Introduction To ArcCatalog

1
Introduction To ArcCatalog
2
ArcCatalog is a data-centric GUI tool used for
managing spatial data
3
With ArcCatalog you can.

• Inspect properties and attributes of data
• Preview and explore data contents
• Evaluate quality and suitability of data
• Create, move, copy, delete, organize, and rename
• Review, update and define metadata
• Import, export, convert
• Define rules and behavior

4
ArcCatalog Gives You.

• Direct access to all your data live.
• Connections to any local or network disks.
• Connections to local or remote folders.
• Connections to relational databases via
• ArcSDE
• MS SQL Server, Oracle, DB2, Sybase, etc.
• OLE DB
• MS Access (jet), Oracle, MS SQL Server, etc.
• Typically OLE DB can retrieve only non-spatial
  data
• Personal geodatabases
• MS Access (jet)

5
ArcCatalog Is Better Equipped to Allow GIS
Analysts To

• Manage the GIS data explosion
• Control consistency and quality of data
• Maintain inventory of data holdings
• Expose incomplete metadata
• Identify redundant data

6
ArcCatalog Is the Principal User Interface Used
to Define and Manage the Geodatabase
7
What is a Geodatabase?

• A new type of geographic data format (GDF) for
  ArcInfo 8.
• Based on Object-Oriented Model
• Users can add behavior, properties, rules and
  relationships to data
• Implemented as extension to standard relational
  database technology
• Supports topologically integrated feature classes
• Extends the coverage model with support for
  complex networks, relationships among feature
  classes, and other object-oriented features
• Provides platform for development of custom data
  models using visual tools like CASE (Computer
  Aided Software Engineering) tools and UML
  (Unified Modeling Language) notation

8
Geodatabase Framework
9
Geographic Feature Data Formats

• Formats are based on representations (models) of
  the real world that can be placed in a GIS to
  produce maps, perform interactive queries, and
  execute analyses.
• CAD first computer mapping model/format.
• Binary file format with little attribute
  information.
• Coverage native ArcInfo 7 format.
• Based on Georelational data model.
• Vector data is maintained in indexed binary files
  and partitioned from, but linked to attribute
  tables by a common identifier.
• Topological relationships are maintained.
• Shortcomings features aggregated into
  collections of points, lines polygons with
  generic behavior. The behavior of a line
  representing a road is the same as the behavior
  of a line representing a stream.

10
Geographic Feature Data Formats

• Shapefile introduced with ArcView
• Also georelational data model nontopological
  vector data format.
• Very prolific format much GIS data in Shapefile
  format.
• Simpler than coverages than because they do not
  store topological associations among different
  features and feature classes.
• Limited analysis capabilities due to lack of
  topology
• Geodatabase introduced in ArcInfo 8.
• Object-oriented model can characterize features
  more naturally by defining object types,
  topological, spatial and general relationships,
  and interactions.
• Geodatabase features can be stored in a single
  database.
• Create custom features in addition to points,
  lines, polygons
• Brings physical model closer to logical model.

11
Supported Data Types

• ArcInfo 8 supports four representations of
  geographic data.
• Vector data for representing features.
• Raster data for images, grids, and surfaces.
• Triangulated irregular networks (TINS) for
  surfaces.
• Tabular data.
• Locators and addresses for finding a geographic
  position from an address.
• Locators apply national postal conventions to
  convert an address to a position.
• Note in AI8, geodatabases do NOT store TINS.
  They must be kept in coverage workspaces.

12
Three Ways to Create a Geodatabase

• Create from scratch.
• Use tools in ArcCatalog to create schema for
  feature datasets, tables, geometric networks,
  etc.
• Migrate existing data.
• Can convert by importing shapefiles, coverages,
  INFO tables, dbase tables, ArcStorm, Map
  LIBRARIAN, and ArcSDE layers.
• Both spatial and non-spatial object component is
  translated.
• Use CASE (Computer Aided Software Engineering)
  tools.
• Can use CASE tools to create new custom objects
  and generate a geodatabase schema from UML
  (Unified Modeling Language).

13
Single-user Geodatabase

• Personal Geodatabase.
• Implemented as a Microsoft Access database (.mdb
  file) by using MS jet engine which is installed
  with AI8. MS access is not needed.
• Can be placed on local or network drives.
• Generally used for personal or small work-group
  use.
• Can handle small to moderately sized datasets.
• Personal geodatabase can yield decent performance
  for datasets of 250,000 objects or less.
• Full functionality of geodatabase served through
  ArcSDE except versioning.
• Versioning allows many editors to work
  concurrently and includes framework to resolve
  edit conflicts.
• If a personal geodatabase is deleted its gone.

14
Multi-user (Enterprise) Geodatabase

• ArcSDE Geodatabase
• ArcSDE is the multi-user data access extension to
  ArcInfo (bundled w/software) that serves
  geodatabases to AI applications running on pcs
  on TCP/IP network.
• Used for demanding datasets requiring concurrent
  editing by multiple users.
• Created by installing a DBMS and ArcSDE on a
  server.
• ArcCatalog only creates and deletes connections
  to ArcSDE geodatabases.
• Can be deployed on UNIX or Windows NT.
• Many use UNIX platform for ArcSDE and DBMS and NT
  for AI applications
• ArcSDE is centrally tuned and managed by a DBA.
• Can build SQL applications to access tables in a
  remote geodatabase.

15
Geodatabase Elements

• Objects
• Object classes
• Features
• Feature classes
• Feature datasets
• Relationships
• Relationship classes
• Geometric networks
• Domains
• Subtypes
• Spatial references

16
Objects Object Classes

• Geodatabases organize geographic data into a
  hierarchy of data objects.
• Objects are instances of an object class that
  have properties and behavior.
• Objects can be related to other objects via
  relationships
• Objects have unique system identifiers (OID)
• Object classes are tables in a geodatabase
  storing non-spatial data (e.g., Parcel owners)
• Objects in an object class have the same
• Properties - stored in the table as attributes
• Behavior - implemented as a component

17
Object Classes (tables)
Pump Table Pump Table Pump Table Pump Table
OID Pump Type Inlet Size .
175 Axial Flow 24 .
.
A row stores an Object
18
Features and Feature Classes

• Features are objects with required shape (Points,
  Multi-points, Lines Polygons) that represent a
  real world object in a layer on a map.
• Features classes are collections of features with
  same type of feature geometry and attributes.
• A feature class is also an object class which
  stores spatial objects (features)(e.g., Parcels).
• All the features in a feature class are in the
  same spatial reference.
• Feature classes which store topological features
  must be contained within a feature dataset to
  ensure a common spatial reference.

19
Feature Classes
Feature Class Table
Lateral Water Lines Lateral Water Lines Lateral Water Lines Lateral Water Lines
OID Shape Type .
583 X,Y,Z,M Domestic .
.
A row stores feature
20
Feature Datasets

• Containers for feature classes
• Shared spatial reference
• Analogous to a coverage
• less restrictive
• May also contain
• relationship classes
• geometric networks

21
Relationships and Relationship Classes

• Relationships are an association between two or
  more objects in a geodatabase that can exist
  between
• spatial objects (features in feature classes)
• nonspatial objects (rows in tables)
• spatial and nonspatial objects
• Related objects can message each other
• origin to destination
• destination to origin
• Both or Neither
• Relationships can trigger behavior
• Cascade, delete, move to follow, custom behavior
• Relationships are stored in a Relationship Class

22
Relationships
Parcels (Spatial)
Owners Non-Spatial
23
Relationship Behavior
24
Geometric Networks

• A topological relationship among a collection of
  feature classes in a feature dataset
• Used to model network systems
• Topology
• Based upon geometric coincidence
• Always live
• Features are constrained to exist within the
  network

25
Geometric Networks

• Network features classes must reside in a
  geometric network
• Directly support network analysis
• Types of Network Features Junction or Edge
• Junction and edge features can be Simple or
  Complex

26
Domains

• Describe the legal values of a field type
• Used to ensure attribute integrity
• Can be shared among classes
• Uniquely named
• Types of domains
• Range domains
• Example- Water distribution mains can have a
  pressure between 40 and 100 psi
• Coded value domains
• Example - Water distribution mains can have a
  diameter of 10, 24 or 36 inches

27
Subtypes

• Feature class subclasses that allow you to
  further distinguish objects without creating new
  feature classes
• Same attributes and behavior
• Can have different default values and domains for
  each field
• Example in a feature class which stores Water
  Mains
• Steel mains can be 0 to 150 psi
• PVC mains can be 0 to 100 psi
• Both are subtypes of the Mains feature class

28
Spatial References

• Describes the projection, spatial domain (X,Y,Z
  M values), and precision for feature datasets or
  feature classes in a geodatabase.
• All feature classes within a feature dataset
  share the same spatial reference.
• Once created, the spatial domain for feature
  dataset/class cannot be changed.
• Data outside extent of dataset need to be created
  in a new dataeset or standalone feature class.

29
For additional detail on the geodatabase
seegeodatabase.ppt
30
ArcCatalog and Metadata

• Metadata is primarily viewed and edited in
  ArcCatalog.
• ArcCatalog allows metadata to be easily created,
  stored, and accessed for all data types supported
  by ArcInfo 8.0 using open, flexible, industry
  standard technology.
• AI8 has out-of-the-box support for the federal
  geographic data committee (FGDC) metadata content
  standard,
• ArcCatalog has a built-in and easily accessible
  full-featured metadata editor.
• AI8 automatically stores metadata with the data
  so that it also travels when the data is moved,
  distributed, exported, or renamed, including
  attached documents.

31
ArcCatalog and Metadata

• Bottom line metadata editor is easy to use.
• Result more organized and accurate data.

32
Underlying Metadata Technology XML

• XMLeXtensible Markup Language
• Document-oriented structured data
• Next step beyond HTML
• Separates data content from
• Content definition
• Content display
• Extensible Markup Language allows specific markup
  to be created for specific data. It has the
  virtues of HTML without its limitations.
• Big advantage is in the portability
• In essence, it travels with the data

33
Where Is Metadata Stored?

• All data types and containers have metadata
• Coverages XML file stored in coverage folder
• Shapefiles images XML file in same location as
  shapefile or image.
• Example Cities.shp will have Cities.shp.xml file
• Folders ArcInfo Workspaces can also have
  metadata Metadata.xml file stored in folder
• Geodatabase data XML stored in the database
  itself
• Example If access database, XML is with .mdb
  file
• Metadata can include attached documents and
  images, e.g., Word, .Jpg.

34
Creating and Editing Metadata

• Choose dataset and click the metadata tab
• Metadata is automatically created if it doesnt
  exist
• This can be turned on/off
• Some metadata is automatically obtained
  (harvested) from the data
• You can control frequency of metadata harvesting
• Automatic time interval
• Manually
• Any file type can be added as an attachment to
  the metadata to extend metadata information

35
ArcCatalog Metadata Editor

36
Extending and Customizing Metadata

• Metadata framework can be extended for various
  custom applications
• Data inventory and management
• Quality control
• Identify and remove redundant data
• Custom metadata import / export
• Very easy to create Metadata for WWW
• Custom metadata publication / search

37
A Simple Right-click of the Mouse Yields Property
Dialog Boxes for All Data Types
38
Working with Coverages

• In ArcCatalog you can.
• Generate topology
• Define coordinate systems
• Modify coverage tics and extent
• Set coverage tolerances
• Create coverage realtionship classes
• Maintain attributes
• Create new coverages

39
Generating Coverage Topology

• Right-click on coverage
• Go to properties
• Click the General tab
• See if topology or FAT exists
• Click feature class to build topology for
• Build or Clean

40
Define Coverage Coordinates

• Right-click and go to properties
• From file menu go to properties
• Can define interactively
• Can copy information from another grid, coverage,
  or TIN

41
Modifying Coverage Tics and Extent

• Right-click on coverage
• Go to properties
• Click the Tics and Extent tab
• Click add
• Click and add to XY
• Fit button recalculates extent

42
Creating New Coverages

• Right click on ArcCatalog folder where you want
  to create a coverage and go to NEW and
  COVERAGE
• Follow steps in create coverage wizard
• Can create a new empty coverage or use a master
  coverage for a template
• The tics, extent, and coordinate system
  information are all copied to from the template
  coverage to the new coverage
• If you do not use a template, you have to add
  tics before adding features

43
Maintaining Coverage Attributes

• With attributes that reside in a feature
  attribute table or separate INFO table ArcCatalog
  can.
• Add new attributes.
• Add redefined attributes.
• Used to combine or create subsets of existing
  attributes.
• Modify.
• Delete.
• Add/remove indexes.
• Attribute indexes help to improve the performance
  of operations that access it.
• If an attribute containg feature geometry is
  indexed, a spatial index is created.
• Always recreate an index after modifying
  attribute values.

44
From ArcCatalog you can add and edit the
properties of fields in tables, shapefiles and
feature classes by right clicking on the object
and going to properties.
45
ArcCatalog Is Highly Customizable

• ArcCatalog is customizable at three levels
• Menu driven, drag and drop (requires no
  programming)
• Position toolbars on or off the application
• Add, move, remove controls
• Create new menu
• Add custom macros tools w/ Visual Basic for
  Applications (VBA)
• Built in VBA scripting
• Customize user interface
• Automate tasks
• Add new forms and controls
• Object component programming
• AI8 is COM (component object model) compliant and
  can be customized with any COM compliant
  programming language
• Visual Basic, Visual C, Visual J, Delphi

46
The ArcCatalog Window
ESRI Metadata Viewer
Detachable Catalog Tree
47
Folder Connections
CAD Dataset (Blue)
CAD Drawing File
Coverages (Yellow)
Raster Datasets (Grid)
Layers (Bright Yellow)
The ArcCatalog Window
48
The ArcCatalog Window
Personal Geodatabase (Grey)
ArcMap Document (.mxd)
Projection (Globe)
Shapefiles (Green)
ArcView Dbase Table (Green) ArcInfo Info Table
(Yellow)
49
The ArcCatalog Window
Preview Tab
TIN Dataset
50
The ArcCatalog Window
Geodatabase
Feature Dataset
Relationship Class
Feature Classes
Annotation Class
51
Projection Files .prj
Options
52
Options
53
Options
54
Options
55
Options
56
Creating Thumbnails
57
Thumbnails
58
Customizing
59
Wizards for Creating Database Connections
Remote Database Connection (Grey Cylinder
w/network)
Database Table (Blue)
Database Connections
60
Add Coverage Attributes
61
Adding Fields
62
Adding Fields
