Rolling

1
Rolling And Extrusion
2

• Rolling Process
• Points
• Significant shape change
• Capital intensive
• Large volume
• Usually hot worked (isotropic)
• Oxide scale
• Tolerances difficult to hold

Can be followed by cold rolling to improve
tolerances and directional properties
3
Rolling Products
Billet Blooms (gt 6 x 6)
Slab Ingots Billets (gt 1.5 x 1.5)
Slab (gt 10 x 1.5)
4
vr
Rolling Model
R
q
p
vo
vf
to
tf
L

• Assumptions
• Infinite sheet
• Uniform, perfectly rigid rollers
• Constant material volume to wo Lo tf wf Lf
  rate (to wo vo tf wf vf )
• where Lo initial plate length Lf
  final plate length

vr
R roller radiusp roll pressure L
contact lengthq contact angle vr roll speed
to initial plate thickness tf final plate
thickness vo plate entry speedVf plate exit
speed
5
Rolling Model
Define draft d to - tf Draft limit
dmax m2R m 0.1 cold m 0.2
warm m 0.4 1.0 hot Define forward slip
s (vf vr)/vr Does it make sense that vr
lt vf?
6
Rolling Model stress, strain, force, power
7
Other rolling configurations
8
Example 21.1 in text
9

• Extrusion
• Limitation requires uniform cross-section vs
  length
• Advantages
• Variety of shapes
• Control mechanical properties in cold and warm
  extrusion
• Little wasted material
• Good tolerances
• Types Direct extrusion and indirect extrusion

Less friction!
10
Extrusion Model

• Assumptions
• Circular cross-section
• Uniform stress distribution

p ram pressure L remaining billet
lengthDo chamber diameter Df extrudate
diameter
11
Extrusion Model stress and strain
Ao billet (chamber) area Af extrudate area
a 0.81.2 b 1.5
12
Extrusion Model stress and strain
13
Extrusion Model non-circular sections
14
Extrusion Model forces and power
Ram force F pAo Power P Fv
15
(No Transcript)
16
(No Transcript)
17
Rolling and Extrusion
What have we learned?
