Data Structures-CSE207

1
Data Structures-CSE207
2
Course Detail

• BASIC CONCEPTS OF ALGORITHM
• (1.2.1,1.4,1.4.1,1.4.2,1.4.3 of Text3)
• POINTERS AND POINTER APPLICATIONS
• (9-3 to 9-7, 10.1 to 10.6 of Text1)
• DERIVED TYPES (12.1,12.2,12.4-12.7 of Text1)
• RECURSION (3.1-3.5 of Text2)
• STACKS AND QUEUES (3.1,3.2,3.4,3.5 of Text3)
• LINKED LIST (4.2-4.4,4.8 of Text3)
• TREES (5.1,5.2,5.3,5.7,10.2 of Text3)
• GRAPHS AND THEIR APPLICATIONS (6.1-6.4 of Text3)
• SEARCHING AND SORTING (7.1,7.3,7.4 of Text3)
• HASHING (8.2 of Text3)

3
Text Books

• Behrouz A. Forouzan, Richard F. Gilberg A
  Structured Programming Approach Using C,Thomson,
  2nd Edition, 2003.
• Aaron M. Tenenbaum,Yedidyah Langsam,Moshe J.
  Augeustein,Data Structures using C, PEARSON
  Education , 2006.
• Ellis Horowitz, Sartaj Sahni , Anderson,
  Fundamentals of Data Structures in C, Silicon
  Press, 2nd Edition, 2007.

4
REFERENCES

• Richard F. Gilberg, Behrouz A. Forouzan, Data
  structures, A Pseudocode Approach with C,
  Thomson, 2005.
• Robert Kruc Bruce Lening, Data structures
  Program Design in C, Pearson Education, 2007.
• Mark Allen Weiss, Data Structures and Algorithm
  Analysis in C, Prentice Hall

5
DataStructure

• Definition
• A data structure is a particular way of storing
  and organizing data in a computer so that it can
  be used efficiently.

6
Basic concepts of Algorithm

• An algorithm is a finite set of instructions that
  , if followed , accomplishes a particular task.
• Characteristics of an algorithm
• Input These are 0 or more quantities that are
  externally supplied.
• Output At least one quantity is produced
• Definiteness Each instruction is clear and
  unambiguous.
• Finiteness If we trace out instructions of an
  algorithm,then for all cases ,the algorithm
  terminates after a finite number of steps
• Effectiveness Every instruction must be basic
  enough to be carried out, in principle by a
  person using a pencil and paper.i.e instructions
  must be feasible.

7
Sorting-Ascending

• Selection sort algorithm
• Find the minimum value in the list
• Swap it with the value in the first position
• Repeat the steps 1 and 2 for the remainder of the
  list (starting at the second position and
  advancing each time)
• Example
• 64 25 12 22 11
• 11 25 12 22 64
• 11 12 25 22 64
• 11 12 22 25 64
• 11 12 22 25 64

8
Selection sort algorithm bit revised

• for(i0iltni)
• Examine listi to listn-1 and suppose that the
  smallest integer is at listmin
• Interchange /swap listi with listmin.

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Performance Analysis

• Space Complexity The space complexity of a
  program is the amount of memory it needs to run
  to completion.
• Time Complexity The time complexity of a program
  is the amount of computer time it needs to run to
  completion

13
Space complexity

• A fixed part that is independent of the
  characteristics of the inputs and outputs. This
  part typically includes the instruction space,
  space for simple varialbes and fixed-size
  component variables, space for constants, etc.
• A variable part that consists of the space needed
  by component variables whose size is dependent on
  the particular problem instance I being solved,
  the space needed by referenced variables, and the
  recursion stack space.
• The space requirement S(P)of any program P is
  written as S(P) c Sp(I) where c is a constant
  and Sp(I) is variable part.

14
Examples

• float abc(float a,float b, float c)
• return abcbc
• Sabc(I)0
• float sum(float list,int n)
• float tempsum0 int i
• for (i0iltni) tempsumlisti
• return(tempsum)
• in C Ssum(I)0

15

• float rsum(float list,int n)
• if(n) return rsum(list,n-1)listn-1)
• return 0
• Srsum(I)6n

16
Time complexity

• The time, T(P), taken by a program P is the sum
  of the compile time and the run (or execution)
  time. The compile time does not depend on the
  instance characteristics. We focus on the run
  time of a program, denoted by Tp (instance
  characteristics).

17

• Determining Tp requires detailed knowledge of
  Compiler translation procedure.
• Obtaining such a detailed estimate is rarely
  worth the effort.
• We count no.of operations in a program
• This gives us a m/c independent measure
• But we should know how to divide the program into
  distinct steps.

18

• Definition A program step is a syntactically or
  semantically meaningful program segment whose
  execution time is independent of instance
  characteristics.
• A2 and A2ab/cd both are treated as steps one
  each though their actual time differs. What we
  need is they should be independent of instance
  characteristics

19
Computation of timecomplexity using global count
method

• float sum(float list,int n)
• float tempsum0 count//assignment
• int i
• for (i0iltni) count//whole for loop as
  one // step
• tempsumlisti count//assignment
• count //last execution of for
• count //for return
• return(tempsum)
• // count2n3

20

• float rsum(float list,int n)
• count //for if condition
• if(n)count //for return and rsum //invocation
• return rsum(list,n-1)listn-1)
• count// for return0
• return 0
• //count2n2

21
Calculate step count for

• void add(int amaxsize,int bmaxsize,int
  cmaxsize,int rows,int cols)
• int i,j
• for(i0iltrowsi)
• for(j0jltcolsj)cijaijbij

22
Finding stepcount using tabular method

• We first find steps/execution or s/e .
• Next we find number of times that each statement
  is executed.This is called frequency.
• s/efrequency gives us step count for each
  statement
• Summing these for every statement gives total
  step count for whole function.

23
Total steps
frequency
s/e
Statement
0 0 1 0 n1 n 1 0
0 0 1 0 n1 n 1 0
0 0 1 0 1 1 1 0
float sum(float list,int n) float
tempsum0 int i for (i0iltni)
tempsumlisti return(tempsum)
2n3
Total
24
Total steps
frequency
s/e
Statement
0 0 n1 n 1 0
0 0 n1 n 1 0
0 0 1 1 1 0
float rsum(float list,int n) if(n) return
rsum(list,n-1)listn-1) return 0
2n2
Total
25
Total steps
frequency
s/e
Statement
0 0 0 r1 rcr rc 0
0 0 0 r1 r(c 1) r.c 0
0 0 0 1 1 1 0
void add(int amaxsize,int bmaxsize,int
cmaxsize,int rows,int cols) int
i,j for(i0iltri) for(j0jltcj) cijai
jbij
2rc2r1
Total
26
Asymptotic Notation

• Determining step counts help us to compare the
  time complexities of two programs and to predict
  the growth in run time as the instance
  characteristics change.
• But determining exact step counts could be very
  difficult. Since the notion of a step count is
  itself inexact, it may be worth the effort to
  compute the exact step counts.
• Definition Big oh f(n) O(g(n)) iff there
  exist positive constants c and n0 such that f(n)
  cg(n) for all n, n n0

27
Examples of Asymptotic Notation

• 3n 2 O(n)
• 3n 2 4n for all n 3
• 100n 6 O(n)
• 100n 6 101n for all n 10
• 10n2 4n 2 O(n2)
• 10n2 4n 2 11n2 for all n 5
• Note O(2)O(1)constant computing time

28
Asymptotic Notation (Cont.)

• Theorem 1.2 If f(n) amnm a1n a0, then
  f(n) O(nm).
• Proof
• for n 1
• So, f(n) O(nm)

29
Asymptotic Notation

• f(n)O(g(n)) only states that g(n) is an
  upperbound on the value of f(n) for all values of
  ngtn0. nO(n2),nO(n3).
• Inorder for this statement to be informative g(n)
  must be as small function of n one can come up
  with for which f(n)O(g(n)).So we say 3n2O(n)
  rather than O(n2).
• Lastly f(n)O(g(n)) does not imply O(g(n))f(n).
  Here should be read as is

30
Asymptotic Notation (Cont.)

• Definition Omega f(n) O(g(n)) iff there
  exist positive constants c and n0 such that f(n)
  cg(n) for all n, n n0. (n0gt0)
• Example
• 3n 2 O(n) as 3n2gt3n ngt1
• 100n 6 O(n) as 100n6gt100n ,ngt1
• 10n2 4n 2 O(n2) as 10n2 4n 2 gtn2 ,ngt1.
• Like O(n) here g(n) is only a lower bound on
  f(n)i.e g(n) should be as large a function of n
  as possible for which the statement f(n) O(g(n))
  is true.
• Hence we never say 3n2 O(1) though it is true.

31
Asymptotic Notation (Cont.)

• Definition f(n) T(g(n)) iff there exist
  positive constants c1, c2, and n0 such that
  c1g(n) f(n) c2g(n) for all n, n n0.
• 3n2 T(n) as 3n2lt4n,ngt2 and 3n2gt3n ngt2
• f(n) T(g(n)) iff g(n) is both upper and lower
  bound of f(n).
• Note In all these we neglect coefficients i.e we
  do not say 3n2O(3n) though it is correct

32
Asymptotic Notation (Cont.)

• Theorem 1.3 If f(n) amnm a1n a0 and am
  gt 0, then f(n) O(nm).
• Theorem 1.4 If f(n) amnm a1n a0 and am
  gt 0, then f(n) T(nm).

33
Use of Asymptotic notations

• The asymptotic complexity can be determined quite
  easily without determining the exact step count.
• We determine asymptotic complexity of each or a
  group of statements in a program and then add
  these to get total asymptotic complexity

34
Asymptotic complexity
Statement
0 0 0 T(r) T(r.c) T(r.c) 0
void add(int amaxsize,int bmaxsize,int
cmaxsize,int rows,int cols) int
i,j for(i0iltri) for(j0jltcj) cijai
jbij
T(r.c)
Total
35
Practical Complexities

• If a program P has complexities T(n) and program
  Q has complexities T(n2), then, in general, we
  can assume program P is faster than Q for a
  sufficient large n.
• However, caution needs to be used on the
  assertion of sufficiently large.

36
Function Values
log n
n
n log n
n2
n3
2n
0
1
0
1
1
2
1
2
2
4
8
4
2
4
8
16
64
16
3
8
24
64
512
256
4
16
64
256
4096
65536
5
32
160
1024
32768
4294967296
37
S.T.The following statements are correct/incorrect

• 5n2-6n T(n2).
• 2n2nlogn T(n2)
• 10n29O(n)
• N2logn T(n2).
