increased heat flow out of the tank
• Fuel Tank Inerting
• Ground Only
• In-flight
• In-Flight with limitations (e.g. High nitrogen
  flow in Descent)
• Other Flammability Reduction methods

25
Potential Mitigating Effects (Continued)

• The model must be modified by the user to
  represent the reduction methodology.
• For any system the model computes if the tank
  flammable every one minute. The user can add
  instructions to overlay this and change a
  flammable count to a non-flammable count if
  the system is effective at that point in the
  flight.

26
Potential Mitigating Effects (Continued)

• For Example,
• A ground based inerting system is effective once
  the tank is flooded with N2, and will stay that
  way until the tank breathes in sufficient air to
  dilute the N2.
• IF the tank is empty, the tank remaining inert
  until the end of cruise,
• IF the tank is full, the tank will become
  un-inert early in cruise
• Algorithms added to the model can compute this
  and reduce flammability appropriately.

27
(No Transcript)
28
Current Status

• The Flammability Exposure model has given the FAA
  and industry a common tool to assess fuel tank
  flammability and to evaluate potential mitigating
  actions.
• The 747 proposed Special Condition uses the model
  to define the current and expected flammability
  exposure when an NGS or other flammability
  reduction method is added.

29
Current Status

• FAA is drafting a revised AC25.981-2 with the
  assistance of AIA to reflect this approach.

30
Model Enhancements

• FAA model is generic and must be made specific
  for a given airplane.
• Thermal models
• Fleet mission distribution
• Daily flight distribution effects
• Mitigation System effects

31
Cautions

• The original model was developed by ARAC I to
  assess the correlation of flammability to the
  fleet accident history
• ARAC I concluded that low flammability tanks,
  (fleet average exposure below 7) could be
  considered acceptable but high flammability tanks
  needed t o be addressed
• As the model is refined and modified the 7 may
  need to be examined for its validity.

32
Conclusions

• FAA has provided a tool to allow the industry to
  assess flammability in fuel tanks and to evaluate
  the effectiveness of mitigating actions.
• Enhancements could be incorporated but we must
  recognize the model is a comparative tool not an
  absolute predictor of flammability.
• The baseline Low Flammability level of 7 needs
  to be examined carefully if too many enhancements
  to the model are made.

33
The Fourth Triennial International Aircraft Fire
and Cabin Safety Research Conference
The Fourth Triennial International Aircraft Fire
and Cabin Safety Research Conference
