High Performanc Wireless Reserach and Education Network

1
High Performance Wireless Research and
Education Network
An interdisciplinary collaboration
University of California, San Diego http//hpwren.
ucsd.edu/
2
HPWREN project objectives

• focus on access networks for research and
  education applications
• fixed or temporary installations
• wide area wireless high performance access
• emphasis on interdisciplinary collaboration
• non-commercial prototype network to demonstrate
  feasibility
• research to understand application performance
  requirements

3
Project participants and collaborators

• Funded by the National Science Foundations
  Networking Division (ANIR)
• Led by the UCSDs San Diego Supercomputer Center
  and Scripps Institution of Oceanography
• Science applications
• Scripps Institution of Oceanography
• Geophysics -- earthquake sensors
• San Diego State University, Astronomy department
• Mt. Laguna Observatory
• San Diego State University, Ecology
• Ecology field stations (Santa Margarita and Sky
  Oaks)
• Lawrence Berkeley National Laboratory and
  California Institute of Technology
• Palomar Observatory
• Education applications
• Pala Indian Reservation and Pala Fire Station
• La Jolla Indian Reservation

4
Network architecture

• high performance backbone network
• commercially available 45Mbps duplex
  point-to-point radios
• backbone nodes at quality locations, including
  UPS
• fairly large antennas (8, 6, or 4)
• network performance monitors at backbone sites
• high speed access links
• commercially available 802.11b radios
• some 45Mbps access links
• access nodes at individual sites
• point-to-point or point-to-multipoint
• small (2 X 3) grid antennas
• some sites include local performance monitors
• network statistics available at
  http//stat.hpwren.ucsd.edu/

5
ANZA Seismic Network--1999
6
Earthquake sensor and data collector on Toro Peak
7
IGPP Real-Time Systems

• ANZA Seismic Network (1981-present)
• 13 Broadband Stations
• 3 Borehole Strong Motion Arrays
• 5 Infrasound Stations
• 1 Bridge Monitoring System
• Kyrgyz Seismic Network (1991-present)
• 10 Broadband Stations
• IRIS PASSCAL Transportable Array (1997-Present)
• 15 - 60 Broadband and Short Period Stations

8
IRIS PASSCAL WirelessTelemetry Array

• Continuous real-time telemetry
• 15-60 Stations
• Integrate with other real-time data sources
• Deployments
• 1997-8 Colorado
• 1998-9 South Africa
• 1999-2000 Montana-Wyoming
• 2001 - Parkfield, California

9
HPWRENtopology--October 2001
Santa Margarita Ecological Reserve
Palomar Observatory
Pala Indian Reservation
Rincon Indian Res.
La Jolla Indian Reservation
San Pasqual Indian Reservation
Mt. Laguna Observatory
UCSD
Backbone node Science site Researcher
location Education site Incident mgmt. site
10
SDSUs Mt. Laguna astronomy observatory
11
High speed backboneplus MLO
North Peak
Stephenson Peak
Mt Laguna Observatory
Mt Woodson
UCSD/SDSC
12
Palomar Observatory
13
Red Mountain, CDF tower
14
May 2001Santa MargaritaEcological Reserve
15
Toro Peak,8700
Salton Sea
Boyd Deep Canyon
Pinyon Flats
16
Boyd Deep Canyon Desert Research Center
17
Example earthquake sensors in the desert
18
Initial PalaIndianReservationconnection
Mt. Woodson
19
La JollaIndian Reservation connection
Palomar Mountain relay site
La Jolla learning center
Mt. Woodson
UCSD/SDSC
20
La Jolla relay siteon Palomar Mountain
21
Video cameras
22
Researchers in the field

• antenna mounted on tripod
• connected to laptop PCMCIA card
• no external power or equipment

23
February 2001,CDF demonstration
24
Multi-agency crisis management demo28 August 2001
Inmarsat satellite
Sharp Hospital relay site
UCSD HPWREN Internet connection at SDSC
network- controllable video camera
64kbps ISDN link
DARPA ENCOMPASS Server at SSC
mobile weather station
Inmarsat ground station
Inmarsat satellite antenna
National Guard Armory
SSC Deployable Communications Support Terminal
25
Tribal Digital Village project

• Native American activity building up on HPWREN
• Funded by Hewlett Packard
• Awarded to the Southern California Tribal
  Chairmens Association
• HPWREN is collaborator, and not the service
  provider
• Objective of a utility architected and operated
  by Native Americans

26
San DiegoCountyNativeAmericanReservations
Pala
Pauma
Los Coyotes
La Jolla
Rincon
San Pasqual
Mesa Grande
Santa Ysabel
Inaja Cosmit
Captain Grande
Barona
Cuyapaipe
Vieja
Manzanita
La Posta
Campo
Sycuan
Jamul
27
San DiegoCountyIndianReservations----backbone
network
Pala
Los Coyotes
Pauma
La Jolla
Cluster 2
Cluster 1
Rincon
San Pasqual
Santa Ysabel
Mesa Grande
Inaja Cosmit
Cluster 3
Cuyapaipe
Barona
Captain Grande
Vieja
Manzanita
Cluster 4
La Posta
Campo
Sycuan
Jamul
28
ROADNetReal-time ObservatoriesApplications and
Data managementNetwork

• San Diego Supercomputer Center
• Scripps Institution of Oceanography
• University of California at San Diego

29
Project Research

• Yosemite
• Snowpack
• Climate
• Coastal Studies
• Pollution
• Erosion
• Deep Ocean
• Climate
• Weather
• Ecological Reserves
• CO2 Monitoring
• Watershed

• Geophysical Monitoring
• GPS
• Seismic
• HPWREN
• Wireless telemetry
• Network Analysis
• Data Management
• Scalable Architecture for Real-Time Data sharing
• Personalized Virtual Sensor Networks
• Information Discovery System

30
Information Technology Research Goals

• XML based integration and dissemination of
  information
• Continuous archives
• Access control systems

• Efficient, scalable sensor networks
• Wireless and high bandwidth technologies
• Network design flexibility

31
(No Transcript)
32
Earthscope -USArray, PBO, SAFOD, InSar Virtual
Seismic Network Planning Issues Realtime
telemetry Data Integration Processing Archiving
33
(No Transcript)
