Power Analysis of WEP Encryption

1
Power Analysis of WEP Encryption

• Jack Kang
• Benjamin Lee
• CS252 Final Project
• Fall 2003

2
Outline

• Background and Motivation
• Objective
• Theory
• Experimental Methodology
• Experimental Results
• Conclusions
• Future Work Directions
• Questions

3
Background and Motivation (1/4)

• The Digital Divide
• Gap between the digitally empowered and digitally
  poor, between developing and developed nations
• Can information and communication technologies
  (ICT) close the gap?
• There are social AND economic reasons to solve
  this problem

4
Background and Motivation (2/4)

• Problems
• More talk than action
• Financial sustainability
• Coordination of activities
• Scope
• E-governance

5
Background and Motivation (3/4)

• Bottom of The Pyramid (BOP)
• Prahad argues that it is profitable to serve the
  poor
• Multinational Corporations have financial
  incentive to step in

Prahalad, C.K. and Hammon, Allen, Serving the
World's Poor, Profitably, Harvard Business
Review, 9/2002.
6
Background and Motivation (4/4)

• So what about the technical problems?
• Low-cost
• Low-power
• Intermittent Connectivity
• User Interfaces for populations with multiple
  languages and low levels of literacy
• Shared accesses as a possibly dominant use mode
• Limited skilled workforce for maintenance

7
Objective

• Evaluate high-level software optimizations and
  low-level hardware configurations for reducing
  power dissipation applied to WEP encryption
• Provide a framework for further study in wireless
  communication infrastructure for developing
  regions

8
Theory Loop Unrolling

• A compiler technique that extends the size of
  loop bodies by replicating the body n times
• The loop exit condition is then adjusted
  accordingly
• Why is power saved?
• More efficient front end less branches means
  the fetch unit is able to fetch large blocks
  without being interrupted by control decisions
• Less branches in the code means reduced power
  dissipation of the branch prediction hardware

9
Theory Cache Optimizations

• Choices in associativity and block sizes will
  affect the miss rate of the cache.
• Power can be saved if we can reduce the miss
  rate.
• No need to go off chip
• Better performance means we may be able to lower
  the clock frequency (and thus voltage levels) and
  still meet minimum performance needs

10
Experimental Methodology

• Software WEP encryption
• Software is cheaper (low-cost)
• Easier to upgrade (limited maintenance)
• SimpleScalar
• Simulates hardware and software configurations
• Wattch
• Provides power estimation

11
Wired Equivalent Privacy (1/3)

• Overview
• 802.11 wireless standard
• Provides wireless network with security
  equivalent to wired network
• Confidentiality
• Access Control
• Data Integrity

12
Wired Equivalent Privacy (2/3)

• Encryption

Hirani, Sohail A. Energy Consumption of
Encryption Schemes in Wireless Devices. Masters
Thesis. University of Pittsburgh, April 2003.
13
Wired Equivalent Privacy (3/3)

• Decryption

Hirani, Sohail A. Energy Consumption of
Encryption Schemes in Wireless Devices. Masters
Thesis. University of Pittsburgh, April 2003.
14
SimpleScalar (1/2)

• Baseline Simulation - Microprocessor
• In-order issue
• No branch prediction
• Minimal number of functional units
• Integer ALU
• Floating Point ALU
• Integer Multiplier/Divider
• Floating Point Multiplier/Divider

15
SimpleScalar (2/2)

• Baseline Simulation Memory
• L1 Instruction Cache
• 16-KB cache
• 32-byte blocks
• Full associativity
• L1 Data Cache
• 16-KB cache
• 32-byte blocks
• 4-way associativity
• Unified L2 Cache
• 18-KB cache
• 32-byte blocks
• 4-way associativity

16
Wattch (1/2)

• Overview
• Framework for analyzing and optimizing
  microprocessor power dissipation at the
  architectural level
• Wattch v1.02
• SimpleScalar Interface
• Simulated PISA instruction set
• Built on Pentium 4/x86 platform

17
Wattch (2/2)

• Conditional Clocking Styles
• NCC No conditional clocking
• CC1 Simple conditional clocking
• Zero power dissipation with zero accesses
• CC2 Aggressive conditional clocking (ideal)
• Linear power dissipation with fractional accesses
• CC3 Aggressive conditional clocking
  (non-ideal)
• 15 power dissipation with zero accesses

18
Experimental Results (1/3)
19
Cache Associativity (2/3)
20
Cache Associativity (3/3)
21
Conclusions

• Significant power savings from software and
  hardware optimizations
• Loop Unrolling
• Max 17 reduction
• Median 15.9 reduction
• Mean 15.9 reduction
• Cache Associativity
• Max 12.5 reduction
• Median 4 reduction
• Mean 5 reduction

22
Future Work Directions

• Study combined effects of optimizations
• Apply these optimizations for new microprocessor
  configurations
• Apply these optimizations to a larger test suite

23
References

• David Brooks, Vivek Tiwari, and Margaret
  Martonosi, Wattch A Framework for
  Architectural-Level Power Analysis and
  Optimizations, 27th International Symposium on
  Computer Architecture (ISCA), June 2000.
• Doug Burger and Todd M. Austin, The SimpleScalar
  Tool set, Version 2.0, Computer Architecture
  News, pages 13-25, June 1997.
• Sohail Hirani, Energy Consumption of Encryption
  Schemes in Wireless Devices, Masters
  Dissertation, University of Pittsburgh, 2003.
• Kenneth Keniston, Grassroots ICT projects in
  India Some Preliminary Hypotheses, ASCI Journal
  of Management 31(12), 2002.
• C.K. Prahalad and Allen Hammon, Serving the
  World's Poor, Profitably, Harvard Business
  Review, September 2002.
• C.K. Prahalad and Stuart L. Hart, The Fortune at
  the Bottom of the Pyramid, strategybusiness,
  issue 26, 2002.
• SimpleScalar toolset. http//www.simplescalar.com
• Wattch toolset. http//www.ee.princeton.edu/dbroo
  ks/wattch-form.html

24
Questions

• Any Questions?
