HLA and antigen presentation

1
HLA and antigen presentation

• Institute of Immunology
• University Hospital
• Motol

2
Structure and function of HLA

• history
• structure of HLA gens and molecules
• function of HLA moleculs
• nomenclature of HLA system
• HLA association with disease
• antigen presentation

3
HLA - MHC

• HLA molecules are responsible for the
  compatibility of the tissues of
  genetically different individuals
• combination of HLA molecules is unique in each
  individual
• monozygotic twins have the same
  histocompatibility molecules on their
  cells
• HLA molecules are responsible for the rejection
  of transplant
• HLA molecules present antigens and provoke immune
  reaction leading to the transplant rejection and
  destruction
• histocompatibility molecules are called
  histocompatibility antigens or transplantation
  antigens.

4
HLA - immune system development

• Histocompatibility molecules are glycoproteins
  expressed at the surface of all vertebrate cells.

• HLA molecules represent the latest stage of the
  development of the immune system.

5
structure of HLA molecules

• Two classes of HLA molecules are recognized and
  designed HLA class I. and HLA class II.
• HLA molecules of both classes are glycoproteins,
  heterodimers, composed from two chains. At least
  one of the chains is polymorphic.
• Structure of HLA molecules of both classes
  enables antigen binding and contact with T cell
  receptors.

6
HLA class I. molecules

• Class I molecules consist of three parts
• a transmembrane protein, called the heavy chain.
  The outermost domains contain two segments of
  polymorphic alpha helix that form two ridges
  with a groove between them called a1and a2, a3 is
  nonpolymorphic domain close to the membrane..
• a molecule of beta-2 microglobulin (ß2m), which
  is attached noncovalently to the heavy chain
• peptide bound to the groove formed by a1and a2
  domaines

7
structure of HLA class I. molecules

• HLA class I. molecules are composed from
• heavy a chain
• b-2 microglobulin
• peptide

8
HLA A,B,C

• Humans synthesize three different types of class
  I. molecules designated HLA-A, HLA-B, and HLA-C.
• These differ only in their heavy chain, all
  sharing the same type of beta-2 microglobulin.
• HLA class I. molecules are expressed on all
  nucleated cells of the body.
• HLA class I. molecules are not expressed on red
  blood cells and only minor level of expression is
  detected on the cells of central nervous system.
• The genes encoding the different heavy chains are
  clustered on chromosome 6 in the major
  histocompatibility complex.

9
HLA class II. molecules

• Class II molecules consist of two transmembrane
  polypeptides an alpha chain and a beta chain.
  Both chains are polymorphic.
• The alpha and beta chains are encoded by clusters
  of loci in the region of chromosome 6 designated
  HLA-D.
• HLA class II. molecules form 3 types, designed
  HLA DR, DP and DQ.
• Class II molecules are not as widely expressed in
  the body as the class I molecules are. However,
  cells where inflammation is occurring express
  class II strongly and provide a powerful stimulus
  to the immune system.

10
Structure of HLA class II. molecules

• Class II molecules consist of two transmembrane
  polypeptides and bound peptide.

11
Structure of HLA class I. and II. molecules

• HLA class I. HLA class II.

12
HLA and peptides

• antigenic peptids in the binding sites of HLA
  molecules
• class I.
• class II.

13
HLA genes
chromozom 6
HLA region
D HLA class III. B C E A G F
DP DQ DR

• HLA class III. are soluble molecules as
  complement, TNF, HSP
• HLA DR a chain is not polymorphic

14
HLA haplotypes

• Haplotype is combination of allelic forms of HLA
  molecules on one chromosome.
• We inherit 3 types of heavy chains for HLA class
  I. molecules from each parent .
• Everybody expresses 6 different types of HLA
  class I. molecules unless honmozygous status for
  some of the types was inherited.

A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
A
B
C
15
HLA polymorfism

• Genes for HLA are the most polymorhic structures
  from all known systems.
• The diversity of alleles in the population makes
  possible thousands of different combinations. In
  a study of 1000 blood and organ donors in San
  Francisco that were typed for HLA-A and HLA-B,
• Over half the group had a combination that was
  unique.
• Another 111 donors had a set of these molecules
  that they shared with only one other person in
  the group.
• The most frequent phenotype (HLA-A1, HLA-A3,
  HLA-B7, and HLA-B8) was found in 11 donors.

16
HLA typing

• The MHC of humans is now completely sequenced! A
  consortium of laboratories reports in the 28
  October 1999 issue of Nature that they have
  determined the sequence of 3,673,800 nucleotides
  on chromosome 6 that encode the genes of the MHC
  as well as many other genes involved in immune
  function.

17
HLA nomenclature
HLA Alleles Assigned July 2012 There are
currently 8159 HLA alleles described by the HLA
nomenclature and included in the IMGT/HLA
Database.
18
HLA nomenclature
19
HLA and antigen presentation

• Although histocompatibility molecules were
  discovered because of the crucial role they play
  in graft rejection, clearly evolution did not
  give vertebrates these molecules exclusively for
  that function.
• The main function of HLA molecules is the process
  called antigen presentation to T lymphocytes.

20
HLA and antigens

• Antigens presented to the immune system come from
  different sources. The main division of the
  antigens recognizes extracellular antigens and
  intracellular antigens.
• The nature of extracellular and intrcellular
  antigens differs markedly and both induce
  different type of immune reaction.
• Intracellular antigens are presented in
  connection with HLA class I.
• Extracellular antigens are presented in
  connection with HLA class II.

21
Antigen presentation

• Antigens are molecules able to induce immune
  response.
• Antigens are mostly proteins, glycoproteins or
  polysaccharides.
• Extracellular antigens enter the body from the
  environment. They are inhaled or ingested
  macromolecules or molecules that are introduced
  beneath the skin .
• Intracellular antigens are antigens that are
  generated within the cells of the body these
  would include proteins encoded by the genes of
  viruses that have infected a cell or aberrant
  proteins that are encoded by mutant genes such as
  mutated genes in cancer cells.

22
Antigen presenting cells and T
lymphocytes

• The recognition of antigen by T cells is
  necessary for induction of the immune response.
• The nature of the outcome of the immune response
  is directed according to the nature of presented
  antigen.
• exogenic antigen presentation

23
Antigen presenting cells and
T lymphocytes

• The recognition of antigen by T cells is
  necessary for induction of the immune response.
• The nature of the outcome of the immune response
  is directed according to the nature of presented
  antigen.
• endogenous antigen presentation

24
Exogenous antigens

• Exogenous antigens (inhaled, ingested, or
  injected) are taken up by "professional"
  antigen-presenting cells
• These include
• phagocytic cells like macrophages and dendritic
  cells
• B lymphocytes which are responsible
• for producing antibodies against the antigen.
• professional antigen-presenting cells
• All these cells expressed HLA class II. molecules

25
Exogenous antigens and cells

• Antigen presenting cells
• engulf the antigen by endocytosis
• degrade it into fragments (e.g. break an
  antigenic protein into short peptides)
• display these peptides at the surface of the cell
  nestled within
• a class II. histocompatibility molecule
• here they may be recognized by CD4 T cells

26
Exogenous pathway
CD4

• Steps of the exogenous antigen presentation
• The two chains of the class II molecule are
  inserted into the membrane of the RER.
• They bind (in their groove) one molecule of
  invariant chain.
• This trimolecular complex is transported through
• the Golgi apparatus and into vesicles called
  lysosomes.
• Invariant chain is actively deleted by HLA DM.
• Invariant chain is replaced by antigen.
• Complex of HLA and antigens moves to the surface
  of the cell.
• Complex HLA-antigen is recognized by CD4 positive
  lymfocyte.

APC
endosome
Golgi
ER
27
Endogenous antigens

• Antigens that are generated within a cell are
• degraded into fragments (e.g., peptides) within
  the cell in proteasome
• selected antigens are transported to ER with
  active action of TAP (transport associated
  protein)
• stable complex of HLA class I. and antigen is
  formed in ER, moves to Golgi
• displayed at the surface
• Here they may be recognized by CD8 T cells.
• Most CD8 T cells are cytotoxic.
• They have the machinery to destroy the infected
  cell (often before it is able to release a fresh
  crop of viruses to spread the infection).

28
Endogenous pathway

• HLA antigens class I. are expressed on all
  nucleated cells
• There are three subunits in each class I
  histocompatibility molecule
• the transmembrane polypeptide - heavy chain
• the antigenic peptide
• beta-2 microglobulin
• complex on the cell surface meets CD8 T
  lymphocyte

29
TAP

• Transport associated protein - TAP is
  responsible for the peptide transport from
  cytoplasm to ER.
• Proteins are degraded to peptide in proteasome.
• The peptides are picked up by TAP proteins and
  transported from the cytosol into the RER where
  they assemble with
• the transmembrane polypeptide and beta-2
  microglobulin.
• this trimolecular complex then moves through the
  Golgi apparatus and is inserted in the plasma
  membrane

proteazome
TAP
30
Antigen presentation pathways
exogenous antigens, HLA class II.
endogenous antigens, HLA class I.
31
B lymfocytes

• B lymphocytes process antigen by the class II
  pathway. However, antigen processing by B cells
  differs from that of phagocytic cells like
  macrophages in crucial ways.

32
BCR

• B cells engulf antigen by receptor-mediated
  endocytosis
• The affinity of B cells for an epitope on an
  antigen may be so high that the B cell can
  process the antigen when it is present in body
  fluids in concentrations thousands of times
  smaller than a macrophage would need
• The remaining steps of antigen processing occur
  by the same class II pathway
• The B cell grows into a clone of plasma cells
  under the influence of cytokines produces by CD4
  lymohocyte
• The antibodies are secreted into the surroundings

33
Antibodies

• antibody production

cytokines
34
Signal pathways, cell activation
35
Summary -antigen presentation pathways
endogenous exogenous B lymfocytes
cell destruction immune response
antibody production
36
Antigen presentation and T lymphocyts
37
Polarisation of T lymphocytes
38
Polarisation of T lymphocytes
39
Presentation of antigen and transplantation
40
Presentation of antigen and infection
41
Presentation of antigen and autoimmunity
42
Presentation of antigen and tumours
43
Presentation of antigen and vaccines
44
Presentation of antigen - summary
45
Presentation of antigen - summary
46
Presentation of antigen - summary
defective ribosomal products (DRiPs) mature
proteins (retirees) ER aminopeptidases (ERAP)
Peptides that fail to bind to MHC class I
molecules are removed by the translocon SEC61 and
enter the cytoplasm
Making sense of mass destruction quantitating
MHC class I antigen presentation Jonathan W.
Yewdell, Eric Reits Jacques Neefjes Nature
Reviews Immunology 3, 952-961 (December 2003)
47
Prezentace antigenu v obrane organismu
48
Antigen presenting cell and lymphocyte
49
Antigen presenting cell and lymphocyte
