The Internet

1
The Internet

• MCC - CIS105

2
Topics

• Briefly describe the history of the Internet
• Describe generally what an Internet service
  provider does
• Describe various types techniques used by
  Internet search sites
• Describe the various types of e-commerce
• Describe how advertising is done on the Internet
• Describe what an intranet is and how a business
  uses it

3
The Internet and Services

• The Internet is a worldwide collection of
  networks used to provide services such as
• World Wide Web (WWW) Websites
• Email, Instant Messaging (IM)
• Telephony Voice over IP (VoIP)
• Social network, newsgroups, discussion boards
• File Transfer Protocol (FTP)
• E-commerce business transactions
• For an overview of Making Use of the Web, see
  pages 116-131 in the textbook Discovering
  Computers 2008.

4
Internet - many networks connected together
5
Quick Time Line

• 1969 - ARPANET (Advanced Research Project Agency)
• Government sponsored the creation of a network.
• Scientists and military shared information.
• Network needed to provide alternative paths in
  case part of the network was destroyed (war).
• 1972 - E-mail capability added
• 1973 The internet went international
• 1986 - National Science Foundation (NFS)
  connected its large network, NSFnet,to ARPANET.
• 1995 NFS transferred service providing role
  to private companies.

6
Number of Users

• 2002 567 million users
• 2003 780 million users after 34 years
  (1969-2003) Compare to
• 2005 US population 295 million
• Telephone took 91 years to reach 100 million
  users.
• Television took 54 years to reach 100 million
  users.

7
Number of Sites

• Another way to measure the growth is by the
  number websites
• 1969 4 sites
• 1971 20 sites
• 1979 200 sites
• 1989 100,000 sites
• 2000 72,000,000 sites
• Why did it grow so much faster between 1989 and
  2000?
• One reason was the number Personal Computers
  grew.
• The other was the introduction of the Graphical
  Browser

8
Graphical Web Browser

• A Browser is software used to navigate on the
  Internet (Internet Explorer, Firefox, etc.).
• 1990 Dr. Berners-Lee from Geneva wanted to make
  the links from one website to another more
  dynamic and easy using hyperlinks .
• HyperText Markup Language (HTML) is the language
  used to create web pages.
• He described the links like a spiders web.
• Hence the name World Wide Web (WWW).
• 1992 Marc Andreessen, college student at
  University of Illinois and Eric J. Bina developed
  Mosaic first graphical web browser for multiple
  platforms.
• Graphical browser with hyperlinks and graphics.
• 1993 Andreessen and Ken McCarthy developed
  Netscape.

9
Internet Service Provider (ISP)

• An Internet Service Provider (ISP) provides the
  server computer and connection software for
  companies and individuals to connect to the
  Internet from their home or business (Earthlink,
  Qwest, Cox, Hughes, etc).
• Users at home need a modem to connect to their
  ISP.
• Dialup over phone lines
• DSL (digital subscriber line) - over phone lines
• Cable coaxial and/or fiber optic
• Fixed Wireless slow to catch on Tempe,
  Chandler
• Mobile Wireless cell phones, PDAs, laptops
• Satellite - Two modems (uplink and downlink)

10
TCP / IP

• TCP/IP is the communication standard (protocol)
  used on the Internet.
• Transmission Control Protocol (TCP) determines
  how messages are managed
• A message sent over the Internet is divided into
  uniformly sized packets.
• Each packet is labeled with its destination
  address.
• At the destination the message is reassembled
  using the sequencing information.
• Internet Protocol (IP) determines how
  communications software and equipment transport
  messages.

11
Uniform Resource Locator (URL)

• A URL is the complete and unique address of a
  Web page.
• Web page URL begins with http
• HyperText Transfer Protocol
• Domain name address of sites host computer
• Last part of domain name is called a top-level
  domain
• Identifies country and/or purpose of organization
• URL may include folder and specific filename.

12
Registering a Domain Name

• Internet Corporation for Assigned Names and
  Numbers (ICANN) is the group that assigns and
  controls top-level domain names.
• Outside the United States, the domain name also
  includes a country code.
• For example - Australia www.philips.com.au

13
Domain Name mapped to IP Address

• An IP address is a unique Numeric Address for
  each device on the Internet.
• An IP address consists of four groups of numbers
  separated with a period. IP Address
  http//64.233.167.99/
• Domain names are mapped to IP Addresses by a
  Domain Name Server (DNS).
• Domain names are meaningful and easier to
  remember for users. Domain
  http//www.google.com/
• Search for IP Addresses (use WhoIs Lookup)
  http//www.dnsstuff.com/
• Error 404 If domain name is not found in DNS.

14
User called Helpdesk because their Internet
connection was not working.

• Turns out the user had set the invalid URL as
  their homepage, so the error page was displayed
  every time they opened their browser ?.

15
Web Browser Limitation

• Browsers can process and display several formats
  such as HTML, gif, jpeg, JavaScript, etc.
• However, browsers cannot handle everything.
• Functionally is increased by using
• Plug-ins
• Helpers
• Web Programming
• See next few slides

16
Plug-ins / Helpers

• Software that increases browser functionality
• Most downloaded from their own Web sites
• Once downloaded and installed, it appears as if
  the browser can handle the new features.
• The features are being processed by the plug-ins.
• Most enhance a sites audio/visual experience
• Flash and QuickTime Players permit viewing sites
  that include quality animation
• Adobe Acrobat Reader displays and prints
  documents created in Portable Document Format
  (PDF) format

17
Web Page Programs

• Small programs can be downloaded to run in your
  browser
• Allow dynamic interaction and dynamic data
• Scripting languages (Client Side)
• Instructions to be interpreted and executed by
  your browser
• JavaScript and VBScript are most common
• Programming Languages (Client and Server Side)
• Java applets and ActiveX controls are most common
• Scripting languages that can call programs stored
  on the server include ASP, JSP, PHP, Perl, and
  others.
• May require additional software be installed such
  as Java Runtime Environment (JRE)
• Cookies information that a program stores on
  your hard disk so that it can remember something
  about you or your process at a later time.

18
Searching the Internet

• Search Engine
• Lets a user specify simple or complex search
  criteria.
• Search engine then searches the entries in its
  database and returns a list of sites that matches
  the criteria.
• Uses spider software to build database.
• Spiders crawl throughout websites collecting
  information can even find hidden files.
• Trivia - Google was supposed to be Googol, the
  number 1 followed by 100 zeros
• Internet directory list is developed by humans
  rather than a spider, so entries are very
  selective (yellowpages).
• www.mc.maricopa.edu/dept/d07/cis105/searchengines.
  html

19
Evaluating the Information

• Author
• Sources
• Server (who provides)
• Objectivity (balanced?)

• Purpose
• Accuracy
• Currency

20
Email

• Basic Electronic Mail (email) needs
• A server with email services
• Users need an account
• Need a client application to access the server
• SPAM is unsolicited e-mail.
• The term spam is said to derive from a famous
  Monty Python sketch.
• SPAM is a trademarked Hormel meat product.
• Phishing is e-mail fraud where the perpetrator
  sends out legitimate-looking e-mails that appear
  to come from well known and trustworthy Web sites
  in an attempt to gather personal and financial
  information from the recipient (see next slide).

21
Phishing Examples
22
Other Communication Services

• Social Networks myspace, facebook
• NewsGroups allows posting and reading of
  messages to a group for everyone to read
  (discussion board).
• IRC Internet Relay Chat
• Text Chatting in Real Time to a group, like a
  party line
• Instant Messaging to one person
• Internet Telephony Real-Time Voice and
  VideoVoIP Voice over IP (Internet Protocol)
• Internet Phone Services (Vonage)

23
File Transfer Protocol (FTP)

• Allows for upload and download of files.
• Anonymous FTP
• No username or password required.
• Uploading will most likely require a username and
  password.
• Some files are compressed into an archive using a
  program like WinZip, so the files need to be
  expanded or extracted after downloading.
• Self-extracting is an executable that is
  double-clicked to begin file extraction.
• If not self-extracting, will need a compatible
  program to extract files.

24
Homepage / Portal

• Homepage is the first page displayed when the
  browser is opened
• A portal is a website that is supposed to be set
  as your homepage.
• Webpage can be personalized so information you
  are interested in is displayed stock market,
  sports, weather
• May advertise referrals to businesses
• Yahoo, Google, MySpace, etc.

25
Internet Advertising

• Many advertisements on Web sites are banner ads
• Pop-over ads open a new window on top of your
  current window
• Pop-under ads open a new window underneath your
  current window
• All this advertising is to increase electronic
  commerce

26
Electronic Commerce

• B2B (Business to Business)
• B2C (Business to Consumer)
• C2C (Consumer to Consumer)
• Ebay.com watch for fraud
• CraigsList.org Free classified ads
• Payments SSL Secure Sockets Layer
• ePal is a 3rd party that handles payments.
• Internet Taxes Freedom Act
• No sales tax on out-of-state sales
• But usually need to pay shipping
• Privacy companies must provide you their
  privacy policy.

27
Intranets Extranets

• An Intranet is a private Internet-like network.
• Uses the same technology as used for an Internet
  site.
• Internal only computers on the same network may
  access services ie Employee Information
• Extranets allow selected customers and suppliers
  to have access to a companys intranet.
• EDI Electronic Data Interchange
• Standard format to exchange data (ie College
  transcripts, financial data)
• Can usually identify an Intranet/Extranet when a
  username and password is required to enter.
• Access can be restricted using firewalls and IP
  addresses.
• Firewalls hardware and software

28
Want to Learn More?

• CIS133DA Internet / Web Dev
• CIS235 e-commerce
• Certificate of Completion or Two-Year Degree in
  Web Technology.www.mc.maricopa.edu/dept/d07/deg
  rees.html
